- Page 1 INSTALLATION AND OPERATING INSTRUCTIONS WCH77T CERAMIC HOB Please read before attempting to install or use this appliance. It is recommended that you keep this user manual in a safe place.
- Page 2 WELCOME Thank you for choosing Willow for your new appliance. Your item is pre-registered and your warranty starts from the point of purchase: all you need to do is keep hold of your proof of purchase. We are proud to provide a range of appliances that have been designed with the consumer in mind.
- Page 3 Installation Electrical Shock Hazard Disconnect the appliance from the mains electricity supply before carrying • out any work or maintenance on it. Connection to a good earth wiring system is essential and mandatory. • Means for disconnection must be incorporated in the fixed wiring in •...
- Page 4 The use of inappropriate guards can cause accidents. Failure to install the appliance correctly could invalidate any warranty or • liability claims. Regarding the details of installation, thanks to refer to the section • <Installation>. Operation and maintenance Electrical Shock Hazard Do not cook on a broken or cracked cooktop.
- Page 5 of children. Failure to use caution could result in injury or cuts. • Important safety instructions Never leave the appliance unattended when in use. Boilover causes smoking • and greasy spillovers that may ignite. Never use your appliance as a work or storage surface. •...
- Page 6 If the supply cord is damaged, it must be replaced by the manufacturer, its • service agent or similarly qualified persons in order to avoid a hazard. This appliance is intended to be used in a domestic household environment • only! Commercial use of any kind is not covered under the manufacturer's warranty! WARNING: The appliance and its accessible parts become hot during use.
-
Page 7: On/Off Switch
Congratulations on the purchase of your new hob. We recommend that you spend some time to read this Instruction / Installation Manual in order to fully understand how to install correctly and operate it. Read all the safety instructions carefully before use and keep this Instruction / Installation Manual for future reference. - Page 8 The ceramic hob can meet different kinds of cuisine demands because of resistance wire heating, micro-computerized control and multi-power selection, really the optimal choice for modern families. The hob centers on customers and adopts personalized design. The hob has safe and reliable performances, making your life comfortable and enabling to fully enjoy the pleasure from life.
- Page 9 Always lift pans off the ceramic hob – do not slide, or they may scratch the glass. Using your Hob To start cooking After power on, the buzzer beeps once, all the indicators light up for 1 • second then go out, indicating that the hob has entered the state of standby mode.
- Page 10 Turn the cooking zone off by scrolling down to”0”. Make sure the display shows”0”. Turn the whole cooktop off by touching the ON/OFF control. Beware of hot surfaces “H” will show which means cooking zone is too hot to touch. It will disappear when the surface has cooled down to a safe temperature.
- Page 11 To cancel the outer zone, press the dual zone key to turn off the second heating circuit, then select the desired power level by touching the “slider” control. Using the Keep Warm function Activate the Keep Warm function 1. Select the zone with the keep warm function (front left zone). 2.
- Page 12 All the zone displays show “||” 2. Touch the pause control one more time, and all the heating zones revert to their original settings. This function is available when one or more heating zones are working. If you don’t cancel the pause control within 30 minutes, the induction hob will automatically switch off.
- Page 13 When the hob has been operating for some time, there will be some residual heat. The letter “H” appears to warn you to keep away from it. Auto Shutdown Safety feature of the hob is auto shut down. This occurs whenever you forget to switch off a cooking zone.
- Page 14 5. Set the time by touching the “slider” control (e.g.9), now the timer you set is 95 minutes. 6. When the time is set, it will begin to count down immediately. The display will show the remaining time. 7. Buzzer will bips for 30 seconds and the timer indicator shows “- - “...
- Page 15 5. Set the time by touching the “slider” control (e.g.9), now the timer you set is 95 minutes. 6. When the time is set, it will begin to count down immediately. The display will show the remaining time. Note: There will be a red dot in the right bottom corner of power level indication which indicating that zone is selected.
- Page 16 Note: Touch the heating zone selection control, the corresponding timer will be shown in the timer indicator. Cancelled the timer 1. Touching the heating zone selection control that you want to cancel the timer. 2. Touching the timer control, the indicator will flash. 3.
-
Page 17: For Stir-Frying
sauces below boiling point. Some tasks, including cooking rice by the absorption method, may require a • setting higher than the lowest setting to ensure the food is cooked properly in the time recommended. Searing steak To cook juicy flavoursome steaks: 1. - Page 18 • sauteing 7 - 8 • cooking pasta • stir-frying • searing • bringing soup to the boil • boiling water Care and Cleaning What? How? Important! Everyday soiling 1. Switch the power to the • When the power to the on glass cooktop off.
- Page 19 Boilovers, melts, Remove these immediately • Remove stains left by with a fish slice, palette melts and hot sugary spills knife or razor blade scraper sugary food or spillovers suitable for ceramic glass as soon the glass cooktops, but beware of as possible.
- Page 20 Unsuitable, abrasive ‘Choosing the right scourer or cookware’. Cleaning products being used. See ‘Care and cleaning’. Technical Specification Ceramic Hob WCH77T Cooking Zones 5 Zones Supply Voltage 220-240V~ Installed Electric Power 8200W Product Size D×W×H(mm) 770x520x50 Building-in Dimensions A×B (mm) 740x490 Weight and Dimensions are approximate.
- Page 21 H(mm) D(mm) A(mm) B(mm) X(mm) WCH77T mini Under any circumstances, make sure the hob is well ventilated and the air inlet and outlet are not blocked. Ensure the hob is in good work state. As shown below. Note: The safety distance between the hotplate and the cupboard above the...
- Page 22 A(mm) B(mm) C(mm) 50 mini 20 mini Air intake Air exit 5mm Before you install the hob, make sure that The work surface is square and level, and no structural members interfere • with space requirements. The work surface is made of a heat-resistant material. •...
- Page 23 If the hob is installed above a drawer or cupboard space, a thermal protection • barrier is installed below the base of the hob. The isolating switch is easily accessible by the customer. • Before locating the fixing brackets The unit should be placed on a stable, smooth surface (use the packaging). Do not apply force onto the controls protruding from the hob.
- Page 24 • The hob shall be installed such that better heat radiation can be ensured to enhance its reliability. • The wall and induced heating zone above the work surface shall withstand heat. • To avoid any damage, the sandwich layer and adhesive must be resistant to heat.
-
Page 25: Product Fiche
PRODUCT FICHE Symbol Value Unit Model WCH77T Type of hob Electric hobs Number of cooking zones 5 zones or areas Heating technology (induction cooking zones Radiant cooking and cooking areas, radiant cooking zones, solid plates) For circular cooking zones Left down:15.5 or area: diameter of useful Left up:19.0... -
Page 26: Product Disposal
0330 0564 777 support@willowappliances.co.uk General Enquiries 0330 0564 777 sales@willowappliances.co.uk Willow Appliances Limited Willow is a UK household electrical Registered in England & Wales, Company number 12117113 appliance company, based in Staffordshire. Unit 7 Wellington Crescent, Fradley Park, Lichfield, Staffordshire, WS13 8RZ... -
Page 27: Product Support
‘Troubleshooting’ section of this user manual. Your Willow product is guaranteed against faults and breakdowns for 24 months. If you need assistance within the first 28 days of your purchase, please contact the retailer supplier. -
Page 28: Year Warranty
The warranty will be rendered invalid if the product is re-sold or has been damaged by inexpert repair. Willow disclaim any liability for loss or damage arising from the breakdown of a product. Specifications are subject to change without notice. - Page 29 WCH77T CERAMIC HOB...
