Operator's Manual
Gasoline containing up to 10% ethanol (E10) is accept-
able for use in this machine. The use of any gasoline ex-
ceeding 10% ethanol (E10) will void the product warranty.
Manual de Operario
Esta máquina puede utilizar gasolina con un con-
tenido de hasta el 10% de etanol (E10). El uso de una
TS 142X
gasolina que supere el 10% de etanol (E10) anulará la
garantía del producto.
Please read the operator's manual carefully and make sure
you understand the instructions before using the machine.
114 20 68-49 Rev. 1
Por favor lea cuidadosamente y comprenda
English/Spanish
estas intrucciones antes de usar esta maquina.
Advertisement
Table of Contents
Related Manuals for Husqvarna 96043030200
Summary of Contents for Husqvarna 96043030200
- Page 1 Operator’s Manual Gasoline containing up to 10% ethanol (E10) is accept- able for use in this machine. The use of any gasoline ex- ceeding 10% ethanol (E10) will void the product warranty. Manual de Operario Esta máquina puede utilizar gasolina con un con- tenido de hasta el 10% de etanol (E10).
-
Page 2: Safety Rules
SAFETY RULES Safe Operation Practices for Ride-On Mowers DANGER: THIS CUTTING MACHINE IS CAPABLE OF AMPUTATING HANDS AND FEET AND THROW ING OBJECTS. FAILURE TO OBSERVE THE FOLLOWING SAFETY INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR DEATH. • Before and while backing, look behind and down for small WARNING: In order to prevent ac ci den tal children. -
Page 3: Slope Operation
SAFETY RULES Safe Operation Practices for Ride-On Mowers III. SLOPE OPERATION • Never remove gas cap or add fuel with the engine running. • Allow engine to cool before refueling. WARNING! When loading or unloading • Never fuel the machine indoors. this machine, do not exceed the maximum •... -
Page 4: Table Of Contents
SUPPORT / HELP If you require assistance or have questions concerning the application, operation, maintenance or parts for your product: • Visit our website: www.husqvarna.com • Call Us Toll Free: 1-800-487-5951 TABLE OF CONTENTS SAFETY RULES ............2-3 MAINTENANCE ............. -
Page 5: Unassembled Parts
UNASSEMBLED PARTS Keys Slope Sheet Battery (1) Oil Drain Tube (2) Hex Bolts (1) Quick Connect (2) Nut Keps Key(s) ASSEMBLY Your new tractor has been assembled at the factory with the exception of those parts left unassembled for shipping purposes. TOOLS REQUIRED FOR ASSEMBLY •... - Page 6 ASSEMBLY ✓ NOTE: You may now roll your tractor off the skid. Continue CHECKLIST using the instructions that follow to remove the tractor from the skid. BEFORE YOU OPERATE YOUR NEW TRAC TOR, WE WARNING: Before start ing, read, un der stand and fol- WISH TO ENSURE THAT YOU RECEIVE THE BEST low all in struc tions in the Op er a tion section of this man u al.
-
Page 7: Operation
OPERATION These symbols may appear on your tractor or in literature supplied with the product. Learn and understand their meaning. REVERSE NEUTRAL HIGH FAST SLOW COLD WEATHER IGNITION SWITCH STARTING POSITION ENGINE OFF LIGHTS ON ENGINE ON ENGINE START PARKING BRAKE MOWER HEIGHT MOWER LIFT FUEL... -
Page 8: Know Your Tractor
OPERATION KNOW YOUR TRACTOR READ THIS OPERATOR'S MANUAL AND SAFETY RULES BEFORE OPERATING YOUR TRACTOR Compare the illustrations with your tractor to familiarize yourself with the locations of various controls and ad just ments. Save this manual for future reference. Fig. -
Page 9: To Move Forward And Backward
OPERATION The operation of any tractor can result in foreign objects thrown into the eyes, which can result in severe eye dam age. Always wear safety glass es or eye shields while operating your tractor or per form ing any ad just ments or repairs. We rec om mend standard safety glasses or a wide vision safety mask worn over spectacles. - Page 10 OPERATION TO USE CRUISE CONTROL (J) (See Fig. 7) TO ADJUST GAUGE WHEELS (See Fig. 9) The cruise control feature can be used for forward travel Gauge wheels are prop er ly ad just ed when they are slight ly only.
-
Page 11: To Operate On Hills
OPERATION REVERSE OPERATION SYSTEM (ROS) (See TO TRANSPORT (See Fig. 3 &12) Fig. 11) When push ing or tow ing your trac tor, ensure transmission is disengaged by placing freewheel control in free wheel ing Your tractor is equipped with a Reverse Operation System po si tion. -
Page 12: Before Starting The Engine
OPERATION BEFORE STARTING THE ENGINE TO START ENGINE (See Fig. 3) The Briggs & Stratton Endurance engine equipped with CHECK ENGINE OIL LEVEL your tractor features a Ready-Start automatic choke system The engine in your tractor has been shipped from the fac- to provide simplifi... -
Page 13: Mowing Tips
OPERATION PURGE TRANSMISSION MOWING TIPS • DO NOT use tire chains when the mower hous ing is CAUTION: Never engage or disengage free- attached to tractor. wheel lever while the engine is run ning. • Mower should be properly leveled for best mowing performance. -
Page 14: Maintenance Schedule
MAINTENANCE BEFORE EVERY EVERY EVERY EVERY EVERY BEFORE MAINTENANCE SCHEDULE EACH SEASON STORAGE HOURS HOURS HOURS HOURS Check Brake Operation Check Tire Pressure Check Operator Presence and ROS Systems Check for Loose Fasteners Check/Replace Mower Blades Lubrication Chart Check Battery Level Clean Battery and Terminals Clean Debris off Steering Plate Check Transaxle Cooling... -
Page 15: Maintenance
MAINTENANCE TRACTOR BLADE CARE For best results mower blades must be kept sharp. Re place Always observe safety rules when per form ing any bent or damaged blades. main te nance. BRAKE OPERATION CAUTION: Use only a replacement blade ap- proved by the manufacturer of your tractor. -
Page 16: Engine Lubrication
MAINTENANCE TO CHANGE ENGINE OIL (See Fig. 16 - 18) V-BELTS Determine temperature range expected before oil change. Check V-belts for deterioration and wear after 100 hours All oil must meet API service classifi cation SJ-SN. of operation and replace if necessary. The belts are not •... - Page 17 MAINTENANCE CLEANING ENGINE OIL FILTER • Clean engine, battery, seat, fi nish, etc. of all foreign Replace the engine oil fi lter every season or every other oil matter. change if the tractor is used more than 100 hours in one year. •...
- Page 18 MAINTENANCE DECK WASHOUT PORT (See Fig. 21) Your tractor’s deck is equipped with a washout port as part of its deck wash system. It should be utilized after each use. 1. Drive the tractor to a level, clear spot on your lawn, near enough to a water spigot for your garden hose to reach.
-
Page 19: Service And Adjustments
SERVICE AND ADJUSTMENTS WARNING: TO AVOID SERIOUS INJURY, BEFORE PERFORMING ANY SER VICE OR AD JUST MENTS: • Depress brake pedal fully and set parking brake. • Place attachment clutch in “DISENGAGED” position. • Turn ignition key to “STOP” and remove key. •... - Page 20 SERVICE AND ADJUSTMENTS • ATTACH MOWER SIDE SUSPENSION ARMS (A) TO • Insert end of link (E) into hole in front mower bracket CHASSIS - Position hole in arm over pin (B) on outside and secure with washer and retainer spring (J). of tractor chassis and secure with retainer spring.
- Page 21 SERVICE AND ADJUSTMENTS TO LEVEL MOWER FRONT-TO-BACK ADJUSTMENT (See Figs. 30 & 31) IMPORTANT: Deck must be level side-to-side. Ensure tires are properly infl ated to the PSI shown on tires. If tires are over or under infl ated, it may affect the appear- To obtain the best cutting re sults, the mower blades should ance of your lawn and lead you to think the mower is not be adjusted so the front tip is 1/8"...
- Page 22 SERVICE AND ADJUSTMENTS TO REPLACE MOWER BLADE DRIVE BELT BELT REMOVAL - (See Fig. 32) • Remove mower. (See “TO REMOVE MOWER” section in this manual.) The mower blade drive belt may be replaced without tools. Park the tractor on level surface. Engage parking brake. NOTE: Observe entire motion drive belt and position of all belt guides and keepers.
- Page 23 SERVICE AND ADJUSTMENTS TO REMOVE WHEEL (See Fig. 34) TO REMOVE CABLES, REVERSE ORDER - • BLACK cable fi rst from chassis and then from the fully • Block up axle securely. charged battery. • Remove axle cover, retaining ring and washers to allow •...
- Page 24 SERVICE AND ADJUSTMENTS TRANSMISSION TO REPLACE HEADLIGHT BULB • Raise hood. REMOVAL/RE PLACE MENT • Pull bulb holder out of the hole in the backside of the grill. • Replace bulb in holder and push bulb holder securely Should your transmission require removal for service or back into the hole in the backside of the grill.
-
Page 25: Storage
STORAGE ENGINE Immediately prepare your tractor for storage at the end of the season or if the tractor will not be used for 30 days or more. FUEL SYSTEM IMPORTANT: IT IS IMPORTANT TO PREVENT GUM DEPOSITS WARNING: Never store the trac tor with FROM FORMING IN ES SEN TIAL FUEL SYSTEM PARTS SUCH gas o line in the tank inside a building AS CARBURETOR, FUEL FIL TER, FUEL HOSE, OR TANK... -
Page 26: Troubleshooting
TROUBLESHOOTING PROBLEM CAUSE CORRECTION 1. Out of fuel. 1. Fill fuel tank. Will not start 2. Engine fl ooded. 2. Wait several minutes before attempting to start. 3. Bad spark plug. 3. Replace spark plug. 4. Dirty air fi lter. 4. - Page 27 TROUBLESHOOTING PROBLEM CAUSE CORRECTION Engine continues to 1. Faulty operator-safety presence control 1. Check wiring, switches and connections. If not run when operator system. corrected, contact an authorized service center/ department. leaves seat with attachment clutch CAUTION: DO NOT operate machine until engaged problem is corrected.
-
Page 28: Suggested Guide For Sighting Slopes For Safe Operation
SUGGESTED GUIDE FOR SIGHTING SLOPES FOR SAFE OPERATION ONLY RIDE UP AND DOWN HILL, NOT ACROSS HILL 15 DEGREES MAX. WARNING: To avoid serious injury, operate your tractor up and down the face of slopes, never across the face. Do not mow slopes greater than 15 degrees. -
Page 29: Español
02.06.20 CL Printed in U.S.A.
