SpacePole Arc SPV1304 Installation Manual

Essentials, vesa 75/100 swing arm screen mount
Hide thumbs
1
2

Advertisement

Quick Links

Download this manual
Screen adjustments
Essentials Installation Guide
310°
SPV1304
SpacePole Arc
VESA 75/100 Swing Arm Screen Mount
®
75°
180°
-20°
Cable is not illustrated to improve images' clarity.
VESA Pivot Adjustability
Pivoted +2°
Pivoted 0°
Pivoted -2°
MK15-0333 version 1.0
1/2022

Advertisement

loading
Need help?

Need help?

Do you have a question about the Arc SPV1304 and is the answer not in the manual?

Questions and answers

Related Manuals for SpacePole Arc SPV1304

Summary of Contents for SpacePole Arc SPV1304

  • Page 1 Screen adjustments Essentials Installation Guide 310° SPV1304 SpacePole Arc VESA 75/100 Swing Arm Screen Mount ® 75° 180° -20° Cable is not illustrated to improve images’ clarity. VESA Pivot Adjustability Pivoted +2° Pivoted 0° Pivoted -2° MK15-0333 version 1.0 1/2022...
  • Page 2 Attach screen onto VESA-75 or -100 key holes Adjust screen height Alternative Tighten 4 x M4 screws Tighten 2 x M6 screws M4 screw For more mounting options see “SpacePole FixingsGuide” Screens can be pivoted ± 2° - see back page...
