SPECIFICATIONS
Part Number: 116844
Set Up Size:185"L x 75"W x 81"H
Packed Size:75"L x 49"W x 26"H
W e i g h t: 190 lbs.
Fishable Area: 68 sq.ft
Instructions: 106993
Please contact customer service directly at the E-mail or phone number listed below for any
quality issues. ONCE USED THIS PRODUCT CANNOT BE RETURNED TO STORE.
** Warranty cannot be honored without an original, dated receipt **
IMPORTANT-PLEASE READ:
This product is warranted to the original retail purchaser (from an authorized dealer) and is non-transferable.
Clam Outdoors has a three-year manufacturer's defect warranty from the date of original purchase. Warranty
does not cover cracked or worn bases (if runner kits have not been installed as recommended), cracked
windows, tent tears or cuts, or broken or bent hoops due to high wind weather conditions or unattended use.
Defective parts will be replaced or repaired (at the manufacturer's option) if found to be defective within three
years from the date of original purchase. Warranty will be void if product has been subject to neglect, misuse,
improper installation, misapplication, alteration, accident including but not limited to improper maintenance, or
use of unauthorized parts or attachments. Please read the entire owner's manual to ensure proper installation,
use, storage and care of your Clam Shelter.
To submit a warranty claim request, please use one of the following methods:
https://clamoutdoors.com/pages/warranty-form
▪ Email:
customerservice@clamcorp.com
In your request, please include your full name, address, phone number, a copy of your receipt, a brief description
of the problem, and pictures to clearly show the area(s) of concern. Our Warranty Department will review your
request, and a Clam representative will contact you regarding your claim status. All returns must be shipped to
us postage pre-prepaid.
It is expressly understood that Clam Outdoors Inc., liability for its products, whether due to breach of
warranty, negligence, strict liability, or otherwise, is limited to the repair of the product as stated above. Clam is
not liable for any injury, loss, damage, or expense, whether direct or consequential, including but not limited to loss
of use, income, profit, or damage to material arising in connection with the sale, installation, use of, inability to
use, or the repair or replacement of Clam products. Clam reserves the right to make alterations or
modifications in its products at any time, which in its opinion, may improve the performance and efficiency of
the product. Clam shall not be obligated to make such alterations or modifications to products already in service
Clam contact information
Customer Service Hrs: 9am to 4pm, Monday – Friday Central Standard Time
Clam Outdoors
Attn: Customer Service
12135 Brockton Lane
Rogers, MN 55369
Phone: 763-231-4120
FISH TRAP BUILD VIDEO
CLAMOUTDOORS.COM
WARRANTY INFORMATION
** REGISTER YOUR PURCHASE ONLINE AT CLAMOUTDOORS.COM **
LIMITATION OF LIABILITY
MODEL 16844

Advertisement

loading
Need help?

Need help?

Do you have a question about the 400XT PRO THERMAL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Clam 400XT PRO THERMAL

  • Page 1 It is expressly understood that Clam Outdoors Inc., liability for its products, whether due to breach of warranty, negligence, strict liability, or otherwise, is limited to the repair of the product as stated above. Clam is not liable for any injury, loss, damage, or expense, whether direct or consequential, including but not limited to loss of use, income, profit, or damage to material arising in connection with the sale, installation, use of, inability to use, or the repair or replacement of Clam products.
  • Page 2: Parts List

    PARTS LIST QTY. PART NO. DESCRIPTION 104904 BASE, X400 104892 HOOP POLE, X400 104897 HALF HOOP POLE, X400 114271 LARGE DIMMABLE LIGHT STICK 106944 TENT, X400, THERMAL 104922 SPREADER POLE KIT, X400 104913 ROOF SPREADER POLE 104915 ADJUSTABLE SPREADER POLE 102759 DELUXE SEAT 101249...
  • Page 3 HARDWARE FASTENERS REFERENCE...
  • Page 4: Step 1 - Seat Assembly

    STEP 1 – SEAT ASSEMBLY Parts Needed for Step 1 Part Number Description Quantity 104905 SEAT TUBE 101429 SEAT TUBE PLUG 101048 BLOCK SLIDE (CIRCLE) 104674 BLOCK SLIDE (OVAL) 101146 EXTRUSION CHANNEL 105478 SWIVEL, SEAT 102759 ASSY, DELUXE SEAT 103810 RETAINING BRACKET 103811 RETAINING BRACKET...
  • Page 5 B. Assemble the Block Slides #101048 (circle) and #104674 (oval) onto Extrusion Channels #101146. C. Install #101147 screws into Block Slides. SAME BLOCK STYLE MUST BE ALIGNED TO EACH OTHER (e.g. oval aligned with oval) D. Rotate Seat Swivel #105478 45 degrees so its star shaped and all slotted holes are accessible. E.
  • Page 6 G. Slide the Seat Tubes through the Block Slides. TIP: APPLY SILICONE SPRAY TO SEAT TUBES TO ALLOW ASSEMBLY TO SLIDE EASIER. H. Install the Retaining Brackets #103810 and #103811 onto the ends of the Seat Tubes using #106456 bolts and #106284. Completed seat assembly being installed onto sled Insert Seat Cover Back #107351 and Bottom #107352 onto completed deluxe seat...
  • Page 7 STEP 2 – LIGHT STICK ASSEMBLY Parts Needed for Step 2 Part Number Description Quantity 104897 HALF HOOP POLE 114271 LARGE LIGHT STICK 106410 LIGHT CORD STORAGE BAG A. Install Light Stick #114271 into the #104897 Half Hoop Poles to make the light stick hoop assembly.
  • Page 8 STEP 3 – BATTERY BRACKET A. Choose which location you’d prefer to have the battery located (battery not included). Light stick cord will need to be able to reach battery. Since there are two light sticks it’s recommended to install the Battery Bracket in the center of the flat back end of the sled.
  • Page 9 STEP 4 – POLE MOUNTING BRACKETS Parts Needed for Step 4 Part Number Description Quantity 101900 MOUNTING BRACKET 101901 MOUNTING BRACKET 106286 SCREW, 1/4-20 X 0.75 106284 NUT, 1/4-20, NYLOCK A. Align the Mounting Brackets #101900 and #101901 so the open end of brackets face the inside of sled.
  • Page 10 STEP 5 – CANOPY SUPPORT POLES Parts Needed for Step 5 Part Number Description Quantity 104894 STRAIGHT CANOPY SUPPORT POLE 104896 BENT PORCH SUPPORT POLE 106331 SCREW, 1/4-20 X 2.50 106284 NUT, 1/4-20, NYLOCK A. Working on one Mounting Bracket, begin by installing the Straight Canopy Support Poles #104894, starting with the back position and working forward.
  • Page 11 STEP 6 – PUTTING SEATS INTO SHELTER A. Put seat assemblies into shelter. Start by putting the Retaining Bracket with the lipped end in first. STEP 7 – HOOP POLES Parts Needed for Step 6 Part Number Description Quantity 104892 HOOP POLE 103605 LARGE RPSX COLLAR...
  • Page 12 A. Put RPSX Collars #103605 onto the Light Stick Hoop Assemblies and Hoop Poles #104892. Align RPSX Collars with the holes in the pole as shown Collar tab is situated inside of hoop pole tube TIP: Twist the lever on the RPSX Collars 90 degrees to allow for easier installation onto Hoop Pole.
  • Page 13 B. Install Light Stick Hoop Pole Assemblies first, making sure the cords of the light sticks are facing the Battery Bracket. C. Continue installing the Hoop Poles, alternating from each end of the shelter as you go. D. Using the Spreader Pole Kit #104922, clip the three roof spreader poles into the shelter.
  • Page 14 STEP 7 – HOOP POLES Parts Needed for Step 6 Part Number Description Quantity 106944 TENT, X400, THERMAL 103605 LARGE RPSX COLLAR 106286 SCREW, 1/4-20 X 0.75 101081 WASHER, 1/4 FLAT 106284 NUT, 1/4-20, NYLOCK A. Drape the Tent (part #106944) over the Hoop Poles. Attach the tent to the poles on the inside with the Velcro straps.
  • Page 15 FOLDING SEQUENCE IMPORTANT!! WHEN COLLAPSING THE X400 SHELTER IT IS VERY IMPORTANT TO COLLAPSE THE LIGHT STICK HOOP POLES FIRST (#1 & #2 in diagram below) AND TO UNDO THE WALL VELCRO ON THESE TWO POLES TO RELIEVE TENSION ON THE TENT. FAILURE TO DO SO MAY CAUSE THE TENT TO TEAR AT THE CORNERS AND WILL NOT BE COVERED UNDER WARRANTY.
  • Page 16: Tips For Use

    (NOTE: Pulling behind an ATV or snowmobile may result in premature wear of the base). ▪ In windy conditions it is advised to secure your shelter to the ice using Clam’s Ice Anchor Kit (PN 108064) and Ice Anchor Installation Tool (PN 108348).
  • Page 17: Safety Instructions

    SAFETY INSTRUCTIONS Please fully understand and follow all safety instructions as outlined. Failure to do so could result in severe injury or death. ▪ DO NOT USE OPEN FLAME HEATERS IN YOUR ICE SHELTER. INJURY OR DEATH MAY RESULT FROM FIRE IF TENT FABRIC IS EXPOSED TO OPEN FLAME. THE TENT IS NOT FIREPROOF, BUT THE FABRIC IS TREATED WITH A FIRE RETARDANT THAT MEETS CPAI-84 SPECIFICATIONS.
  • Page 18: Frequently Ask Questions

    FREQUENTLY ASK QUESTIONS Fish Trap FAQ’s Q: Should I install a runner kit/hyfax to the base of my shelter? A: The warranty on our shelters does not cover cracked or worn bases if a runner kit has not been installed. Additionally, bases will wear much quicker without a runner kit installed. Q: The zipper on my shelter freezes up and/or sticks.
  • Page 19 begin to flake off, especially along the folds in the fabric when the shelter is collapsed. This does not affect the function of the fabric. If you feel that too much light is now entering your shelter in the places where some of the coating has come off, you may wish to apply a new layer of rubberized coating.
