Summary of Contents for Candy CSD49TWM5/1-80
-
Page 3: Table Of Contents
Thank you for choosing this product. WEEE contains both polluting substances (which We are proud to offer the ideal product for can cause negative consequences for the you and the best complete range of home environment) and basic components (which can appliances for your daily routine. -
Page 4: General Safety Rules
1. GENERAL SAFETY in a safe way and understand the hazards involved. RULES Children shall not play with the This appliance is intended to appliance. Cleaning and user be used in household and maintenance shall not be made similar applications such as: by children without supervision. - Page 5 Do not expose the washing Electrical connections machine to rain, direct sunlight safety instructions or other weather elements. Protect from possible freezing. The technical details (supply voltage and power input) are indicated on the product rating When moving, do not lift the ...
-
Page 6: Installation
2. INSTALLATION Remove the 2 or 4 transportation screws (A) on the back and remove the 2 or 4 flat washers, rubber bungs and plastic spacer tubes (B) as illustrated in figure 1. If the washing machine is built- ... - Page 7 Instructions for mounting the furniture door Position the template onto the reverse of the furniture door. It is possible to mount the hinges and closure magnet on the right or left-hand side depending on your requirements. Mark the screw hole positions, then drill out these positions.
- Page 8 Mount the furniture door to the front of the washer using the hinges. Fix the spacers (I) in place with the 2 screws (J) and then fix the hinges with 2 screw (H). We suggest mounting the furniture door so that it opens towards the left, which is the same direction as the porthole door.
-
Page 9: Hydraulic Connections
Hydraulic connections Connect the water hose to the water supply tap (fig. 3) only using the hose supplied with the appliance (do reuse old hose-sets). SOME MODELS may include one or more of the following features: HOT&COLD (fig. 4): ... - Page 10 Setting The washing machine should be installed in its final position such that the water fill hose is not kinked or trapped. The corrugated drain hose should be inserted into suitable drain pipe of between 50 cm and 85 cm height above the floor using the curved drain hose support.
-
Page 11: Detergent Drawer
3. DETERGENT DRAWER detergent draw split into compartments as illustrated in figure 9: compartment "1": for prewash detergent; compartment “ ”: for special additives, softeners, starch fragrances, etc.; WARNING: only use liquid products; the washing machine is set to automatically dose additives at each cycle during the last rinse. -
Page 12: Practical Hints
4. PRACTICAL HINTS Maximise the load size Achieve the best use of energy, water, Load tips detergent time using recommended maximum load size. When sorting laundry, make sure: Save up to 50% energy by washing a full load instead of 2 half loads. - have eliminated metallic objects such as hair clips, pins, coins, from laundry;... - Page 13 The use of ecological detergents without When washing heavily soiled whites, phosphates cause following we recommend using cotton programs of effects: 60°C or above and a normal washing powder (heavy duty) that contains - cloudier rinse drain water: This effect is bleaching agents that at medium/high tied to the suspended zeolites which do temperatures provide excellent results.
-
Page 14: Cleaning And Maintenance
5. CLEANING AND Remove and clean the filter; when finished, replace it turning it clockwise. MAINTENANCE The filter handle will be locked when it is not possible to turn any further and the Looking after your appliance correctly can handle is horizontal. -
Page 15: Quick User Guide
6. QUICK USER GUIDE 7. CONTROLS AND PROGRAMS This appliance automatically adjusts the level of the water to the type and quantity of washing. This system gives a reduction in energy consumption and a saving in washing times. Program selection ... -
Page 16: Start/Pause Button
START/PAUSE button WARNING: Don’t touch the display while inserting Close the door BEFORE selecting the plug because machines button START/PAUSE. calibrates the systems during the first seconds: touching the display, the machine couldn’t work property. In Press to start the selected cycle. ... -
Page 17: Options Button
To delay the start use the following - EXTRA RINSE procedure: This option allows you to add one rinse at - Select the required programme. the end of the washing cycle and is useful - Press the delay start button once to for people with delicate and sensitive activate it (h00 appears on the display) skin, for which a small amount of... - Page 18 Pressing the SMART DOSE button you SMART DOSE button (AUTODOSE will be able to set the autodose function, SYSTEM) according to your needs. SOME MODELS are provided with the If you want to change the factory settings, automatic dosage, that carries out a precise press SMART DOSE button.
-
Page 19: Temperature Selection
The default setting for the water To prevent damage to the fabrics, it is hardness is set in the factory at level 2 not possible to increase the speed (HL2) this satisfies over the maximum allowed for the requirements of the majority of users. programme. -
Page 20: Digital Display
Wait until the DOOR LOCKED light has KEY LOCK gone out before opening the door. Pressing simultaneously buttons 2) SPIN SPEED TEMPERATURE SELECTION and SPIN SELECTION for about 3 seconds, the The indicator lights show the spin speed of machine allows you to lock the keys. - Page 21 8) NIGHT & DAY INDICATOR LIGHT - adjusts the rhythm of drum rotation for the type of fabric being washed; The indicator light shows the selection of the relevant option. - recognizes the presence of lather, increasing, if necessary, the amount of 9) Kg Check (function active only on water during rinsing;...
- Page 22 Table of programmes (MAX.) PROGRAMME (see control panel) (MAX.) Drum Clean Cottons 90° ECO 40-60 60° Jeans 40° Wool/Hand Wash 30° Synthetics 60° Rinse Drain + Spin Delicates 59' 40° Sport Plus 39' 30° Hygiene Plus 59' 60° 30° 30° Rapid 40°...
- Page 23 Please read these notes: INFORMATION FOR THE TEST Maximum load capacity of dry clothes, LABORATORIES according to the model used (see control panel). STANDARD PROGRAMMES ACCORDING TO Only with PREWASH option (EU) No 1015/2010 e No 1061/2010 selected (programmes with PREWASH option available).
-
Page 24: Description Of Programmes
the same cycle. This programme is used Description of programmes to assess the compliance with the EU Ecodesign legislation (environmentally To clean different types of fabrics and friendly products design). various levels of dirt, the washing machine has specific programs to meet every need Jeans of washing (see table of programmes). - Page 25 programme washes at a low temperature for Mixed & Coloured 59' 59 minutes. Recommended for small loads. This programme offers you the freedom to wash all kinds of fabrics and non-fading Sport Plus 39' colours together, with a full load, obtaining Created to remove dirt from technical excellent results in only 59 minutes.
-
Page 26: Troubleshooting And Warranty
8. TROUBLESHOOTING AND WARRANTY If you believe the washing machine is not working correctly, consult the quick guide provided below which includes some practical tips on how to fix the most common problems. ERROR CODE FORMAT Models with a display: the error is shown by a number preceded by the letter “E” ... - Page 27 OTHER ANOMALIES Problem Possible causes and practical solutions The washing machine Make sure the product is plugged into a working supply socket. Make sure power is on. does not work / start Make sure the wall socket is working, testing it with another appliance such as a lamp.
- Page 28 Except for the list of spare parts available Warranty on our website, under no circumstances The product is guaranteed under the should you repair or attempt to repair the terms and conditions stated on the appliance yourself or have the appliance certificate included with the product.
- Page 32 - CSD TWME (WM BI AD) -...
