- Page 1 GATES & FENCES VISTAWALL INSTALLATION GUIDE - SLAT A STEP-BY-STEP GUIDE TO INSTALLING YOUR FENCE...
-
Page 2: Tools List
INTRODUCTION Thank you for choosing The recommendations detailed If you have any questions, Fentec Aluminium range. in this guide are formulated please contact our Technical This product will provide along the lines of good building Team on 0800 002 725. We are you with many years of practice. -
Page 3: Components List
Plastic knock in cap Channel ends caps, left & right Conversion kit components Aluminium post cap To change the orientation of your fence 100 X 16 x 1780mm Slat 30 X 30 Slat channel Tek screws 0800 002 725 fentec.co.nz... - Page 4 10mm either side of the channel] and you are using 65x65mm posts, then you will have an 1865mm post centre to post centre This also shows the in-between measurements, should you be fitting your slat between posts other than a 65x65mm profile, i.e, timber posts or concrete blocks 0800 002 725 fentec.co.nz...
- Page 5 If the fenceline follows any contours in the land or the fenceline is curved, regularly check the height of the posts as you work down the line to ensure a good visual line along the top of the fence. 0800 002 725 fentec.co.nz...
- Page 6 70mm embedment. In timber: 4 x 12mm coachscrews with min 120mm 125.0mm embedment. Flange 125x125x5 125.0mm 4 . 2 Fix the posts in place with four fixings of the correct type for the situation. 0800 002 725 fentec.co.nz...
- Page 7 To ensure your fence aesthetically looks correct, make sure the ‘screw port side’ is all facing the same direction (generally on the inside of your property looks best). Attach slat channel to post by screwing through the slat cavity 0800 002 725 fentec.co.nz...
- Page 8 One screw per slat is all that is required Important: We do not recommend the slats be fitted with less than 5mm gaps between each slat. This may cause capillary action and cause corrosion to the slat system. 0800 002 725 fentec.co.nz...
- Page 9 Important: It is important that the object you use to tap the cover clip in with won’t damage the powder coating. Do not use the metal part of your hammer, this will cause scratches or dents. 0800 002 725 fentec.co.nz...
- Page 10 STEP-BY-STEP GUIDE VERTICAL CONVERSION GUIDE How to Convert the orientation of your VistaWall Slat fence Fitting bottom slat Post Depending on the total width of the bay, the maximum post width face to face is 1800mm. Lay the additional slat horizontal and screw fix on either end.
-
Page 11: Frequently Asked Questions
All persons using power equipment must be trained and certified to use the equipment and must wear all applicable personal protection gear. Fentec cannot accept any responsibility for any faulty installation or damage or injury arising from installation work. - Page 12 0800 002 725 fentec.co.nz...
