ROOMS TO GO 79911 Series Assembly Instruction

Dual power loveseat with console
Hide thumbs
1
2
3
4
5

Advertisement

Table of Contents

Manufactured for Rooms To Go
NO.
Description
Backrest
A
(LSF, RSF)
B
Seat
Console
C
backrest
Wall plug
D
transformer
ASSEMBLY INSTRUCTION
(Version 1, updated Oct. 2024)
DUAL POWER LOVESEAT WITH CONSOLE
HLVN 79911 / 79912
LIST OF PARTS
Item
Quantity
2
1
1
1
HLVN
SKU:
79911-54HP
11179137
79912-54HP
11179125

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 79911 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ROOMS TO GO 79911 Series

Summary of Contents for ROOMS TO GO 79911 Series

  • Page 1 ASSEMBLY INSTRUCTION (Version 1, updated Oct. 2024) DUAL POWER LOVESEAT WITH CONSOLE HLVN 79911 / 79912 Manufactured for Rooms To Go HLVN SKU: 79911-54HP 11179137 79912-54HP 11179125 LIST OF PARTS Description Item Quantity Backrest (LSF, RSF) Seat Console backrest Wall plug...

  • Page 2: Power Connection

    ASSEMBLY INSTRUCTIONS Step 1: Take out carefully the back cushions from the packing and console's backrest from inner console frame. Step 2: Positing the female metal receiver brackets over the male metal posts. Push down the female brackets over male posts simultaneously until each side is locked into place an audile "click" is heard. POWER CONNECTION Step 3: Lift velcro flap located at the bottom back.

  • Page 3: Electrical Controls

    Step 4: Connect wall plug transformer to transformer switch. And connect transformer plug to electrical outlet. ELECTRICAL CONTROLS 1 Press button to recline the sofa to desired position 2 Press button to raise the sofa to the upright position. 3 Press button to activate the headrest forward. 4 Press button to return headrest to the closed position.
  • Page 4 WARNINGS * Keep unit at least 9" from wall. * Keep unit at least 24" from all heat sources. * Avoid placing unit in areas where unit can be exposed to direct sunlight other powerful light sources, as fading or discoloration may occur. * Do not reach under seat when mechanism is operating or serious injury may occur.

  • Page 5: Care And Cleaning

    CARE AND CLEANING * Upholstered furniture is packaged tightly to protect it during transsit. This packaging can sometimes cause creases or misshaped cushions when the furniture comes out of the packaging. These issues will correct themselves over time as the fibers of the cushions are exposed to air. However, shaping the cushions with your hands can alleviate the creases and compressed fibers more quickly.

This manual is also suitable for:

79912 series79911-54hp79912-54hp1117913711179125
