- Page 1 Aluminium Installation Guide Products: Lodge, Delta, Alto, Mansion, Axis, Fortress & Balustrade A step-by-step guide to installing your fence...
-
Page 2: Tool List
Introduction Thank you for choosing Fentec Aluminium range. The recommendations detailed in this guide This product will provide you with many years of are formulated along the lines of good building trouble free protection if installed in accordance practice. They are not intended to be an with the directions outlined in this document. - Page 3 Suggested Hole Diameter (mm) (mm) Length Height 125x125 3 Rail 1.1-1.2 0.6-0.7 150x150 2 Rail 0.95-1.05 0.45-0.55 150x150 2 Rail High 1.1-1.2 0.6-0.7 200x200 1 Rail 0.65-0.7 0.5-0.55 Gate posts are usually 0.3m longer/0.3m deeper in-ground. fentec.co.nz | 0800 002 725...
- Page 4 Post sizes & fixings are dependent on the application & design 125.0mm requirements. Fixings - indicative In concrete: 4x M12 HILTI HST stud anchors or similar with 125.0mm minimum 70mm embedment. Flange 125x125 In timber: 4x 12mm coachscrews with minimum 120mm embedment. 125.0mm fentec.co.nz | 0800 002 725...
- Page 5 All persons using power equipment must be trained & certified to use the equipment & must wear all applicable personal protection gear. Terranota Ltd cannot accept any responsibility for any faulty installation or damage or injury arising from installation work. fentec.co.nz | 0800 002 725...
