Samsung VG-TM2560 Instruction Manual

About the Samsung SolarCell Remote (Samsung Smart Remote)
Solar Cell
Expose to light when the remote is not in use.
This will extend the remote's operating time.
USB port (C-type) for charging
Used for quick charging. The LED on the front will light when
charging. When the battery is fully charged, the LED will turn off.
• The USB Cable is not provided.
Fire or explosion may occur, resulting in damage to the remote control or
personal injury.
• Do not apply shock to the remote control.
• Be careful not to let foreign substances such as metal, liquid, or dust come in
contact with the charging terminal of the remote control.
• When the remote control is damaged or you smell smoke or burning fumes,
immediately stop operation and then repair it at the Samsung service centre.
• Do not arbitrarily disassemble the remote control.
• Be careful not to let infants or pets suck or bite the remote control. Fire or explosion
may occur, resulting in damage to the remote control or personal injury.
UK Declaration of Conformity
Manufacturer
Name: Samsung
Registered Trade Name: Samsung Electronics Co., Ltd
Address: 129 Samsung-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, Korea
Product Details
Product: Smart Control
Model(s): VG-TM2560
Declaration and applicable standards
We hereby declare under our sole responsibility that the product
above is in compliance with the essential requirements of the Radio
Equipment Regulations 2017 by application of:
EMC Safety
EN 301 489-1 V2.2.3 EN IEC 62368-1:2020+A11:2020
EN 301 489-17 V3.2.4 EN IEC 62368-3 :2020
EN 62311:2008
-00
1
2
3
4
Radio
EN 300 328 V2.2.2
and the Restriction of the Use of Certain Hazardous Substances in
Electrical and Electronic Equipment Regulations 2012 by application
of EN IEC 63000:2018.
Signed for and on behalf of : Samsung
Samsung Euro QA Lab, Saxony Way, Yateley, GU46 6GG, UK ※
2024-12-12 (Place and date of signature)
Glenn Bodman – Director Regulatory
Compliance
(Name and signature of authorized
person)
※ This is not the address of Samsung Service Centre. Please see the
address or the phone number of Samsung Service Centre in the
warranty card or contact the retailer where you purchased your
product.
Button
Press to turn the TV on or off.
(Power) For The Frame model, When watching TV, press to switch to Art mode. In Art mode, press to switch to the
Home screen. Press and hold to turn off the TV completely.
Used as MIC when using voice recognition with the remote control.
When charging the remote control via the USB port, the LED is lit if charging is in progress. When charging is
1 MIC / LED
complete, the LED is turned off.
• Do not impact the MIC hole or use a sharp object to poke into the hole.
If this button is pressed while watching a broadcast, users are provided with recommendations related to the
current content.
Click to Search
• Types of recommendations may differ, depending on the content provider.
• This function may not be supported depending on the model or geographical area.
Runs Voice Assistant. Press and hold the button, say a command, and then release the button to run Voice
Assistant.
(Voice Assistant)
• The supported Voice Assistant's languages and features may differ by geographical area.
You can access Setting menu / virtual numeric pad / Colour buttons / Option pad / SmartThings directly.
• Accessing the SmartThings app using this button may not be supported, depending on the model.
• Use this button to access additional options that are specific to the feature in use.
(Settings / Number
• Press to bring up the virtual numeric pad on the screen. Use the numeric keypad to enter numeric
/ Colour button)
values. Select numbers and then select Done or Enter Number to enter a numeric value. Use to change
the channel, enter a PIN, enter a ZIP code, etc.
• When pressed for 1 second or more, the Shortcuts menu screen appears.
2 Directional button
Moves the focus and changes the values seen on the TV's menu.
(up, down, left, right)
Selects or runs a focused item. When pressed while you are watching a broadcast programme, detailed
3 Select
programme information appears.
Press to return to the previous menu. When pressed for 1 second or more, the running function is terminated.
(Return)
When pressed while you are watching a programme, the previous channel appears.
Press to switch to the Home Screen.
(Smart Hub) • If you press this button for more than 1 second, the same function as when pressing the
achieved.
When pressed, the playback controls appear. Using these controls, you can control the media content that is
playing.
(Play/pause)
To use Game Bar, press and hold the button in Game Mode.
• Game Bar may not be supported depending on the model or geographical area.
Move the button up or down to adjust the volume. To mute the sound, press the button. When pressed for 2
seconds or more, the Accessibility Shortcuts appears.
(Volume)
• may not be present, depending on the model.
Move the button up or down to change the channel. To see the Guide screen, press the button.
(Channel)
• When pressed for 1 second or more, the Channel List screen appears.
Press each button to run its function.
4 Launch app button
• Available apps may differ depending on the geographical area or contents provider.
If the Samsung Smart Remote does not pair to the TV automatically, point it at the front of the TV, and then press
+ (Pairing)
and hold the and buttons simultaneously for 3 seconds or more.
– Use the Samsung Smart Remote less than 6 m from the TV. The usable distance may vary with the wireless environmental conditions.
– The images, buttons, and functions of the Samsung Smart Remote may differ with the model or geographical area.
– The Universal Remote function operates normally only when you use the Samsung Smart Remote that comes with the TV.
– It is recommended to use an original Samsung charger. Otherwise, it may cause performance degradation or failure of the product. In this
case, the warranty service is not applicable.
– When the remote control does not work due to low battery, charge it by using the USB-C type port.
– For specific functions of each button on the Samsung Smart Remote, access the Remote Control Guide (
Settings > All Settings > Support > Tips and User Guides > Remote Control Guide).
Description
button is
> left directional button >
