Federal Signal Corporation FT350A-A Manual

Federal Signal Corporation FT350A-A Manual

Watertight ringdown telephone, analog
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

Watertight Ringdown Telephone
FT350A-A Analog
25500986 Rev A0 0225
Limited Warranty: This product's limited warranty can be found at www.fedsig.com/SSG-Warranty.
SAFETY MESSAGES TO INSTALLERS AND USERS
The equipment is not intended for repair by the user. Repair of this equipment shall be carried out by the manufacturer
or manufacturer's authorised agent.
It is the responsibility of the end user to take suitable precautions to prevent exposure to aggressive chemicals that
may attack metals or the polymeric materials used in the construction of this equipment. Specific details of vulnerable
materials shall be provided in the instructions.
•
Read and understand instructions before installing or operating equipment.
•
Do not install this device near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
•
Only use attachments and accessories specified by the manufacturer.
•
Refer all servicing to qualified service personnel.
•
Prior to installation, consult local building and electrical code requirements.
•
WARNING: ELECTRICAL HAZARD — This product should be installed by a licensed electrician accoring to all
electrical and building codes.
•
WARNING: DISLOCATION HAZARD — To prevent injury, this apparatus must be attached securely to the floor/wall
in accordance with the installation instructions.
Failure to follow all safety precautions and instructions may result in property damage, serious injury, or death to you or
others.
:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FT350A-A and is the answer not in the manual?

Questions and answers

Related Manuals for Federal Signal Corporation FT350A-A

Summary of Contents for Federal Signal Corporation FT350A-A

  • Page 1 Watertight Ringdown Telephone FT350A-A Analog 25500986 Rev A0 0225 Limited Warranty: This product’s limited warranty can be found at www.fedsig.com/SSG-Warranty. SAFETY MESSAGES TO INSTALLERS AND USERS The equipment is not intended for repair by the user. Repair of this equipment shall be carried out by the manufacturer or manufacturer’s authorised agent.
  • Page 2 Package Contents • FT350A-A Telephone Model • FT350A-A Weatherproof 4X telephone with armored handset cord Options • P006461 Locking door kit Accessories • P7225 Weatherproof ring detect relay (external to telephone) • P7232 Weatherproof off-hook detect relay (external to telephone) •...
  • Page 3 Watertight Enclosure CSA Type 4X, IP66 Overview Federal Signal’s FT350A-A telephone offers maximum efficiency under extreme environmental conditions. The sturdy Thermoplastic Resin enclosure protects the internal circuitry against windblown dust and rain, corrosion, splashing and high-pressure water. The telephone is approved with a CSA Type 4X rating, making it the ideal telephone for use in wet or corrosive atmospheres such as chemical plants or offshore platforms.

  • Page 4: Installation

    Figure 1 Typical Features Magnetic Reed Hook Switch Faceplate - 14-Guage Steel, Satin Coat Primed and Powder Coated Heavy Duty Handset with Volume Control Handset Retainers 22" Armored Handset Cord Thermoplastic Resin Enclosure Installation NOTES: • Follow all appropriate electrical codes and use only approved electrical fittings for the installation. •...
  • Page 5 To install the telephone: Separate the faceplate from the housing by removing the two temporary, factory-installed screws and unplugging the wiring harness from the faceplate. Drill or punch holes at dimples for conduit or glands. Use the template provided to locate and drill holes for mounting screws. Secure the unit to the wall.

  • Page 6: Operation

    Operation The FT350A-A ringdown phone is designed for automatic calling simply by removing the handset from the cradle. Field Repairs Field repairs may be carried out only by qualified technicians using OEM parts. Substitution of parts voids the warranty and may pose a hazard to users of the equipment.

  • Page 7: Maintenance And Service

    Storage General Storage (All situations): • Note any stacking limits or warnings on packaging (if any). • Do not store in temperatures over +80C°. • Store in original packaging if possible until needed. Long Term Storage (> 6 Months): • If the area is air-conditioned and not subject to high changes in humidity, continue to store in original packaging.
  • Page 8 2645 Federal Signal Drive, University Park, Illinois 60484 Additional translations available at signaling.fedsig.com Traducciones adicionales disponibles en signaling.fedsig.com Customer Support 1-800-344-4634+1-708-534-4756, iordersup@fedsig.com Technical Support 1-800-755-7621+1-708-587-3587, signalsupport@fedsig.com signaling.fedsig.com © 2025 Federal Signal Corporation. All rights reserved worldwide. All trademarks are property of their respective owners.
