8572777A
27" (69 CM) GAS WASHER/DRYER
INSTALLATION INSTRUCTIONS
WASHER/DRYER SAFETY .............................. 1
INSTALLATION INSTRUCTIONS .................... 2
Tools and Parts.............................................. 2
Alternate Parts ............................................... 3
Location Requirements ................................ 3
Drain System .................................................4
Electrical Requirements................................. 5
Gas Supply Requirements............................. 5
Venting Requirements ...................................6
Remove Shipping Strap ................................ 7
Install Leveling Legs ...................................... 8
Connect the Drain Hose ................................ 8
Connect the Inlet Hoses ................................ 8
Secure the Drain Hose .................................. 9
Plan Vent System ........................................10
Install Vent System ......................................11
Level Washer/Dryer .....................................11
Make Gas Connection.................................11
Connect Vent ...............................................12
Complete Installation...................................12
WASHER/DRYER SAFETY
Your safety and the safety of others are very important.
IMPORTANT SAFETY INSTRUCTIONS
When discarding or storing your old clothes dryer, remove the door.
SAVE THESE INSTRUCTIONS
