Screen adjustments
Essentials Installation Guide
SPV3306
75°
SpacePole Arc
VESA 75/100 Display Screen Mount
®
310°
-20°
Cable is not illustrated to improve images' clarity.
VESA Pivot Adjustability
Pivoted +2°
Pivoted 0°
Pivoted -2°
MK15-0336 version 1.0
1/2022
Advertisement
Related Manuals for SpacePole Arc VESA 75
Summary of Contents for SpacePole Arc VESA 75
- Page 1 Screen adjustments Essentials Installation Guide SPV3306 75° SpacePole Arc VESA 75/100 Display Screen Mount ® 310° -20° Cable is not illustrated to improve images’ clarity. VESA Pivot Adjustability Pivoted +2° Pivoted 0° Pivoted -2° MK15-0336 version 1.0 1/2022...
- Page 2 Attach screen onto VESA-75 or -100 key holes Adjust screen height Alternative Tighten 4 x M4 screws Tighten 2 x M6 screws M4 screw For more mounting options see “SpacePole FixingsGuide” Screens can be pivoted ± 2° - see back page Allen key not included in SPV3306...
