Model No.
- 9534 -
p/n 109534
S p e c i f i c a t i o n s
H e i g h t - 5 6 " ( 1 4 " p a c k e d )
Width - 3 5 "
Depth - 8 8 " ( 4 3 " p a c k e d )
W e i g h t – 5 0 l b s .
Instructions – 1 0 3 9 9 6
* * * * * * W a r r a n t y I n f o r m a t i o n * * * * * *
NOTICE!!! Please contact customer service directly at the E-mail
** Warranty cannot be honored without an original, dated receipt **
IMPORTANT - PLEASE READ:
This product is warranted to the original retail purchaser (from an authorized dealer) and is non-transferable. Clam
Corporation has a one year manufacturer's defect warranty from the date of original purchase. Warranty does not cover
cracked or worn bases (if runner kits have not been installed as recommended), cracked windows, tent tears or cuts, or
broken or bent hoops due to high wind weather conditions or unattended use. Defective parts will be replaced or repaired
(at the manufacturer's option) if found to be defective within one (1) year from the date of original purchase. Warranty will
be void if product has been subject to neglect, misuse, improper installation, misapplication, alteration, accident including
but not limited to improper maintenance, or use of unauthorized parts or attachments. Please read the entire owner's
manual to ensure proper installation, use, storage and care of your Clam Shelter.
To submit a warranty claim request, please use one of the following methods:
Email:
CustomerService@ClamCorp.com
Phone
763-231-4120
Fax:
763-231-4121
Customer Service – Warranty Department
Write:
12135 Brockton Lane North
Rogers, MN 55369
In your request, please include your full name, address, phone number, a copy of your receipt, a brief description of the
problem, and pictures to clearly show the area(s) of concern. Our Warranty Department will review your request, and a
Clam representative will contact you regarding your claim status. All returns must be shipped to us postage pre-prepaid. .
It is expressly understood that Clam Corporation's liability for its products, whether due to breach of warranty,
negligence, strict liability, or otherwise, is limited to the repair of the product as stated above. Clam Corporation is not
liable for any injury, loss, damage, or expense, whether direct or consequential, including but not limited to loss of use,
income, profit, or damage to material arising in connection with the sale, installation, use of, inability to use, or the
repair or replacement of Clam Corporation products. Clam Corporation reserves the right to make alterations or
modifications in its products at any time, which in its opinion, may improve the performance and efficiency of the
product. Clam shall not be obligated to make such alterations or modifications to products already in service.
Due to Clam's continued product improvements, Clam reserves the right to change specifications without
notice. For complete details see the assembly and or operating instructions that are provided and packed
with the purchased product.
or phone number listed below for any quality issues
(Preferred Method)
- L i m i t a t i o n o f L i a b i l i t y -

Advertisement

loading
Need help?

Need help?

Do you have a question about the Dave Genz LEGACY Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Clam Dave Genz LEGACY Series

  • Page 1 It is expressly understood that Clam Corporation’s liability for its products, whether due to breach of warranty, negligence, strict liability, or otherwise, is limited to the repair of the product as stated above. Clam Corporation is not liable for any injury, loss, damage, or expense, whether direct or consequential, including but not limited to loss of use, income, profit, or damage to material arising in connection with the sale, installation, use of, inability to use, or the repair or replacement of Clam Corporation products.
  • Page 2 -PARTS LIST- PART NUMBER DESCRIPTION QTY. 103915 BASE, SCOUT 13/14 103916 HOOP, CANOPY, TRAPPER/SCOUT 103900 TENT, SCOUT TC BIG MOUTH 101399 SWIVEL, SEAT 103614 ASSY, FOLDING SEAT 102814 EXTRUSION, V-CHANNEL 103996 INSTRUCTION, SCOUT EXP 13/14 109222 KIT, TOOL KIT 101095 ROPE, 3/8 DIA X 9 FT TOW 103030 ASSY, SEAT, SLIDE TUBE...
  • Page 3 STEP 1 Install (2) Brackets, PN 103833 STEP 2 Install Front seat mount tube, PN 103100...
  • Page 4 STEP 3 Assemble the seat mount brackets. STEP 4 Rotate the top of the swivel 45 degrees and mount it to the seat mount brackets. Mount the seat to the swivel.
  • Page 5 PN103046 and setting the front slide bracket onto the front seat mount tube PN103100. Spring Plunger The Clam Seat. The Clam seat is adjustable. Simply position it at the angle of preference. To lay the seat to flat pull just past vertical and the seat will release and lay down.
  • Page 6 STEP 6 Install the tube spacer caps PN 101083 onto all of the hoop poles PN 103916. STEP 7 Install (3) of the hoop poles Assembled in Step 6 to Brackets PN 103834, left and right hand sides. Pole assembled in Step 6 Leave the front hole of the Bracket PN103834 open for the front porch pole.
  • Page 7 STEP 8 Start the Expanding Porch pole assembly Insert PN 103770 onto pole PN 103923. Make sure to push on thumb button when pushing it on. Insert pole PN 103922 into PN 103770.
  • Page 8 STEP 9 Assemble the two corners of the EXP bar, left and right hand side. 103923 103921 Spreader portion assembled in Step 8.
  • Page 9 STEP 10 Assemble bracket #103834 with poles to bracket #103833 by inserting #101486 Bolt through: -103834 Bracket with poles. -103835 Nylon washer. -103833 Bracket. -101081 Washer -101082 Nut.
  • Page 10 STEP 11 STEP 12 Install spreader pole PN101074 And (2) “S” Clips PN 103623 Do not install the Expandable porch pole at this time. This will be installed in Step Install the Tow Rope PN 101095. Knot each end of the rope after routing the rope through the base.
  • Page 11 STEP 13 Install the Expandable Porch Pole through the sleeve in the front of the tent and then attach it to the front portion of the bracket. See Step 13 Cont’d. -The porch pole is not shown going through the Sleeve for easier viewing.
  • Page 12 STEP 13 Cont’d...
  • Page 13 STEP 14 To “set ” t he t ent , g ra sp the t ent mate r ia l at th e re ar o f th e she lt er an d pu l l it d own wa rd . Obs erv e th e por ch ar ea o f the t ent l i ft ing ac c o rd in gl y a s y o u pu l l.
  • Page 14 STEP 15 CATCH SOME BIG FISH!!! Visit the Clam and Ice team websites for product tips, fishing techniques, and NEW and innovative products THE SPREADER POLE The Spreader Poles can attach to any pole you wish by snapping it to the chosen pole with the two provided “S”...
  • Page 15 Pulling behind an ATV or snowmobile may result in premature wear of the base). ▪ In windy conditions it is advised to secure your shelter to the ice using Clam’s Ice Anchor Kit (PN 108064) and Ice Anchor Installation Tool (PN 108348).
  • Page 16: Frequently Asked Questions

    Q: What will help keep mice or rodents from eating the tent of my Clam or Fish Trap? A: We recommend that you keep your tent in a sealed plastic tote with laundry dryer sheets or moth balls. If the shelter is stored in a barn or shed take the tent off the house and store it in a rodent-free environment such as in your home.
  • Page 17 We are only set up to ship warranty or replacement parts required to MAINTAIN a Clam shelter (tents, poles, parts, patch kits, etc.). No accessories – see a local dealer or an online dealer of Clam products. If the replacement parts are not warranty you will be charged for the product plus actual shipping charges.
