Summary of Contents for Sherman hobby MIG140 FLUX
- Page 1 Machine Translated by Google V1.2 21.08.23 USER MANUAL...
-
Page 2: General Remarks
Machine Translated by Google WARNING! Before installing and starting the device, please read this manual 1. GENERAL REMARKS The device may only be started and operated after carefully reading this Operating Instructions. Due to the continuous technical development of the device, some of its functions may be modified and their operation may differ in detail from the descriptions in the manual. - Page 3 Machine Translated by Google • Use ventilation devices and exhaust systems installed in places with limited air exchange. air, • Blow with fresh air when working in a confined space (tanks), • Use masks and respirators. Burn prevention: • Wear appropriate protective clothing and footwear to protect against radiation burns. arc and splinters, •...
-
Page 4: Technical Parameters
Machine Translated by Google 3. GENERAL DESCRIPTION The MIG 140 FLUX semi-automatic welder is used for manual welding of steel using self-shielded flux-cored wires without the need for protective gases. The device uses synergistic settings and automatically selects the wire feed speed to the set welding voltage. -
Page 5: Connection To The Power Supply
Machine Translated by Google 5. PREPARING THE DEVICE FOR WORK 5.1 CONNECTION TO THE POWER SUPPLY 1. The MIG 140 FLUX device should only be used in a single-phase power supply system, three-wire with grounded neutral point. 2. The MIG 140 FLUX semi-automatic welding machine is designed to work with a 230V 50Hz network. protected by 10 A slow-acting fuses. -
Page 6: Overheating Protection
Machine Translated by Google 5.4 PREPARING THE MIG GUN FOR WORK Depending on the type of material being welded and the diameter of the electrode wire, install the appropriate current tip and wire guide insert into the MIG torch. Electrode wire diameter 0.8 0.9 Contact tip diameter 6. -
Page 7: Preparing The Device For Work
Machine Translated by Google 8. PREPARATION FOR THE WELDING PROCESS 8.1 PREPARING THE DEVICE FOR WORK 1. Make sure the power switch (7) is in the OFF position. 2. Install the spool of self-shielding wire. 3. Securely attach the ground cable clamp to the workpiece being welded. 8.2 SETTING WELDING PARAMETERS 1. -
Page 8: Maintenance Instructions
Machine Translated by Google 10. OPERATING INSTRUCTIONS The MIG 140 FLUX semi-automatic welder should be operated in an atmosphere free from corrosive components and high dust levels. The device should not be placed in dusty places, near working grinders, etc. Dust and contamination with metal filings of control boards, cables and connections inside the device may lead to an electrical short circuit and, consequently, to damage to the welder. -
Page 9: Electrical Diagram
Machine Translated by Google 12 ELECTRICAL DIAGRAM... - Page 10 Machine Translated by Google 13. STORAGE AND TRANSPORT INSTRUCTIONS The device should be stored at a temperature of -10°C to +40°C and relative humidity of up to 80%, free from corrosive fumes and dust. The transport of packed devices should be carried out in covered means of transport. During transport, the packed device should be secured against moving and ensured in the correct position.
- Page 11 Machine Translated by Google DECLARATION OF CONFORMITY 01/MIG140FLUX/2022 Authorized manufacturer representative: TECWELD Piotr Polak 41-943 Piekary ÿlÿskie ul. Emerald 21/3/6 branch: 41-909 Bytom 1G Krzyÿowa Street We declare that the product listed below: Semi-automatic welding machine Trade name: MIG 140 FLUX MIG-140FL Type: Manufacturer's trademark:...
