- Page 1 OUTDOORS DELIGHTS NOVECENTO GRILL OWNERS GUIDE Do not discard. Contains important information about your product.
- Page 2 TROMEN® hereby warrants to the ORIGINAL PURCHASER of manufacturing problems; Otherwise, all expenses incurred will be this TROMEN® charcoal grill that it will be free from defects in paid by the user. both materials and workmanship, provided it is assembled and...
- Page 3 FAILURE TO OBSERVE DANGERS, WARNINGS AND CAUTIONS CONTAINED IN THIS OWNER'S MANUAL MAY RESULT IN SERIOUS BODILY INJURY OR DEATH, FIRE OR FIRE CAUSING DAMAGE ) will alert you about important information. The SAFETY SYMBOLS Please read all safety information in this Owner's Guide before lighting the grill. Do not use it inside the house! This Fogon should only be used outdoors.
-
Page 4: Security Notes
Do not proceed to save the stove until the ashes and coals are completely extinguished. Using abrasive cleaners on the cooking grates or the grill itself will damage the finish of the surfaces. The Fire Pit needs to be clean regularly. SAFETY TIPS FOR HANDLING FOOD Wash your hands well with hot, soapy water before starting to prepare any dish and after handling fresh meat, poultry, or fish. -
Page 5: Product Setup
PRODUCT SETUP STEP 1 Locate the side faces then with the TROMEN key fix the sides to start assembling the equipment STEP 2 Continue linking sides to form the hexagon; Remember to bolt the legs at an equidistant distance of (120°) - Page 6 STEP 3 Attach the grill support and the Plancheta using the screws found in the installation kit STEP 4 Repeat the same procedure but now with the grill. STEP 5 Position the griddle and the grill on the sides of the stove...
- Page 7 STEP 6 Place the base inside de stove STEP 7 Fix the cross with the screws provided in the installation kit. STEP 8 Adjust the screw to avoid the pivot of the cross (use the Tromen key)
- Page 8 NOTE: The Novecento Grill is designed to be used at two different heights. If you want to change the size you must bolt the legs and locate them in the following diameter...
-
Page 9: Exploded View
(rain, dust, etc.) WWW.TROMEN.NZ serviciotecnico@tromen.com DENOMINATION QUANTITY CHECK CNJ CROSS SIDE PANEL WITH HANDLE SIDE PANEL BASE LEGS GRILL AND GRIDDLE SUPPORT CNJ CROSS SUPPORT ENAMELDED GRILL ENAMELDED GRIDDLE 5/16 HEXAGON BOLT 5/16 FLAT WASHER TROMEN KEY CHECK DONE BY:...
