  • Page 1 Connect XL Single landscape Manual...

  • Page 2: Table Of Contents

    Manual Connect XL Single landscape TABLE OF CONTENTS INTRODUCTION About this document Other relevant documents Symbols used in this manual WARRANTY AND LIABILITY Warranty Liability PRODUCT INFORMATION Intended use Specifications Requirements for the work environment SYSTEM AND APPLICATION 1. Components SAFETY 1.

  • Page 3: Introduction

    Manual Connect XL Single landscape INTRODUCTION ABOUT THIS DOCUMENT This manual covers the installation instructions for the Blubase Connect XL mounting system for solar panelsonflatroofswithroofingmaterialsmadeofconcrete,bitumen,EPDM,andPVC.Forotherroof materials,pleasecontactyoursupplier. The mounting system is suitable for mounting solar panels in a single landscape orientation.

  • Page 4: Warranty And Liability

    Blubase extends a 20 year product warranty. The warranty is subject to the warranty terms and general terms & conditions of Blubase. These can be found on the website www.blubase.com. LIABILITY Blubase accepts no liability for damage or injury caused by the failure to comply (strictly) with the safety guidelinesandinstructionsinthismanual,orbynegligenceduringinstallationoftheproductandthe accessories listed in this document.

  • Page 5: Product Information

    Manual Connect XL Single landscape PRODUCT INFORMATION INTENDED USE TheBlubaseConnectXLSinglemountingsystemisintendedformountingsolarpanelsonflatroofs. With this mounting system you can install solar panels with the long side at the bottom (landscape). The mounting system is intended to be installed in a single arrangement. SPECIFICATIONS...

  • Page 6: System And Application

    Manual Connect XL Single landscape SYSTEM AND APPLICATION 1. COMPONENTS Component 1) Connect XL base element 8) Easymidclamp 2) Connect back plate 9) Easyendclamp 3) Connect ballast tray 10) ConnectXLsidedeflectorleft 4) Connect Solarsteller 11) ConnectXLsidedeflectorright 5) Connect leveling block 12) Connect cable grommet...

  • Page 7: Safety

    Always use a lifting aid or hoisting device when moving heavy equipment. Caution! Neverwalkonthesystemoronthesolarpanels. Blubase is in no way responsible for the installation and/or connection of lightning protection on the roof. Get expert advice from your specialist and ensure that a safe installation can be guaranteed accordingtoEN-IEC62305andHD-IEC60364.

  • Page 8: Installation

    Manual Connect XL Single landscape INSTALLATION 1. PREPARATION Inspect the roof. The roof is in good condition. Theroofconstructionhassufficientbearingcapacitytosupporttheinstallation,takinginto account wind and snow loads. Check the project plan and components. Check the project plan. Check that all components are present (page 5).
  • Page 9 Manual Connect XL Single landscape 5  Drawthelinesofthefieldandmakenoteoftheorientationofthenortharrow. Usethe3-4-5ruletomakesuretheanglebetweenyourperpendicularlinesis90degrees. Consult the project plan to determine the position of the base elements for your project. Take the starting point of the installation from the project plan. 90º 6  MarkthepositionofthefirstConnectXLbaseelement. Bemindfuloftheedgezone.Consulttheprojectplantodeterminethepositionofthefirstbase element.

  • Page 10: Place The Base Elements

    Manual Connect XL Single landscape 2. PLACE THE BASE ELEMENTS 1  Placethefirstbaseelementontheroofandalignthebaseelementwiththemarkedlines. Optional: Add friction mats underneath the base plates of each base element.
  • Page 11 Manual Connect XL Single landscape Situational: Place leveling blocks underneath the feet of each element when installing on roofs with pebbles. Make sure the pebbles on the roof are level with the leveling blocks. Onlyuselevelingblocksonroofswithpebbles.Donotuselevelingblockstoraisethesystemfrom theroof,asthisheavilyincreasesthewindloadonthesolarpanels. Remove all pebbles and debris from the positions of the leveling blocks.
  • Page 12 Manual Connect XL Single landscape Place the next base element on the roof. Tilt up the high base until it clicks into upright position. Click! 8  UsetwoSolarstellerstoalignthebaseelementsperpendicularatthecorrectdistance. Repeat steps 2.1. - 2.8. for every module of the row.
  • Page 13 Manual Connect XL Single landscape 9  Extendthesegmentbyinsertingthecouplerintotheendofthebaseelementuntilitclicksinto place. Click! 10 Tilt up the high base of the base element until it clicks into upright position. 11 Slide the base element over the coupler until it clicks into place. Tip:Inthismanual,thebaseelementsareinstalledinsouthorientation.foreast-westorientation, horizontally rotate every second base element 180 degrees.
  • Page 14 Manual Connect XL Single landscape 12 Realign the base elements using at least two Solarstellers.

  • Page 15: Place Ballast

    Manual Connect XL Single landscape 3. PLACE BALLAST Thecalculatordeterminestheballastneededforyourproject.Followtheinstructionsfromthe projectplandeterminedbythecalculator.Ifanythingchangesinthelayoutofthesolarpanelfield, the ballasting has to be recalculated. 1  Placetheballasttrayoverthebaseelementinthepositionspecifiedintheprojectplan. Align the cut-outs in the ballast tray with the hole and lip of the base element. 3  Fixtheballasttraytothemodulewithtwoscrews. 4  Situational:Placeasecondballasttrayinfrontofthefirstballasttray.
  • Page 16 Manual Connect XL Single landscape 7  Placethefollowingballasttrayoverthenextbaseelement,partiallyoverlappingthefirstballast tray. Align the cut-outs in the ballast tray with the hole and lip of the base element. 9  Fixtheballasttraytothemodulewithtwoscrews. 10  Evenlydistributebricksovertheballasttrays. Followtheprojectplanfortherequiredpositionsandquantitiesofballast. Whenusingalternativeballastforms,thecalculatedweightpertraymustbemet.Additionally,the ballast must be properly contained within the trays at all times.’...

  • Page 17: MountingTheFirstSolarPanel

    Manual Connect XL Single landscape 4. MOUNTING THE SOLAR PANELS Donotmountanysolarpanelsiftheremaybestrongwindsinthetimebetweenmountingthesolar panelandwinddeflectors.Immediatelymountthewinddeflectorsaftermountingafieldofsolar panels. Place the solar panel upright on two low bases between the guides. Carefully lower the solar panel on the high bases.
  • Page 18 Manual Connect XL Single landscape Mount the end clamps on the high and low base and tighten the screw using a 8mm hex tool. Apply atorqueof8Nm. See appendix A for cable management instructions. Place the solar panel upright on two low bases between the guides.
  • Page 19 Manual Connect XL Single landscape Mount the mid clamps on the high and low base and tighten the screw using a 8mm hex tool. Apply atorqueof8Nm. Repeat steps 4.4. - 4.6. for every panel of the row. Mount the end clamps on the high and low base of the last panel of the row and tighten the screw...
  • Page 20 Manual Connect XL Single landscape 8  Attachagroundingcabletothehighbase(A)orbaseelement(B)ofeachsolarpanelfield.

  • Page 21: Placing Back Plates

    Manual Connect XL Single landscape 5. PLACING BACK PLATES Place the back plate in the designated slots in the high bases and tilt the back plate up against the high base. Align the back plate with the high base 3  Securethebackplatetothefirsthighbasewithtwocladdingscrews.Usea3/8"socket.
  • Page 22 Manual Connect XL Single landscape Place the next back plate in the designated slots in the high bases. 5  Tiltthebackplateupandalignthebackplatewiththesolarpanel,overlappingthefirstbackplate. 6  Securebothbackplatestothehighbasewithtwocladdingscrews.Usea3/8"socket. Repeat the steps in this chapter for all back plates.

  • Page 23: InstallingSideDeflectors

    Manual Connect XL Single landscape 6. INSTALLING SIDE DEFLECTORS 1  Placethesidedeflectorinthedesignatedslotsinthebaseelementandaligntheholesinthe deflectortothenotchesinthebaseelement. 2  Insertthecablegrommetintothesidedeflector. 3  Securethesidedeflectortothebaseelementandhighbasewithtwocladdingscrews.Usea3/8" socket. Repeatthestepsinthischapterforallsidedeflectors.

  • Page 24: Placing End Caps

    Manual Connect XL Single landscape 7. PLACING END CAPS 1  Optional:ifyouaregoingtoinstallendcapsontheouterbaseelementsofthesegment,movethe footatthelowbaseofthefirstbaseelementintherowoneslotbackwards. 2  Optional:Placeendcapsonthefirstandlastbaseelementsofeveryrow. Click!

  • Page 25: Annexes

    Manual Connect XL Single landscape ANNEXES A. Cable management Mount the optimizer to the predrilled screw hole of a base element for every row. Iftwoballasttraysareinstalledonthebaseelement,drillaholenexttotheballasttraysinthe base element and mount the optimizer to the base element. Guide the solar panel cables through cable guides at the front of the high bases.

  • Page 26: Spare Parts List

    Manual Connect XL Single landscape Spare parts list Generic name Art. Code Description Base element 500175 Connectbaseelement,landscape,pw=1130-1150,Magnelis Ballast tray 500530 Connectballasttray,landscape,pl=1663-1778,L=1901,Magnelis 500531 Connectballasttray,landscape,pl=1779-1894,L=2017,Magnelis 500532 Connectballasttray,landscape,pl=1895-2010,L=2133,Magnelis 500533 Connectballasttray,landscape,pl=2011-2126,L=2249,Magnelis 500500 Connectballasttray,portrait,pw=1035-1150,L=1273,Magnelis Back plate 500240 Connect back plate 72-cell panels 500245 Connect back plate 72-cell panels large...
