KROMAX OFFICE-11 Manual

Desk mount for led/lcd monitors
Hide thumbs

Advertisement

Quick Links

Download this manual
ИНСТРУКЦИЯ
DESK MOUNT
FOR LED/LCD MONITORS
Настольный кронштейн для LED/LCD мониторов
15"-34"
38
-86
75 75
MAX
VESA
10
WEIGHT
100 100
kg
FULL MOTION
пожизненная
ГАРАНТИЯ
НАКЛОННО-ПОВОРОТНЫЙ
OFFICE-11
MAX WEIGHT
Нагрузка
10
kg
TILT
Угол наклона
±45°
TURN
Угол поворота
360°
COLOR
Цвет
BLACK
75х75
100х100

Advertisement

loading
Need help?

Need help?

Do you have a question about the OFFICE-11 and is the answer not in the manual?

Questions and answers

Related Manuals for KROMAX OFFICE-11

Summary of Contents for KROMAX OFFICE-11

  • Page 1 ИНСТРУКЦИЯ OFFICE-11 DESK MOUNT FOR LED/LCD MONITORS Настольный кронштейн для LED/LCD мониторов MAX WEIGHT 15"-34" Нагрузка 75 75 TILT VESA WEIGHT 100 100 Угол наклона ±45° TURN Угол поворота 360° COLOR Цвет BLACK 75х75 100х100 FULL MOTION пожизненная ГАРАНТИЯ НАКЛОННО-ПОВОРОТНЫЙ...
  • Page 2 Dear Customer! Thank you for choosing our product. This user manual contains the information about assembling procedure and mounting instructions. Please care- fully learn it and follow the guidelines stated here in order to completely use all the advantages and convenience which our wall mounts give you.
  • Page 3 ATTENTION · ВНИМАНИЕ OFFICE-11 bracket for table mounting LED/LCD monitors and TV-sets with screen sizes 15“-32” inches (38-81 cm) and the maximum total load for 10 kg. • This bracket is designed for tabletop mounting. Included accessories are designed exclusively for attachment to the table.

  • Page 4: Complete Set

    COMPLETE SET · КОМПЛЕКТАЦИЯ Ø4 4 Ø5 4 M4*8mm x 4 M4 *12mm x 4 M5*8mm x 4 M5*12mm x 4 M6*8mm x 4 M6*12mm x 4 S=4 x 1 S=5x 1 S=6 x 1 NECESSARY TOOLS Ø10...
  • Page 5 ШАГ STEP Install the bracket to the desk - Select right holes on the mount (1) according to the thickness of desk. - Insert the mount (1) to the edge of the desk then tighten the knob to fix it firmly. Монтаж...
  • Page 6 ШАГ STEP Install the bracket on the top of desk - Remove the mount (1) from the bracket at first. - Install the mount (2) to the bracket. - Install the bracket to the top of the desk. Screw must pass through the hole. The diameter of hole have to from 8.5mm to 70mm.
  • Page 7 ШАГ STEP Install the bracket to the side part of the desk - Remove the clamping fixture from the mount (1) at first. - Attach the bracket to the side part of the desk then fix it with the six screws as shown in the picture. ATTENTION: Before installing the bracket, make sure that this variant is reliable and one can stand the total load of bracket and the monitors.
  • Page 8 ШАГ STEP - Insert the arm component to the tube, then tighten the knob to fix the arm component to a proper height on the tube. - Установите кронштейн на штангу и зафиксируйте его на нужной высоте с помощью регулировочной ручки.
  • Page 9 ШАГ STEP /D/E/F/G/H - Screw two bolts on the back of TV, don’t tighten it. Note: The washer (A/B) is only used for bolts (C,D,E or F). - Закрутите два винта на задней части монитора таким образом, чтобы остался зазор. Примечание: Шайбы (A/B) использовать только с винтами (C,D,E,F).
  • Page 10 ШАГ STEP /D/E/F/G/H - Insert the two bolts into the holes on the TV plate, then put the display on the plate slowly. - Install the other two screws, and screw all four screws down at last. - Аккуратно установите монитор на пластину кронштейна. - Вкрутите...
  • Page 11 ШАГ STEP - Please keep the arm level during tension adjustment. Use a proper Allen key to slightly loosen or tighten the adjust ment screw according to the display weight. - If display settles on its own, rotate adjustment screw towards the “+” symbol. - If display rises on its own, rotate adjustment screw towards the “-”...
  • Page 12 ШАГ STEP - This model includes a cable management feature. Remove the separation blades at first, then insert the cables into plastic terminal block, put back the separation blades on the plastic - Данный кронштейн имеет дополнительные кабель-каналы, для скрытой проводки всех соединительных кабелей.
  • Page 13 СХЕМА · SCHEME 100 mm 75 mm...

  • Page 14: Warranty

    The company Kromax provides a manufacturer’s warranty on all welded and mechanical connections of this item during the entire life period. In the event of a defect, the product will be repaired or replaced free of charge. Should the model be out of production, the company Kromax reserves the right to replace it for an equal cost and functionality.
  • Page 15 ЗАМЕТКИ · NOTE...
  • Page 16 Подробная информация на WWW.KROMAX.RU...
