Summary of Contents for mabe MEI12VR
- Page 1 Window air conditioner Read this manual completely before installing your new air conditioner Model No. MEI09VR MEI12VR...
-
Page 3: Table Of Contents
CONTENTS Thank you for choosing MABE air conditoner.Our design is based on the best eff- iciency and the lowest noise operation and it can keep the room comfortable. Please read this operating manual carefully before operating the unit and keep it for consultation. -
Page 4: The Refrigerant
The Refrigerant ● To realize the function of the air conditioner unit, a special refrigerant circulates leads to explosion . It can ● Compared to common refrigerants, R32 is a nonpolluting refrigerant with no lower. R32 has got very good thermodynamic features which lead to a really high WARNING: Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacture.Should repair be necessary, contact your... -
Page 5: Precautions
Precautions Warning This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge,unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance. -
Page 6: Function
Function Introduction Window type room air conditioners of Autumn Spring can regulate the room temperature and dry Summer Winter Room the room. It is convenient for your work, study temp. and life. It can be widely used in residence, shop, hotel, office, library and laboratory, and Wind so on. -
Page 7: Power Requirement
Power requirement Rated voltage :230V~ 60Hz ● The electric components will be damaged when the voltage is too high. If the voltage is too low, the compressor will vibrate violently to damage the refrigerant system and easily cause the compressor and electric components not work. The ground must be connected. -
Page 8: Installation
Installation Installation precaution: Window type conditioner is so valuable and the improper installation of it will cause a lot of da- mage! Please associate the professional tech- nician to install the unit and don’t install it by yourself. Otherwise, we are not responsible for the damage like this. -
Page 9: Installation Procedure
Installation procedure: 1) Remove the sticker from the front panel. 2) Put the unit into the installation hole. ● When installing the unit, it should be sl- Horizontal line anted down to the back to avoid the en- largement of noise or vibration. (Slant 6~10mm between 6-10mm.) (Shown at right figure.) -
Page 10: Drain Water
Drain water : Drain pan and drain hose need to be installed before using. Drain hose is not included in the products, you need to purchase it locally to satisfy your particular needs. Use the following procedure to install drain pan and drain hose. -
Page 11: Notes For Installation
Notes for installation Remove Before removing air conditioner to the other place, you Then it must be done under the direction of the profe- ssional technician. In addition, the charge of this must be paid. Noise enlargement of noise and vibration. ●... -
Page 12: Air Direction Adjustment
Panel outlook picture, just for reference, please take the real unit as standard. Cabinet Air inlet (behind the louver front intake grille) Front intake grille Remote control panel Air direction adjustment positioning the vane to discharge the air upwards, downwards or straight out. - 9 -... -
Page 13: Remote Control Operation Procedure
Remote control operation procedure Buttons on remote controller ON/OFF button MODE button +/- button FAN button SWING button SLEEP button TIMER button Introduction for icons on display screen Timer on Timer off Sending signal auto operation swing operation cool operation sleep operation dry operation lock... -
Page 14: Introduction For Buttons On Remote Controller
Introduction for buttons on remote controller Note: ● This is a general use remote controller, it could be used for the air conditioners with multifunction; For some function, which the model doesn't have, if press the corresponding button on the remote controller that the unit will keep the original running status. - Page 15 Introduction for buttons on remote controller FAN button Pressing this button can select fan speed circularly as: AUTO, SPEED 1 ( SPEED 2 ( ) , SPEED 3 ( ), SPEED 4 ( ) (unavailable in this air conditioner. Speed 4 is the same with speed 3.). AUTO SPEED 1 (equals to low fan speed) SPEED 2 (equals to mid fan speed)
-
Page 16: Function Introduction For Combination Buttons
Introduction for buttons on remote controller Note: ● Range of time setting is: 0.5~24h ● The interval between two motions can't exceed 5s, otherwise the remote con- troller will exit setting status. Function introduction for combination buttons Child lock function Press “+”... -
Page 17: Replacement Of Batteries In Remote Controller
Replacement of batteries in remote controller 1. Press the mark “ ” on back cover of batteries box cover for remote controller with fingers as shown in the fig, and then remove the batteries box cover along the arrow direction. Battery 2. -
Page 18: Remote Control Panel
Remote control panel Note: If wireless remote controller is lost, open the surface panel and operate manually. POWER BUTTON SIGNAL RECEIVER Operation starts when pressing this button, and stops when pressing this button again. MODE BUTTON SWING BUTTON Select the operation mode, AUTO, HEAT, COOL, FAN, Activate the automatic air swing function. -
Page 19: Operation Tips
Operation Tips ※ Operating Temperature Range Indoor side DB/WB(°C) Outdoor side DB/WB(°C) 32/23 43/- Maximum cooling 27/- 24/18 Maximum heating The operating temperature range (outdoor temperature) for cooling only unit is 18°C~ 43°C; for heat pump unit is -7°C~ 43°C. Operation for comfort and economy Do not overcool the room te- Keep blind or curtains closed. -
Page 20: Caution
Caution Operations for safety and health 1) The plug must be accessible after the appliance is positioned. 2) Do not use this appliance in the laundry. 3) If the power cord is damaged, it must be replaced by the manufacture or its service agent in void of hazard. - Page 21 Always wait at Always wait at least 3 minutes before least 3 minutes. switching the air conditioner on again after you have switched it off during cooling or heating. Please notice that the unit is filled with flammable gas R32. Inappropriate treatment of the unit involves the risk of severe damages of people and material.
-
Page 22: Care And Maintenance
Care and maintenance Always turn off the air conditioner and main power supply before cleaning to ensure safety. Cleaning unit Air filter 1. Cut power of f before cleaning. The air filter behind the intake grille should be Plug out only washed at least once every two weeks or as after air con- often as it needs cleaning. -
Page 23: Troubleshooting Guide
Troubleshooting guide Please check the following items before asking for repair, it saves your time andmoney. Fault phenomenon Trouble-shooting ● Is there a power failure? Air conditioner ● Is the plug out? dose not oper- ● Is power fuse or switch off ? ate at all. -
Page 24: After Service
Malfunction code Solution Means defrosting status. It’s the normal phenomenon. Please contact professional person to deal with it. Please contact professional person to deal with it. Please contact professional person to deal with it. Please contact professional person to deal with it. Please contact professional person to deal with it. -
Page 25: Safety Operation Of Flammable Refrigerant
Safety operation of flammable refrigerant ● Qualification requirement for installation and maintenance man 1. All the work men who are engaging in the refrigeration system should bear the valid certification awarded by the authoritative organization and the qualification for dealing with the refrigeration system recognized by this industry. If it needs other technician to maintain and repair the appliance, they should be supervised by the person who bears the qualification for using the flammable refrigerant. - Page 26 ● Welding 1. If you should cut or weld the refrigerant system pipes in the process of maintain- ing, please follow the steps as below a. Shut down the unit and cut power supply b. eliminate the refrigerant c. vacuuming d.
- Page 28 66129920359...
