Prophete G300N Quick Start Manual

BICYCLE SAT NAV (G300N)
Item Check List
Please check all the following items have been included before starting.
These two tendons
have to be on the
left and right side
of the bracket.
Rubber
G300N
Bracket Micro USB Cable
How to mount the bracket
Cycle Computer
Bracket
Rubber
Use the rubber to tighten the bracket on the handlebar or stem with rubber ties.
Place the GPS cycle computer on the bracket and secure it by turning clockwise.
DISPLAY AND KEY FUNCTIONS
Up Key
Down Key
GPS Indicator
Pause / Return Key
Turn on/off
To start the computer, hold the power key for 3 seconds until bee sound.
Auto Sleep
Auto sleep: When there is no recording after 6 minutes of no speed, and no button pressed
the computer will turn off to save battery.
When there is recording after 1 hour with no speed, and no button pressed the computer
will turn off to save battery.
Rubber ties x4 Cycle
Press Up and Down Key to change mode.
Cycle Bike Page
NOTE: When the corresponding sensors are paired, the Cadence Mode, Heart Rate Mode, and
Power Mode will appear.
The speed must maintain for 8 seconds or more to have
Heart Rate %, and
MAX
Training
Training
Navigation
Navigation
View: Select track press up/down key to switch and press OK to view.
Delete: Select track press up/down key to switch and press OK to delete.
History
History
Setting
Setting
BLE Connect
Customized page
Setting Exercises
Power Key /
Press up/down key to select option.
Backlight
Contrast
General
Setting
Battery Indicator
Set Altitude
Setting Altitude
Backlight
Record / Select Key
Short press on power button to turn ON/OFF backlight.
Set Sensor
Setting Sensor
Cadence Page HR Page Power Page
AVG
Cadence,
MAX
AVG
Power data.
MAX
FTP Test My Workout
View Delete
View Delete Delete All
Profile Sensor Exercises General
GPS System
User page Page Type
System Contrast
Location sync.
Choose Sensor Scan
Set Clock
Setting General System
Clock will automatically adjust when GPS signal has been received.
Set Unit
Setting General System
Set User
Setting Profile User Profile
Record
Under cycle mode press record.
MAINTENANCE
If the display contrast changes and figures become faint, it's time to recharge
the battery. Do not expose cycle computer to extremely cold or hot
Total
temperatures i.e. don't leave the unit in direct sunlight for extended periods of
the time.
TROUBLESHOOTING
AVG
Heart Rate,  Display is black or very light:
MAX
The battery power may be low. Recharge the battery.
Display becomes dark or black:

The unit may be too hot. Place the unit in a shaded area, and it will return to
normal.
The unit operates slowly or struggled:

The unit is too cold. Warm the unit, and it will return to normal.
 Data in display varies enormously:
Check the surroundings for electromagnetic or away from the source of
interference.
Data in display shows slowly:

The unit may be affected by low temperature factor but it does not influence the
function reading when the temperature rises.
Current Speed does not appear:

It may cause by the following situation:
Speed from GPS: GPS signal is weak, please make sure
o
turn on the GPS and move to the outdoor, a wide area
without inter
Altitude
Speed from the sensor: The distance & position is too far,
o
please refer to the sensor's manual and adjust.
Altitude seems not accurate:

The device altitude can be entered for more accurate data.
WARRANTY
The statutory warranty provisions apply. Damage resulting from improper use,
failure to observe the user manual and care instructions, environmental factors,
normal wear and tear, or damage resulting from accidents, a fall/impact, or
modifications to the product are excluded from the warranty. No new warranty
period begins when the item is repaired or replaced.
IMPORTANT HEALTH NOTICE
Please read over the following information before using the GPS computer.
 Never use the GPS computer in combination with other medical / implanted
electronic equipment and device (especially heart pacemakers, EKG equipment,
TENS equipment, cardio-pulmonary machines and pacemaker).
 If you are severely ill or pregnant, please consult your doctor before using GPS
computer.
 Keep this device away from children.
As with most electronic receiving devices, there can sometimes be interference

that causes inaccurate display readouts. Avoid using GPS computer near
common sources of interference. These include high voltage power lines, air
conditioning motor units, fluorescent lights, wristwatches, mobiles and computer.
EN
Clock
Unit
