- Page 1 Screen adjustments Essentials Installation Guide 75° SPV306 SpacePole Arc VESA 75/100 Top mount ® -20° 210° Cable is not illustrated to improve images’ clarity. VESA Pivot Adjustability Pivoted +2° Pivoted 0° Pivoted -2° MK15-0337 version 1.0 1/2022...
- Page 2 Tighten screen mount screws Attach screen onto VESA-75 or -100 key holes Alternative Tighten 4 x M4 screws Tighten 1 x M6 screws M4 screw For more mounting options see “SpacePole FixingsGuide” Screens can be pivoted ± 2° - see back page...
