- Page 1 Landscape South Manual...
-
Page 2: Before You Get Started
PV system. While care has been taken when producing the calculations and dimensions in the Blubase calculation tool, no rights can be derived from them. The prices are indicative and may vary; for example, due to rising prices of raw materials. - Page 3 The Magnelis steel and the aluminium take care of equalisation. They prevent tension from building up in the material and failures from occurring in the inverters or microinverters. (NEN 1010:2015) TIP: Use this point to earth. Blubase Lingenstraat 9 8028 PM Zwolle, Nederland T. (+31) 085-8000 501 info@blubase.nl...
-
Page 4: Mounting Plan
Manual MOUNTING PLAN STAP 1 Use the mounting plan and the ballast plan from the Blubase calculation tool. Determine the first mounting point within the free edge region (see Page 5) and continue working North to South from there. UNDERLYING ELEMENTS STAP 2 ake the basic component and always click the stand to its upright position first. - Page 5 Repeat these steps for all rows to carry out the mounting plan. The next page contains instructions on using the Measuring profile. Solar panel dimensions Solar panel dimensions Solar panel dimensions Blubase Lingenstraat 9 8028 PM Zwolle, Nederland T. (+31) 085-8000 501 info@blubase.nl...
- Page 6 TIP: From the outset, be sure to use right angles of 90º. If you do, the mounting system will always be straight and the solar panels will always fit. Blubase Lingenstraat 9 8028 PM Zwolle, Nederland T. (+31) 085-8000 501 info@blubase.nl...
-
Page 7: Solar Panels
Click the clamps into the basic component and turn them tight (torque of 8–10 Nm). * There is little difference between mounting landscape and portrait set-ups. In case of portrait mounting, there are three clamp positions and two stands. Blubase Lingenstraat 9 8028 PM Zwolle, Nederland T. -
Page 8: Cable Management
The cable tray contains a shielded area for the other cables. A cable clip has already been pre-mounted. Blubase Lingenstraat 9 8028 PM Zwolle, Nederland T. (+31) 085-8000 501 info@blubase.nl... -
Page 9: Rear Panels
Torque: 5Nm TIP: It goes without saying that you do not need a rear plate for an East-West set-up, as the solar panels will protect against the wind themselves. Blubase Lingenstraat 9 8028 PM Zwolle, Nederland T. (+31) 085-8000 501 info@blubase.nl... - Page 10 If you are working with gravel or you wish to elevate the mounting system for another reason, consider the use of our raising blocks. They fit neatly underneath the bases of a basic component. Blubase Lingenstraat 9 8028 PM Zwolle, Nederland T. (+31) 085-8000 501 info@blubase.nl...
- Page 11 East-West Connector 2300 2980 Article No 500050 1320 Connector 1320 2000 Article No 500013 1500 Connector 1500 2180 Article No 500015 1700 Connector 1500 2380 Article No 500017 Blubase Lingenstraat 9 8028 PM Zwolle, Nederland T. (+31) 085-8000 501 info@blubase.nl www.blubase.com...
- Page 12 Connect Landscape Manual BACK PLATES BALLAST BOXES * above 1620mm the PV-panel is no longer supported at the bottom. Check the manual if this is allowed. Blubase Lingenstraat 9 8028 PM Zwolle, Nederland T. (+31) 085-8000 501 info@blubase.nl www.blubase.com...
- Page 13 12 metres. If the building is taller, please contact Blubase in advance for a project-specific, customised solution. • • If a flat roof is sloping more than four degrees, the Blubase connect mounting system must be secured/anchored to prevent movement. • •...
