- Page 1 X-MAX ROBOTIC CLEANER WITH WET MOPPING FUNCTION VACUUMS MOBILE PROFI LASER EL. CONTROLLED MOPS APPLICATION EQUIPMENT NAVIGATION MOPPING...
-
Page 2: Table Of Contents
Google Play and AppStore under the name "RobZone" Thank you for purchasing the ROBZONE DUORO X-MAX robotic vacuum cleaner Please read the chapter "rules for safe use" in detail before use, in order to use the robot vacuum cleaner safely. -
Page 3: Safe Use Rules
Safe use rules Before using the robot vacuum cleaner, please read the safe use rules thorou- ghly and follow all normal safety rules to reduce the risk of damage to the robot vacuum cleaner or in case of injury to yourself. Keep this manual. -
Page 4: Top Features And Functions
Publication, uploading, copying or translation into other languages of this manual and similar or related materials is only possible with the written permission of the manufacturer and the dealer Robzone Europe. Protected by copyright. We have made every effort to ensure that this manual is an accurate and good guide for the operation of your robotic vacuum cleaner. -
Page 5: Package Content
+ Aquamax mop (part of Profi case) Main fine filter Network adapter + secondary filter Package content may vary slightly from model to model. Instructions are always included in each package. The relevant listing is given for the specific model at www.robzone.com... -
Page 6: Cleaner Description
Cleaner description Cleaner body Laser Main control Waste lidar button container Waste container and water tank Bumper Main Anti-impact switch strip WiFi light/ button Suction head ACTIVE BRUSH with rotary brush Rotary brush Cover grid Airmax of the rotary brush Cleaner bottom Left wheel Left side brush... -
Page 7: Main Control Button
Aquamax combined mopping module Waste container Dust bin Filtration Water tank Charging base Indicator light Charging surfaces Main control button The indicator light flashes white Wi-Fi button = I activate the system The light is blue The indicator light flashes red = Wi-Fi connected = a problem occurred The indicator light flashes... - Page 8 Remark: It is possible that Duoro X-Max will move to another room before it has finished cleaning the first room. This is due to the layout of the rooms. Don't worry, before it completes the task, it will return to clean up the areas it missed.
- Page 9 3. Install the Homevac cleaning station or charging base. 4. Activate the robot. 5. Download the Robzone app to your smartphone and pair the robot with the app. 6. Place the robot on the charging base and let it charge (for the first charge, at least 5 hours).
-
Page 10: Start Cleaning
To load the map correctly Remove from the floor open all doors. smaller objects. A robotic vacuum cleaner is not perfect and needs to get to know its new surroundings first in order to serve you reliably for a long time. Don't be fooled by the seemingly illogical movement, but a robot cleans differently than a human. -
Page 11: Cleaning Modes
End of cleaning If there is a charging base in the cleaning area, the robot will automatically locate it, park itself and start rechar- ging the battery when it has finished cleaning. If the battery capacity is not enough to clean the entire area, the robot will automatically resume cleaning where it left off until it is finished. -
Page 12: Extra Cleaning Programs
Quick – smart cleaning The robot first uses a laser sensor to map the apartment space and select the most suitable cleaning route. During this program, the robot cleans systematically by constantly evaluating the surrounding environment. It doesn't miss a spot. Before finishing the cleaning, the robot thoroughly scans the entire area around the walls. Once it has covered the entire area, it stops cleaning. - Page 13 Boost Effect The robot detects more soiled carpet and automatically increases power for a thorough cleaning. Mode activation In the mobile app, you can choose to repeat Mobile app Cleaning -> Boost effect the cleaning mode 1x - 2x - 3x for each cleaning and thus increase the quality of cleaning.
-
Page 14: Mopping
Mopping The DUORO X-MAX robotic vacuum cleaner is equipped with a combined mopping module for mop attachment, including an electronically controlled water tank. Thanks to the revolutionary wet cleaning solution, you can simply set any intensity in the mobile app of mop wetting according to the type or soiling of the floor. - Page 15 Never vacuum liquids, the robot is designed for wet mopping but never for wet vacuuming! Wetting intensity setting In the Robzone mobile app, you can conveniently set the intensity of the floor wetting according to its type...
-
Page 16: Mobile Application
To use the mobile app, first install the app on your mobile device (phone, tablet) and pair the app with the robot. 1. Download the "ROBZONE" app from Google Play or the AppStore. 2. Sign up for the app. 3. Enter the details of your home Wifi to which the robot will be connected when cleaning. -
Page 17: Scheduled Cleaning
Loading the map into the app for the first time The robotic vacuum cleaner scans the entire space during the first cleaning and then divides it into rooms. The division may not be 100% correct, so it is possible to make detailed adjustments to the rooms in the app exactly according to reality. -
Page 18: Charging Base
For maximum battery life, follow the recommendations for regular use of the robot, even if there is a long interruption in use (e.g. going on holiday). It is recommended to keep the charging base active at all times, connected to the mains. The robot vacuum cleaner should be parked in the charging base in between the regular cleaning phases. -
Page 19: Battery Status
Battery status The battery status light on the main control button informs you of the battery status or you can find the current status on the in the mobile app. Charging states The indicator light flashes WHITE robot is charging The indicator lights WHITE robot is charged The indicator light flashes RED slowly battery is low, the robot will search for a charging base to recharge. -
Page 20: Regular Maintenance
Sensors Equipped with sensitive sensors and precise laser navigation, the robotic vacuum cleaner has perfect orienta- tion in space and excellent visibility of obstacles. • Anti-fall IR sensors Thanks to them, the robot will never fall down the stairs. Magnetic floor sensors These make the robot react to the magnetic tape and avoid forbidden areas. -
Page 21: Waste Container
Waste container A) Press the latch to slide the waste container out of the robot. B) Press the latch to open the waste container and empty the collected dirt. C) Remove the filter set (fine filter + Hepa filter + Nano Air filter/if installed + secondary filter) and clean them with a dust brush. - Page 22 Cleaning of suction head ACTIVE BRUSH Remove the protective grille of the suction head. To release the grille, pre- ss the two latches towards the body of the head and then pull the latches out of the safety locks with a light tug. Remove the brush part and clean both the brush and its cover using a cloth or brush.
- Page 23 Distributor: RobZone Europe, s.r.o. Průmyslová 11472/11 102 00 Praha 10 Czech Republic Made in China Li - Ion...
