- Page 1 INSTALLATION AND OPERATING INSTRUCTIONS WCH30T/WCH60T CERAMIC HOB Please read before attempting to install or use this appliance. It is recommended that you keep this user manual in a safe place.
- Page 2 WELCOME Thank you for choosing Willow for your new appliance. Your item is pre-registered and your warranty starts from the point of purchase: all you need to do is keep hold of your proof of purchase. We are proud to provide a range of appliances that have been designed with the consumer in mind.
-
Page 3: Installation
Installation Electrical Shock Hazard • Disconnect the appliance from the mains electricity supply before carrying out any work or maintenance on it. • Connection to a good earth wiring system is essential and mandatory. • Means for disconnection must be incorporated in the fixed wiring in accordance with the wiring rules. - Page 4 in the instructions for use as suitable or hob guards incorporated in the appliance. The use of inappropriate guards can cause accidents. • Failure to install the appliance correctly could invalidate any warranty or liability claims. • Regarding the details of installation, thanks to refer to the section <Installation>.
- Page 5 safety cover is retracted. Use with extreme care and always store safely and out of reach of children. • Failure to use caution could result in injury or cuts. Important safety instructions • Never leave the appliance unattended when in use. Boil over causes smoking and greasy spillovers that may ignite.
- Page 6 • Do not use pans with jagged edges or drag pans across the glass surface as this can scratch the glass. • Do not use scourers or any other harsh abrasive cleaning agents to clean your cook top, as these can scratch the ceramic glass. •...
- Page 7 the possibility of electric shock, for hob surfaces of glass-ceramic or similar material which protect live parts. • A steam cleaner is not to be used. • The appliance is not intended to be operated by means of an external timer or separate remote-control system.
- Page 8 Instruction / Installation Manual for future reference. Product Overview Top View 1. max. 1800 W zone 2. max. 1200 W zone 3. Control panel WCH30T 1. max. 1800 W zone 2. max. 1200 W zone 3. max.1800 W zone 4. max.1200 W zone 5. Control panel...
- Page 9 WCH60T 1. ON/OFF switch 4. Child lock 2. Select power level 5. Select heating zone 3. Setting the timer Product Information The ceramic hob can meet different kinds of cuisine demands because of resistance wire heating, micro-computerized control and multi-power selection, really the optimal choice for modern families.
- Page 10 Do not use cookware with jagged edges or a curved base. Make sure that the base of your pan is smooth, sits flat against the glass, and is the same size as the cooking zone. Always centre your pan on the cooking zone.
- Page 11 2. Place a suitable pan on the cooking zone that you wish to use. Make sure the bottom of the pan and the surface of the cooking zone are clean and dry. 3. Touching the heating zone selection control, and an indicator next to the key will flash 4.
- Page 12 Beware of hot surfaces “H” will show which means cooking zone is too hot to touch. It will disappear when the surface has cooled down to a safe temperature. It can also be used as an energy saving function if you want to heat further pans, use the hotplate that is still hot.
- Page 13 Power level Default working timer (hour) Using the Timer You can use the timer in two different ways: • You can use it as a minute minder. In this case, the timer will not turn any cooking zone off when the set time is up. •...
- Page 14 5. Set the time by touching the “-” or “+” control (e.g.9), now the timer you set is 95 minutes. 6. When the time is set, it will begin to count down immediately. The display will show the remaining time. 7.
- Page 15 5. set the time by touching the ”-“ or ”+” control (e.g.9), now the timer you set is 95 minutes. 6. When the time is set, it will begin to count down immediately. The display will show the remaining time. Note: There will be a red dot in the right bottom corner of power level indication which indicating that zone is selected.
- Page 16 corresponding zone will flash. Note: Touch the heating zone selection control, the corresponding timer will be shown in the timer indicator. Canceled the timer 1. Touching the heating zone selection control that you want to cancel the timer. 2. Touching the timer control, the indicator will flash.
- Page 17 has heated through. Simmering, cooking rice • Simmering occurs below boiling point, at around 85˚C, when bubbles are just rising occasionally to the surface of the cooking liquid. It is the key to delicious soups and tender stews because the flavour develop without overcooking the food.
- Page 18 Heat Settings Heat setting Suitability • delicate warming for small amounts of food 1 - 2 • melting chocolate, butter, and foods that burn quickly • gentle simmering • slow warming • reheating 3 - 4 • rapid simmering • cooking rice •...
- Page 19 Care and Cleaning What? How? Important! Everyday soiling 1. Switch the power to • When the power to on glass the cook top off. the cook top is (fingerprints, 2. Apply a cook top switched off, there will marks, stains cleaner while the be no ‘hot surface’...
- Page 20 Spillovers on the 1. Switch the power to • The cook top may touch controls the cook top off. beep and turn 2. Soak up the spill itself off, and the 3. Wipe the touch touch controls control area with a may not function clean damp sponge while there is...
- Page 21 Supply Voltage 220-240V~ 50/60Hz Installed Electric Power 6000W Product Size D×W×H(mm) 590×520×50 Building-in Dimensions A×B (mm) 560×490 Ceramic Hob WCH30T Cooking Zones 2 Zones Supply Voltage 220-240V~ 50/60Hz Installed Electric Power 2900W Product Size D×W×H(mm) 290×520×50 Building-in Dimensions A×B (mm) 270×490...
- Page 22 B(mm L(mm) X(mm) WCH60T mini WCH30T mini Under any circumstances, make sure the hob is well ventilated and the air inlet and outlet are not blocked. Ensure the hob is in good work state. As shown below. Note: The safety distance between the hotplate and the cupboard...
- Page 23 A(mm) B(mm) C(mm) 50 mini 20 mini Air intake Air exit 5mm Before you install the hob, make sure that • The work surface is square and level, and no structural members interfere with space requirements. • The work surface is made of a heat-resistant material. •...
- Page 24 When you have installed the hob, make sure that • The power supply cable is not accessible through cupboard doors or drawers. • There is adequate flow of air from outside the cabinetry to the base of the hob. • If the hob is installed above a drawer or cupboard space, a thermal protection barrier is installed below the base of the hob.
- Page 25 • The hob must be installed by qualified personnel or technicians. We have professionals at your service. Please never conduct the operation by yourself. • The hob shall not be mounted to cooling equipment, dishwashers and rotary dryers. • The hob shall be installed such that better heat radiation can be ensured to enhance its reliability.
- Page 26 • If the appliance is being connected directly to the mains supply, an omnipotent circuit breaker must be installed with a minimum gap of 3mm between the contacts. • The installer must ensure that the correct electrical connection has been made and that it complies with safety regulations. •...
-
Page 27: Product Fiche
Product fiche Symbol Value Unit Model WCH30T Type of hob Electric hobs Number of cooking zones 2 zones or areas Heating technology (induction cooking zones Radiant cooking and cooking areas, radiant cooking zones, solid plates) For circular cooking zones or area: diameter of useful surface area per electric Up: 19.0... - Page 28 WCH60T...
-
Page 29: Product Disposal
0330 0564 777 support@willowappliances.co.uk General Enquiries 0330 0564 777 sales@willowappliances.co.uk Willow Appliances Limited Willow is a UK household electrical Registered in England & Wales, Company number 12117113 appliance company, based in Staffordshire. Unit 7 Wellington Crescent, Fradley Park, Lichfield, Staffordshire, WS13 8RZ... -
Page 30: Product Support
‘Troubleshooting’ section of this user manual. Your Willow product is guaranteed against faults and breakdowns for 24 months. If you need assistance within the first 28 days of your purchase, please contact the retailer supplier. -
Page 31: Year Warranty
The warranty will be rendered invalid if the product is re-sold or has been damaged by inexpert repair. Willow disclaim any liability for loss or damage arising from the breakdown of a product. Specifications are subject to change without notice. - Page 32 WCH30T/WCH60T CERAMIC HOB...
