Summary of Contents for Franklin Water Treatment POZ1 Series
- Page 1 Installation Instructions and Owner’s Manual POZ1 Series Backwashing Ozone Generator Filter System Franklin Water Treatment, LLC 12630 US Highway 33 N Churubusco, IN 46723 Phone (260) 693-1972 Fax (260) 693-0602 POZ1 Instruction Manual 220323AF.docx...
-
Page 2: Table Of Contents
Table of Contents Pre-installation Instructions Page 2 Media Types Page 2 General Installation Page 4 Bypass Valve Page 5 Installation Instructions Page 6 General Operation Page 10 Maintenance Page 11 Troubleshooting Guide Page 13 Specifications Page 17 Component Parts Breakdown Page 18 Component Parts List Page 19... -
Page 3: Pre-Installation Instructions
Pre-installation Instructions Description of the filter system: The POZ1 system includes a filtration tank (with gravel and distributor) and a backwashing control valve with ozone generator and bypass valve with plumbing adapters. Filtration media used with the POZ1 system may be of the following types: PART MEDIA... - Page 4 Pre-installation Instructions (cont.) Water Supply This filter will function properly when the water supply is furnished by a jet pump, submersible pump, variable speed (constant pressure) pump or community water supply. As with all other filter systems, however, it is imperative that the well pump provides enough flow rate for the filter to adequately backwash.
-
Page 5: General Installation
General Installation GENERAL INSTALLATION & SERVICE WARNINGS The water conditioner is not designed to support the weight of plumbing. Do not use Vaseline, oils, other hydrocarbon lubricants or spray silicone anywhere. A silicone lubricant may be used on black “O” Rings. This will allow ease of installation and decrease chance of rolling from the bypass and tank connections. -
Page 6: Bypass Valve
Bypass Valve The bypass valve is used to isolate the control valve from the plumbing system's water pressure in order to perform control valve repairs or maintenance. The 1" full flow bypass valve incorporates four positions including a diagnostic position that allows a service technician to have pressure to test a system while providing untreated bypass water to the building. -
Page 7: Installation Instructions
Installation Instructions STEP 1: Unpack filter unit, making sure to remove entire contents of the shipping container prior to disposal. STEP 2: With the filter unit in the upright position, remove the control valve from the mineral tank being careful to not pull the distributor out of the gravel at the bottom of the tank. If the filter model has a “-DH”... - Page 8 Installation Instructions (cont.) Union Meter Injector Housing Brine Refill Elbow Brine Refill Elbow Drain Elbow 3/4” MNPT Retainer Clip with Compression Nut 3/4” FNPT & Tube Insert for 5/8” OD Drain Tube (Retainer Clip not shown) Control Valve Cover FIGURE 2: Top View of Control Valve STEP 10: With the bypass valve handles in the bypass position (Figure 3, Page 5), turn on water supply.
- Page 9 Installation Instructions (cont.) Press the “UP” or “DOWN” buttons until the minutes match the current time. Press the “NEXT” button to return to the main display B) Enter Programming: Press “NEXT” and “UP” (triangle pointing up) buttons simultaneously for 3 seconds. Days Between Regeneration: The upper left of the display will show “DAYS BETWEEN REGEN SET”...
- Page 10 Installation Instructions (cont.) STEP 16: Regenerant Draw Cycle: Plug the transformer into the electrical outlet. DO NOT press the “REGEN” button to advance the control valve to the “REGENERANT DRAW DN” cycle. It must complete the backwash cycle and begin the regenerant draw cycle naturally in order for the ozone generator to turn on.
-
Page 11: General Operation
General Operation USER DISPLAYS When the system is operating, one of several displays may be shown. Pressing NEXT will alternate between the displays. One of the displays is the current time of day. The second display shows days to a regen/gallons remaining (depending on how it is programmed). -
Page 12: Maintenance
Maintenance 1) If your unit contains activated carbon, you should replace the carbon and gravel underbed at least every three years. Replacement may be required sooner if the taste and odor being removed begins to reappear in the treated water or you experience increasing pressure drop that is not resolved by increasing the frequency of backwashing. - Page 13 Maintenance (cont.) 11) If control valve was removed, attach bypass valve to control valve body. 12) If control valve was removed, reattach Drain Line to Control Valve (Figure 6, Page 7). 13) IMPORTANT! Carbon, Filter Ag, Zeolite and Greensand Plus must be soaked for at least 2 hours prior to submitting it to full backwash flow rate to prevent loss of media to drain.
-
Page 14: Troubleshooting Guide
Troubleshooting PROBLEM CAUSES SOLUTIONS 1) Check if display is blank, see “Blank Display” section of Page 14. 2) Check if display has an error message, see “Error Code” section of Page 16. 3) Verify drive motor is connected to A) Filter not circuit board connector J1 (labeled backwashing “MOTOR”) and is not faulty... - Page 15 Troubleshooting (cont.) PROBLEM CAUSES SOLUTIONS Air in system 1) Ensure well system has proper air B) Insufficient soak Loss of media elimination control time before first to drain 2) Check media level and adjust if backwash after necessary installing media 1) Re-plumb the water lines so that the A) Unit is installed supply side of the line is connected to...
- Page 16 Troubleshooting (Ozone Generator) PROBLEM CAUSES SOLUTIONS A) Unit not wired correctly to relay or 1) Correct unit wiring connections and no power verify power is being supplied (12VDC Ozone unit does not B) Unit not from transformer) turn on programmed 2) Correct unit programming correctly 3) Replace fuse...
- Page 17 Troubleshooting (Error Codes) ERROR CODE: CAUSES SOLUTIONS A) Drive motor not 1) Re-insert motor, check for broken wires, inserted fully to verify motor plugged into connector J1 engage pinion or is 1001 – unable to (labeled “MOTOR”) on control valve circuit defective board and reset control valve (hold “NEXT”...
-
Page 18: Specifications
SPECIFICATIONS Description POZ1-1054 POZ1-1248 POZ1-1354 POZ1-1465 Filter Media Volume, cu. ft. Gravel Underbed, lbs. Operating Flow Rate, gpm Continuous @ 5 gpm/ft of media surface area Service @ 10 gpm/ft of media surface area Peak @ 18 gpm/ft of media surface area Backwash @ 10 gpm/ft of media surface area... -
Page 19: Component Parts Breakdown
Component Parts Breakdown... -
Page 20: Component Parts List
Component Parts List Part Ref # Description Number Control valve, cover, 5.3 GPM DLFC, less bypass for models POZ1-1054 & “-DH” POZ1-1054-VLV-L-BP Control valve, cover, 7.5 GPM DLFC, less bypass for model POZ1-1248 & “-DH” POZ1-1248-VLV-L-BP Control valve, cover, 9.0 GPM DLFC, less bypass for model POZ1-1354 & “-DH” POZ1-1354-VLV-L-BP Control valve, cover, 11.0 GPM DLFC, less bypass for model POZ1-1465 &... -
Page 21: Control Valve Breakdown
Control Valve Breakdown... -
Page 22: Control Valve Parts List
Control Valve Parts List Part REF # Description Number CV3002-A Drive Assembly (does not include circuit board or motor) CV3186-06 Power Cord with Transformer, 15 VDC CV3003 Meter and Cable Assembly CV3006 Bypass Valve, Less Fittings CV3998-01FA Front Cover CV3107-01 Drive Motor CV3578HP- Circuit Board... -
Page 23: Ozone Generator Breakdown & Parts List
Ozone Generator Parts List... -
Page 24: Installation Fittings
Installation Fitting Assemblies 3/4" & 1" PVC SOLVENT ELBOW 1" PVC MALE NPT ELBOW Part # Description Part # Description 3/4" & 1" PVC solvent CV3007-01 1" PVC male NPT CV3007 elbow assy elbow assy CV3151 Nut, 1" quick connect CV3151 Nut, 1"... - Page 25 Installation Fitting Assemblies (cont.) 1" BRASS SHARK BITE 3/4" BRASS SHARK BITE Part # Description Part # Description 1" brass shark bite CV3007-13 3/4" brass shark bite CV3007-12 assembly assembly CV3151 Nut, 1" quick connect CV3151 Nut, 1" quick connect CV3150 Split ring CV3150...
- Page 26 Installation Fitting Assemblies 3/4" QUICK CONNECT Description Part # 3/4" QUICK CONNECT QFNCR4 (*2 required) SERVICE WRENCH - CV3193 Although no tools are necessary to assemble or disassemble the valve, the Service Wrench, (shown in various positions on the valve) is available to aid in assembly or disassembly.
-
Page 27: Ten Year Limited Warranty
TEN YEAR LIMITED WARRANTY WARRANTY – Franklin Water Treatment, LLC warrants this water conditioner against any defects that are due to faulty material or workmanship during the warranty period. This warranty does not include damage to the product resulting from accident, neglect, misuse, misapplication, alteration, installation or operation contrary to printed instructions, or damage caused by freezing, fire, flood, or Acts of God.
