- Page 1 Atlas Copco Heatless adsorption compressed air dryers CD 220, CD 300, CD 360 Basic control Instruction book...
-
Page 3: Basic Control
Atlas Copco Heatless adsorption compressed air dryers CD 220, CD 300, CD 360 Basic control From following serial No. onwards: API 692 000 Instruction book Original instructions Copyright notice Any unauthorized use or copying of the contents or any part thereof is prohibited. -
Page 4: Table Of Contents
Instruction book Table of contents Safety precautions......................4 ...........................4 AFETY ICONS ......................4 AFETY PRECAUTIONS GENERAL ...................5 AFETY PRECAUTIONS DURING INSTALLATION ....................6 AFETY PRECAUTIONS DURING OPERATION ................7 AFETY PRECAUTIONS DURING MAINTENANCE OR REPAIR General description......................9 ........................9 ENERAL DESCRIPTION .............................10 PERATION Electrical diagram......................14 Installation........................16 ........................16 IMENSION DRAWINGS... - Page 5 Instruction book ......................29 IMITATIONS FOR OPERATION ..........................29 PECIFIC DATA Instructions for Use......................31 Guidelines for inspection.....................32 Pressure Equipment Directives...................33 Declaration of conformity....................34 2920 7095 00...
-
Page 6: Safety Precautions
Instruction book Safety precautions Safety icons Explanation Danger for life Warning Important note Safety precautions, general General precautions All responsibility for any damage or injury resulting from neglecting these precautions, or non-observance of the normal caution and care required for installation, operation, maintenance and repair, even if not expressly stated, will be disclaimed by the manufacturer. -
Page 7: Safety Precautions During Installation
Instruction book Safety precautions during installation Precautions during installation 1. The dryer must only be lifted using suitable equipment and in accordance with the applicable safety regulations. Loose or pivoting parts must be securely fastened before lifting. It is strictly forbidden to dwell or stay in the risk zone under a lifted load. -
Page 8: Safety Precautions During Operation
Instruction book Also consult following safety precautions: Safety precautions during operation Safety precautions during maintenance or repair. These precautions apply to machinery processing or consuming air or inert gas. Processing of any other gas requires additional safety precautions typical to the application which are not included herein. -
Page 9: Safety Precautions During Maintenance Or Repair
Instruction book Safety precautions during maintenance or repair Precautions during maintenance or repair 1. Always use the correct safety equipment (such as safety glasses, gloves, safety shoes, etc.). 2. Use only the correct tools for maintenance and repair work. 3. Use only genuine spare parts. 4. - Page 10 Instruction book Also consult following safety precautions: Safety precautions during installation Safety precautions during operation. These precautions apply to machinery processing or consuming air or inert gas. Processing of any other gas requires additional safety precautions typical to the application which are not included herein.
-
Page 11: General Description
Instruction book General description General description Introduction The air dryers described in this book are heat-less adsorption dryers, built to remove moisture from compressed air for industrial purposes. The standard version is intended to reach a pressure dew point (PDP) of -40 ˚C (-40 ˚F). -
Page 12: Operation
Instruction book Rear view of a dryer reference designation reference designation Tower A Control panel Tower B Timer Dryer inlet Cubicle Dryer outlet Solenoid valves Inlet valve Nozzle for regeneration air Pneumatic actuator Pressure gauge tower A Pneumatic valve Pressure gauge tower B Silencer Air filter Non-return valve... -
Page 13: Flow Diagram
Instruction book The compressed air entering the dryer is led to one of the towers by means of the inlet valve (IV), which is controlled by a pneumatic actuator (PA). As the air flows upwards through the tower, the desiccant adsorbs the water vapour and the compressed air is dried. - Page 14 Instruction book Reference Designation Reference Designation Inlet Pressure switch Outlet Manual valve Air net Pilot air filter Dryer Pressure regulator (optional) Vessel Adjustable restriction Compressor Filter with drain Pressure indicator V11/V12 Outlet valve vessel A/B Outlet filter DDp Orifice V21/V22 Safety valve (optional) IF1/IF2 Inlet filter DD/PD...
-
Page 15: Service Panel
Instruction book Reference Designation Reference Designation TT01 Inlet temperature Y1A/Y2A Electrical signal regenerate vessel A/ Service panel The flow diagram of the dryer is also shown on the service panel: Service panel with flow diagram Reference Description On/Off switch LED Power ON LED Automatic operation LED Service Alarm 2920 7095 00... -
Page 16: Electrical Diagram
Instruction book Electrical diagram The complete service diagram is available inside the electric cabinet. Reference Explanation Customer's installation Maximum fuses with regard to circuit protection. Cable section may impose fuses of smaller value 2920 7095 00... - Page 17 Instruction book Reference Explanation Supply settings for X9 Connection for remote control (X3): to NO contact of compressor Supply connection for 115 and 230 V Time setting solenoid valves Reference Designation Reference Designation Controller card LED/Display card Solenoid relay, left tower Solenoid relay, right tower Y1 - (Y3) - Solenoid valve(s) left tower...
-
Page 18: Installation
Instruction book Installation Dimension drawings CD 220 2920 7095 00... - Page 19 Instruction book CD 300 2920 7095 00...
-
Page 20: Installation Proposal
Instruction book CD 360 Dryer inlet Dryer outlet Dimension of inlet and outlet connection Installation proposal Piping Make sure that all pipes, filters, valves, etc. are clean and that they are installed correctly with or without bypass system. Make sure that the piping is installed stress-free. For more information concerning air nets, cooling systems etc. - Page 21 Instruction book Depending from the fact if the remote control connector X3 is used or not (see also section Operation), there are two possibilities: Installation in case X3 is not used If the freeze contact X3 is not used, the correct order of installation is compressor - air receiver - dryer.
-
Page 22: General Recommendations
Instruction book Compressed air prefilter for general purpose filtration, particle removal down to 1 micron, maximum oil carry-over 0.5 ppm This filter provides extra protection of the dryer and extends the lifetime of the high efficiency filter cartridge (4). High efficiency filter, particle removal down to 0.01 micron, maximum oil carry-over 0.01 ppm To remove remaining impurities. -
Page 23: Electrical Connections
Instruction book Provide sufficient space under the filter elements in order to be able to replace the filter cartridges without the need having to disassemble the piping. • Always install a high efficiency filter (4) at the inlet of the dryer. A prefilter (3) is recommended to extend the lifetime of the high efficiency filter. - Page 24 Instruction book • For 115 V AC: connect the supply cable to terminals 2 (line) and 5 (neutral) and place a jumper wire between terminals 2-3 and 4-5: • X3 (freeze contact - P4) If you want to use the feature to “freeze” the regeneration cycle when the compressor runs unloaded, connect pin 1 and 2 of connector X3 with the potential free contact of the compressor (contact closed = freeze).
-
Page 25: Operating Instructions
Instruction book Operating instructions Safety Always observe all relevant safety instructions. Initial start-up To start up the dryer for the first time or after a long period of standstill, proceed as follows: 1. If installed, open the bypass valves of the dryer. 2. -
Page 26: During Operation
Instruction book During operation At regular intervals, check the status of the LED’s on the control panel. Refer to section Problem solving. Stopping To stop the dryer, proceed as follows: 1. If installed and if necessary, open the bypass valves of the dryer so that the application will still receive compressed air. -
Page 27: Maintenance
• Disconnect all pressure sources and vent the internal pressure of the system before dismantling any pressurized component. • Use genuine Atlas Copco spare parts only. Consult the Spare Parts List for part numbers. For preventive maintenance, dedicated Service kits are available. -
Page 28: Resetting The Service Timer
Instruction book Resetting the service timer Resetting procedure for basic control version Control panel, basic version To reset the timer card, proceed as follows: • Close off the dryer as described in the stopping procedure, see section Operating instructions. • Switch off the dryer by putting Switch S1 to ‘Off’ position. LED (2) (dryer operating) will extinguish. Perform the service plan as scheduled. -
Page 29: Disposal Of Used Material
Instruction book Disposal of used material Used filters or any other used material (e.g. desiccant, lubricants, cleaning rags, machine parts, etc.) must be disposed of in an environmentally friendly and safe manner, and in line with the local recommendations and environmental legislation. -
Page 30: Problem Solving
Instruction book Problem solving Overview Symptom Possible cause Corrective action PDP temperature too high The dryer has not had the time to Close the valve installed between the regenerate completely. dryer and the application (if permitted) and have the desiccant regenerated. The silencers are clogged. -
Page 31: Technical Data
Min. compressed air inlet temperature ˚F 35.6 35.6 Specific data Standard version (PDP -40 ˚C) - 11 bar Desiccant type: activated alumina (Al CD 220 CD 300 CD 360 Max. volume flow at dryer inlet Max. volume flow at dryer inlet 2920 7095 00... - Page 32 Instruction book CD 220 CD 300 CD 360 Regeneration air consumption average at max. inlet flow Total amount of desiccant Total amount of desiccant Recommended filter size DD/PD/DDp Mass Mass 1323 1433 Time of half a cycle Regeneration time Installed power Standard version (PDP -40 ˚C) - 16 bar...
-
Page 33: Instructions For Use
Instruction book Instructions for Use Instructions Step Description The dryers can contain pressurized air. This can be potentially dangerous if the equipment is misused. The dryer vessels must only be used as a compressed air vessel and must be operated within the limits specified on the data plate. -
Page 34: Guidelines For Inspection
The Declaration of Conformity / Declaration by the Manufacturer is part of the documentation that is supplied with this air dryer. Local legal requirements and/or use outside the limits and/or conditions as specified by Atlas Copco may require other inspection periods as mentioned below. -
Page 35: Pressure Equipment Directives
Left vessel Right vessel Design Vessel diameter Vessel internal pressure (mm) volume (l) (bar)e CD 220 1624 0269 00 1624 0270 00 CD 300 1624 0180 00 1624 0181 00 CD 360 1624 0202 00 1624 0203 00 Table B Type Min. -
Page 36: Declaration Of Conformity
Instruction book Declaration of conformity Typical example of a Declaration of Conformity document (1): Contact address: Atlas Copco Airpower n.v. P.O. Box 100 B-2610 Wilrijk (Antwerp) Belgium 2920 7095 00... - Page 38 Atlas Copco's pursuit of innovation never ceases, driven by our need for reliability and efficiency. Always working with you, we are committed to providing you the customized quality air solution that is the driving force behind your business.
