117208 Tablemount for Cynap Videobar
The Cynap Videobar by WolfVision is designed for versatile installations and can also be mounted on the optional tablemount.
Simply hang the Cynap Videobar on the tablemount until the fixing screws engage in the slots. Set up the device horizontally and
tighten all three hex nuts (spanner 8mm). Establish the required cable connections (guide the cables either from top, bottom, or
through the centre-hole of the tablemount).
Adjust the the camera view to your room requirements by tilting the Cynap Videobar.
To remove, disconnect all cables, loosen the three hex nuts and simply lift the device to pull it off.
Safety Instructions
· Pay attention to local regulations and laws.
· Pay attention to the mechanical load of 7kg [15.43lb], the table must be suitable for this additional load.
Avoid overloading: Do not exceed the recommended maximum load. Overloading may cause damage to the products or lead to
accidents.
· Prevent the system from falling down.
· Regular inspection: Check the tablemount regularly for wear, loose screws, or other signs of deterioration. Replace defective parts
immediately.
· Do not modify: Do not make any changes to the mount, as this may compromise its safety and functionality.
· For operation, ensure that the scissor mechanism remains in the folded position at all times.
· Do not lean on the Cynap videobar and do not place any objects on it.
Warning
· Improper installation or failure to adhere to weight and size restrictions may result in serious injuries or damage to the equipment.
· Keep out of reach of children.
· Contains small parts that are not suitable for children under 3 years. Choking hazard!
Disclaimer
WolfVision disclaims any liability for injuries or damages resulting from improper use or installation. Please follow the operating
instructions and contact your WolfVision partner if you have any questions or concerns.
Example of mounted Cynap Videobar
Holder
mounted on
the back of
the Cynap
Videobar
Please note:
Consider heat dissipation of 100 Watt! Keep area around the Cynap Videobar clear.
Metal cabinets will decrease the possible range of wireless devices!
Printed in Austria - March 2025
.
