Samsung QN43LS05BAFXZA Manual

ENG
About the Samsung SolarCell Remote (Samsung Smart Remote)
The Accessibility Shortcuts button on your
remote provides easy access to the accessibility
functions on your TV.
For more information, refer to the next page.
Press and hold the Volume button to
display the Accessibility Shortcuts menu.
For battery recycling
go to call2recycle.org;
or call 1-800-822-8837
Expose to light when the remote
is not in use. This will extend the
remote's operating time.
USB port (C-type) for charging
Used for quick charging. The LED on the front will
light when charging. When the battery is fully
charged, the LED will turn off.
• The USB Cable is not provided.
Fire or explosion may occur, resulting in damage to the remote control or personal injury.
• Do not apply shock to the remote control.
• Be careful not to let foreign substances such as metal, liquid, or dust come in contact with the charging
terminal of the remote control.
• When the remote control is damaged or you smell smoke or burning fumes, immediately stop operation
and then repair it at the Samsung service center.
• Do not arbitrarily disassemble the remote control.
• Be careful not to let infants or pets suck or bite the remote control. Fire or explosion may occur, resulting in
damage to the remote control or personal injury.
Solar Cell
Button
Press to turn the TV on or off.
-01 • Select whether to switch the TV to Landscape Mode or Portrait Mode before turning off
(Power) or to turn off the TV without changing the orientation. To change to the desired setting,
navigate to Power Off Mode (
> Power and Energy Saving > Power Off Mode) and change the setting.
Used as MIC when using voice recognition with the remote control.
When charging the remote control via the USB port, the LED is lit if charging is in progress.
1 MIC / LED
1
When charging is complete, the LED is turned off.
• Do not impact the MIC hole or use a sharp object to poke into the hole.
Runs Voice Assistant. Press and hold the button, say a command, and then release the button to
run Voice Assistant.
• The supported Voice Assistant's languages and features may differ by geographical region.
(Voice Assistant)
[ Keep the remote more than 0.6 inches (15.24 mm) from your face when using and speaking
2
to Voice Assistant through the mic on the remote.
Each time you press this button, Settings menu / virtual numeric pad / Option pad with Color
3
buttons are displayed alternately.
(Settings - Number • Use this button to access additional options that are specific to the feature in use.
• Press to bring up the virtual numeric pad on the screen. Use the numeric keypad to enter
- Color button)
numeric values. Select numbers and then select Done or Enter Number to enter a numeric
value. Use to change the channel, enter a PIN, enter a ZIP code, etc.
Press the button to rotate the screen to Landscape Mode or Portrait Mode.
(Rotate)
2 Directional button
Use to navigate the menu or move the focus to highlight items on the Home Screen.
(up, down, left, right)
4
Selects or runs a focused item. When pressed while you are watching a broadcast program,
3 Select
detailed program information appears.
Press to return to the previous menu. When pressed for 1 second or more, the running function
(Return)
is terminated. When pressed while you are watching a program, the previous channel appears.
Press to switch to the Media Home. From the Ambient Mode screen, press to switch to the
(Smart Hub)
Ambient Mode Home.
When pressed, the playback controls appear. Using these controls, you can control the media
content that is playing.
(Play/pause)
To use Game Bar, press and hold the button in Game Mode.
• Game Bar may not be supported depending on the model or geographical area.
(Volume) Move the button up or down to adjust the volume. To mute the sound, press the button.
Move the button up or down to change the channel. To see the Guide screen, press the button.
(Channel)
When pressed for 1 second or more, the Channel List screen appears.
Press and hold the button up or down to quickly change the channel.
Launch the app indicated by the button.
4 Launch app button
• Available apps may differ depending on the geographical area or contents provider.
If the Samsung Smart Remote does not pair to the TV automatically, point it at the front of the
+ (Pairing)
TV, and then press and hold the
Use the Samsung Smart Remote less than 20 feet (6 m) from the TV. The usable distance may vary with the wireless
environmental conditions.
– The images, buttons, and functions of the Samsung Smart Remote may differ with the model or geographical area.
– The Universal Remote function operates normally only when you use the Samsung Smart Remote that comes with the TV.
– It is recommended to use an original Samsung charger. Otherwise, it may cause performance degradation or failure of
the product. In this case, the warranty service is not applicable.
– When the remote control does not work due to low battery, charge it by using the USB-C type port.
– When some apps are launched in Portrait Mode, their mode can be switched to Landscape depending on the app's policy.
Description
> Menu > Settings > All Settings > General & Privacy
and buttons simultaneously for 3 seconds or more.
