Dell Pro 14 Plus Portable Monitor
P1425
Teardown Instruction
Model: P1425
Regulatory Model: P1425f
February 2025
Rev. A00
Regulatory information
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pro 14 Plus and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dell Pro 14 Plus

Summary of Contents for Dell Pro 14 Plus

  • Page 1 Dell Pro 14 Plus Portable Monitor P1425 Teardown Instruction Model: P1425 Regulatory Model: P1425f February 2025 Regulatory information Rev. A00...

  • Page 2: Notes, Cautions, And Warnings

    A WARNING indicates a potential for property damage, personal injury, or death. © 2025 Dell Inc. or its subsidiaries. All rights reserved. Dell Technologies, Dell, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other trademarks may be trademarks of their respective owners.

  • Page 3: Table Of Contents

    Installing the hinge ............................... 20 Power button ..................................22 Removing the power button ............................22 Installing the power button ............................23 Function button ................................. 24 Removing the function button ............................. 24 Installing the function button ............................25 Contacting Dell........................26 Chapter 3: Contents...

  • Page 4: Chapter 1: Safety Instructions

    Safety Instructions Use the following safety guidelines to protect your monitor from potential damage and to ensure your personal safety. Unless otherwise noted, each procedure included in this document assumes that you have read the safety information that shipped with your monitor. NOTE: Before using the monitor, read the safety information that is shipped with your monitor and printed on the product.

  • Page 5: Before Working Inside Your Monitor

    Before working inside your monitor Steps Save and close all open files and exit all open applications. Turn off your monitor. Disconnect your monitor and all attached devices from their electrical outlets. Disconnect all attached network devices and peripherals, such as keyboard, mouse, and dock from your monitor. CAUTION: To disconnect a network cable, first unplug the cable from your monitor and then unplug the cable from the network device.

  • Page 6: Disassembly And Reassembly

    Disassembly and reassembly NOTE: The images in this document may differ from your computer depending on the configuration you ordered. Recommended tools Phillips screwdriver #00  Screw list NOTE: When removing screws from a component, it is recommended to note the screw type, the quantity of screws, and then place them in a screw storage box.

  • Page 7: Sleeve

    Sleeve Removing the sleeve Prerequisites Follow the procedure in Before working inside your monitor. Steps Pull the monitor out from the sleeve. Figure 1. Removing the sleeve Installing the sleeve Steps Replace the monitor to the sleeve. Figure 2. Installing the sleeve Next steps Follow the procedure in After working inside your...

  • Page 8: Bottom Base Cover

    Bottom base cover Removing the bottom base cover Prerequisites Follow the procedure in Before working inside your monitor. Remove the sleeve. Steps Remove the six rubbers on the bottom base cover. Remove the six screws (M2x4) that secure the bottom base cover. Lift the bottom cover up from the monitor.
  • Page 9 Figure 4. Removing the bottom base cover Disassembly and reassembly...

  • Page 10: Installing The Bottom Base Cover

    Installing the bottom base cover Steps 1. Replace the six screws (M2x4) to secure the bottom base cover. 2. Adhere the six rubbers on the bottom base cover to cover the screws. Figure 5. Installing the bottom base cover Next steps Install the sleeve.

  • Page 11: Main Board

    Main board Removing the main board Prerequisites Follow the procedure in Before working inside your monitor. Remove the sleeve. Remove the bottom base cover. Steps Remove the five screws (M1.6x2.5) that secure the main board. Pull the main board up and flip it over to make the connector visible. Disconnect the auto-rotation sensor cable from the connector on the main board.
  • Page 12 Figure 7. Removing the main board Disassembly and reassembly...

  • Page 13: Installing The Main Board

    Figure 8. Removing the main board Installing the main board Steps Connect the eDP cable to the connector on the main board. Connect the auto-rotation sensor cable to the connector on the main board. Flip the main board over and place it into the top base cover. Replace the five screws (M1.6x2.5) to secure the main board with the top base cover.
  • Page 14 Figure 10. Installing the main board Disassembly and reassembly...
  • Page 15 Next steps Installing the bottom base cover. Install the sleeve. Follow the procedure in After working inside your monitor. Disassembly and reassembly...

  • Page 16: Auto-Rotation Sensor Board

    Auto-rotation sensor board Removing the auto-rotation sensor board Prerequisites Follow the procedure in Before working inside your monitor. Remove the sleeve. Remove the bottom base cover. Remove the main board. Steps Remove the front bezel from the back cover. (Can not rework without new adhesive.) Tilt open the monitor base.

  • Page 17: Installing The Auto-Rotation Sensor Board

    Figure 12. Removing the auto-rotation sensor board Installing the auto-rotation sensor board Steps Connect the auto-rotation sensor cable to the connector on the auto-rotation sensor board. Open the monitor base. Make the auto-rotation sensor cable go through the hole between the back cover and the hinge. Adhere the auto-rotation sensor board on the back cover.
  • Page 18 Figure 14. Installing the auto-rotation sensor board Next steps Install the main board. Install the bottom base cover. Install the sleeve. Follow the procedure in After working inside your monitor. Disassembly and reassembly...

  • Page 19: Hinge

    Hinge Removing the hinge Prerequisites Follow the procedure in Before working inside your monitor. Remove the sleeve. Remove the bottom base cover. Remove the main board. Remove the auto-rotation sensor board. Steps Remove the six screws (M2x3) that secure the hinge to the top base cover. Remove the six screws (M2x3) that secure the hinge to the back cover.

  • Page 20: Installing The Hinge

    Figure 16. Removing the hinge Installing the hinge Steps Place the hinges on the top base cover. Replace the six screws (M2x3) to secure the hinges to the top base cover. Flip the monitor over, replace the six screws (M2x3) to secure the hinges to the back cover. Figure 17.
  • Page 21 Figure 18. Installing the hinge Next steps Install the auto-rotation sensor board. Install the main board. Install the bottom base cover. Install the sleeve. Follow the procedure in After working inside your monitor. Disassembly and reassembly...

  • Page 22: Power Button

    Power button Removing the power button Prerequisites Follow the procedure in Before working inside your monitor. Remove the sleeve. Remove the bottom base cover. Remove the main board. Remove the auto-rotation sensor board. Remove the hinge. Steps Remove the two screws (M1.6x2.5) that secure the power button to the top base cover. Lift the power button up from the top base cover.

  • Page 23: Installing The Power Button

    Installing the power button Steps Replace the power button on the top base cover. Replace the two screws (M1.6x2.5) to secure the power button to the top base cover. Figure 20. Installing the power button Next steps Install the hinge. Install the auto-rotation sensor board.

  • Page 24: Function Button

    Function button Removing the function button Prerequisites Follow the procedure in Before working inside your monitor. Remove the sleeve. Remove the bottom base cover. Remove the main board. Remove the auto-rotation sensor board. Remove the hinge. Remove the power button. Steps Remove the three screws (M1.6x2.5) that secure the function button to the top base cover.

  • Page 25: Installing The Function Button

    Installing the function button Steps Replace the function button on the top base cover. Replace the three screws (M1.6x2.5) to secure the function button to the top base cover. Figure 22. Installing the function button Next steps Installing the power button.

  • Page 26: Chapter 3: Contacting Dell

    Contacting Dell To contact Dell for sales, technical support, or customer service issues, see www.dell.com/contactdell. NOTE: Availability varies by country and product, and some services may not be available in your country. NOTE: If you do not have an active internet connection, you can find contact information about your purchase invoice, packing slip, bill, or Dell product catalog.
