- Page 1 INSTALLATION AND OPERATING INSTRUCTIONS WCH60D CERAMIC HOB Please read before attempting to install or use this appliance. It is recommended that you keep this user manual in a safe place.
- Page 2 WELCOME Thank you for choosing Willow for your new appliance. Your item is pre-registered and your warranty starts from the point of purchase: all you need to do is keep hold of your proof of purchase. We are proud to provide a range of appliances that have been designed with the consumer in mind.
-
Page 3: Installation
Installation Electrical Shock Hazard Disconnect the appliance from the mains electricity supply before carrying • out any work or maintenance on it. Connection to a good earth wiring system is essential and mandatory. • Means for disconnection must be incorporated in the fixed wiring in •... - Page 4 The use of inappropriate guards can cause accidents. Failure to install the appliance correctly could invalidate any warranty or • liability claims. Regarding the details of installation, thanks to refer to the section • <Installation>. Operation and maintenance Electrical Shock Hazard Do not cook on a broken or cracked cooktop.
- Page 5 of children. Failure to use caution could result in injury or cuts. • Important safety instructions Never leave the appliance unattended when in use. Boilover causes smoking • and greasy spillovers that may ignite. Never use your appliance as a work or storage surface. •...
- Page 6 If the supply cord is damaged, it must be replaced by the manufacturer, its • service agent or similarly qualified persons in order to avoid a hazard. This appliance is intended to be used in a domestic household environment • only! Commercial use of any kind is not covered under the manufacturer's warranty! WARNING: The appliance and its accessible parts become hot during use.
- Page 7 Congratulations on the purchase of your new hob. We recommend that you spend some time to read this Instruction / Installation Manual in order to fully understand how to install correctly and operate it. Read all the safety instructions carefully before use and keep this Instruction / Installation Manual for future reference.
-
Page 8: Product Information
Product Information The ceramic hob can meet different kinds of cuisine demands because of resistance wire heating, micro-computerized control and multi-power selection, really the optimal choice for modern families. The hob centers on customers and adopts personalized design. The hob has safe and reliable performances, making your life comfortable and enabling to fully enjoy the pleasure from life. - Page 9 Always lift pans off the ceramic hob – do not slide, or they may scratch the glass. Using your Hob To start cooking After power on, the buzzer beeps once, the indicators light up for 1 second • then go out, indicating that the hob has entered the state of standby mode. 1.
- Page 10 to left to“OFF”. The Residual heat indicator will flash. Turn the whole cooktop off by touching the ON/OFF control. Beware of hot surfaces Residual heat indicator will flash which means cooking zone is too hot to touch. It will disappear when the surface has cooled down to a safe temperature.
-
Page 11: For Stir-Frying
Using a lid will reduce cooking times and save energy by retaining the heat. • Minimise the amount of liquid or fat to reduce cooking times. • Start cooking on a high setting and reduce the setting when the food has •... - Page 12 Heat Settings Heat setting Suitability • delicate warming for small amounts of food 1 - 2 • melting chocolate, butter, and foods that burn quickly • gentle simmering • slow warming • reheating 3 - 4 • rapid simmering • cooking rice •...
- Page 13 Boilovers, melts, Remove these immediately • Remove stains left by with a fish slice, palette melts and hot sugary spills knife or razor blade scraper sugary food or spillovers suitable for ceramic glass as soon the glass cooktops, but beware of as possible.
- Page 14 Unsuitable, abrasive ‘Choosing the right scourer or cookware’. Cleaning products being used. See ‘Care and cleaning’. Technical Specification Ceramic Hob WCH60D Cooking Zones 4 Zones Supply Voltage 220-240V~ 50Hz / 60Hz Installed Electric Power 6000W Product Size D×W×H(mm) 590×520×50 Building-in Dimensions A×B (mm) 560×490...
- Page 15 H(mm) D(mm) A(mm) B(mm) X(mm) WCH60D mini Under any circumstances, make sure the hob is well ventilated and the air inlet and outlet are not blocked. Ensure the hob is in good work state. As shown below Note: The safety distance between the hotplate and the cupboard above the...
- Page 16 A(mm) B(mm) C(mm) 50 mini 20 mini Air intake Air exit 5mm Before you install the hob, make sure that Tthe work surface is square and level, and no structural members interfere • with space requirements. The work surface is made of a heat-resistant material. •...
- Page 17 When you have installed the hob, make sure that The power supply cable is not accessible through cupboard doors or drawers. • There is adequate flow of air from outside the cabinetry to the base of the • hob. If the hob is installed above a drawer or cupboard space, a thermal protection •...
- Page 18 Cautions • The hob must be installed by qualified personnel or technicians. We have professionals at your service. Please never conduct the operation by yourself. • The hob shall not be mounted to cooling equipment, dishwashers and rotary dryers. • The hob shall be installed such that better heat radiation can be ensured to enhance its reliability.
- Page 19 PRODUCT FICHE Symbol Value Unit Model WCH60D Type of hob Electric hobs Number of cooking zones 4 zones or areas Heating technology (induction cooking zones and cooking areas, radiant Induction cooking cooking zones, solid plates) For circular cooking zones or area: diameter of useful Left Up: 15.5...
-
Page 21: Product Disposal
0330 0564 777 support@willowappliances.co.uk General Enquiries 0330 0564 777 sales@willowappliances.co.uk Willow Appliances Limited Willow is a UK household electrical Registered in England & Wales, Company number 12117113 appliance company, based in Staffordshire. Unit 7 Wellington Crescent, Fradley Park, Lichfield, Staffordshire, WS13 8RZ... -
Page 22: Product Support
‘Troubleshooting’ section of this user manual. Your Willow product is guaranteed against faults and breakdowns for 24 months. If you need assistance within the first 28 days of your purchase, please contact the retailer supplier. -
Page 23: Year Warranty
The warranty will be rendered invalid if the product is re-sold or has been damaged by inexpert repair. Willow disclaim any liability for loss or damage arising from the breakdown of a product. Specifications are subject to change without notice. - Page 24 WCH60D CERAMIC HOB...
