  • Page 1 Service Manual Refrigerator Model: AFD630IX CA 61116 321138...
  • Page 2 PRODUCT Brand: Haier Model: AFD630IX Product Code: 61116 Fisher & Paykel Appliances Ltd Fisher & Paykel Customer Services Pty Ltd 78 Springs Road, East Tamaki PO Box 798, Cleveland, QLD 4163 Manukau 2013 A.C.N. 003 3335 171 PO Box 58-732, Botany...

  • Page 3: Table Of Contents

    SERVICE MANUAL Issue 201106 Rev. Model: AFD630IX Ref1106S013V0 Contents Chapter 1 General Information ..................4 1-1. General Guidelines ......................... 4 1-2. Insurance test ......................... 4 1-3. How to read this Service Manual .................... 5 Chapter 2 Product Feature .................... 6 2-1.
  • Page 4 SERVICE MANUAL Issue 201106 Rev. Model: AFD630IX Ref1106S013V0 Chapter 8 Trouble shooting ..................29 8-1. Common problems and solutions ..................29 8-1-1 Symptom: food in the fridge storage compartment is frozen ........29 8-1-2 Symptom: the buzzer beeps to alarm ................29 8-1-3 Symptom: no defrosting ....................

  • Page 5: Chapter 1 General Information

    SERVICE MANUAL Issue 201106 Rev. Model: AFD630IX Ref1106S013V0 Chapter 1 General Information 1-1. General Guidelines When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or damaged by the short circuit. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly installed.

  • Page 6: How To Read This Service Manual

    SERVICE MANUAL Issue 201106 Rev. Model: AFD630IX Ref1106S013V0 Photo used in this manual The illustration and photos used in this Manual may not base on the final design of products, which may differ from your products in some way. 1-3. How to read this Service Manual 1-3-1.

  • Page 7: Chapter 2 Product Feature

    SERVICE MANUAL Issue 201106 Rev. Model: AFD630IX Ref1106S013V0 Chapter 2 Product Feature 2-1. SPECIFICATIONS Model AFD 630 I X Sketch Product description (Refrigerator/Freezer) Refrigerator Type of appliance (FS=freestanding / BI= built-in) Type of cooling system(NF=no frost/ S=static) Climate class* Freezer compartment / Star rating...
  • Page 8 Features: Energy consumption per | 100 net / 24 h 1.47 Cooling system: K=Compressor / A=Absorption Aesthetics Colours: W=white, B=Obsidian, SS=stainless steel Cabinet / Door / Top / Frame (w / c) B/B/B/B Fascia panel / Handle (w / c) B/ss Door: F=flat / R= rounded / S = streamline...

  • Page 9: Main Functions And Features

    SERVICE MANUAL Issue 201106 Rev. Model: AFD630IX Ref1106S013V0 ice maker Manual/ Automatic Ice cube tray(s) n° Butter holder Egg trays Adjustable feet front / rear n° 2 / - Castors front / rear -/yes Length of cable/incl. plug Condenser Back wall / Integrated...

  • Page 10: External Views

    SERVICE MANUAL Issue 201106 Rev. Model: AFD630IX Ref1106S013V0 ◆ Zero degree fresh keeping. 2-3. External views Fridge storage compartment Display panel Turnover box (include egg box) Turnover box rack Shelf Butter box Wire wine holder Middle bottle rack Fresh keeping box cover...

  • Page 11: Product Dimensions

    SERVICE MANUAL Issue 201106 Rev. Model: AFD630IX Ref1106S013V0 2-4. Product Dimensions Three-Door Refrigerator Dimensions: Refrigerator height H=1880mm Refrigerator width W=595mm Refrigerator depth D=730mm Cabinet depth D1=576mm Door depth D2=78mm...

  • Page 12: Chapter 3 Disassembly

    SERVICE MANUAL Issue 201106 Rev. Model: AFD630IX Ref1106S013V0 Chapter 3 Disassembly 3-1 Installing the Freezer Drawer Handle (1) Take the handle from the packing bag and align it with the handle seat on the door. note: the screw hole on the handle should be facing downward.

  • Page 13: Dismantle And Install The Upper Decoration Strip And Cables

    SERVICE MANUAL Issue 201106 Rev. Model: AFD630IX Ref1106S013V0 connecting it. Please do not disconnect the wires. Gently put the front decoration strip on the top of the refrigerator. ⑷ Detach the screws affixed to the upper hinge and remove the hinge.

  • Page 14: 3-2-3: Dismantle And Install The Middle And Lower Hinges

    SERVICE MANUAL Issue 201106 Rev. Model: AFD630IX Ref1106S013V0 (6) Remove the stop block on the bottom of the door and then reatacht on the other side of the door after turning 180 degrees. (7) Turn the middle hinge by 180 degrees and then fit it on the other side of the cabinet.

  • Page 15: Removing The Freezer Drawer

    SERVICE MANUAL Issue 201106 Rev. Model: AFD630IX Ref1106S013V0 (5) Take out the 3 hole plugs on the other side of the cabinet. Turn the middle hinge by 180 degrees and install it on the other side of the cabinet. Attach the 3 screws removed in step 1.

  • Page 16: Removal Of Freezing Air-Duct

    SERVICE MANUAL Issue 201106 Rev. Model: AFD630IX Ref1106S013V0 (1) Take out the accessories in the fridge storage compartment which may interfere with the removal of the air-duct (including shelves, large and small crispers, air-duct decoration strips) (fig. ①); (2) Detach the 2 screws in the upper part of the air-duct (fig. ②);...

  • Page 17: Chapter 4 Control And Display System

    SERVICE MANUAL Issue 201106 Rev. Model: AFD630IX Ref1106S013V0 Chapter 4 Control and display system 4-1. Control and display panel Control panel A1 Switch on/off the fridge storage compartment Fridge compartment indicating icon A2 Menu key Freezer compartment indicating icon A3 Temperature up...
  • Page 18 SERVICE MANUAL Issue 201106 Rev. Model: AFD630IX Ref1106S013V0 compartment will become the ex-factory settings “5” and “-18” respectively. The brightness of *** icon will decrease to half automatically when the refrigerator is not being operated. ■ Fridge storage temperature setup Press key A2 until icon D flashes.

  • Page 19: Sensor Distribution And Malfunction Codes

    SERVICE MANUAL Issue 201106 Rev. Model: AFD630IX Ref1106S013V0 When the fridge storage compartment door is open for more than 3 minutes, icon G will flash and the buzzer will give out 3 beeps every 30 seconds. If you close the door, the alarm will be silenced and icon G will go off.

  • Page 20: Graphic Display Of The Sensor Location

    SERVICE MANUAL Issue 201106 Rev. Model: AFD630IX Ref1106S013V0 Malfunction of Display panel communication between the display panel and the power board Malfunction of the fan Display panel 4-2-3 Graphic display of the sensor location Ambient temperature sensor Fridge storage temperature sensor...

  • Page 21: Chapter 5 Control Principle Of Electronic Component

    SERVICE MANUAL Issue 201106 Rev. Model: AFD630IX Ref1106S013V0 continuously until the temperature sensed by the sensor reaches 7℃. In the (FORCED DEFROSTING MODE), the door display panel displays T2 T2, the refrigerator conducts forced defrosting, the compressor and the fan are turned off, and the defrosting heating wire is turned on.

  • Page 22: Chapter 6 System Flow Principle

    SERVICE MANUAL Issue 201106 Rev. Model: AFD630IX Ref1106S013V0 open-circuit). In this case, it will exit the defrosting state after 30 minutes. Chapter 6 System flow principle 6-1. Refrigeration flow chart Principle diagram and description of the refrigeration cycle The refrigerant is compressed in the compressor, from there, it enters the dry filter, de-dewing tube, and the condenser, and goes into the evaporator after being throttled and decompressed in the capillary tube.

  • Page 23: Air Flow Chart

    6-3 Air Flow Chart Schematic drawing and description of air circulation in the refrigerator air-duct...
  • Page 24 SERVICE MANUAL Issue 201106 Rev. Model: AFD630IX Ref1106S013V0...

  • Page 25: Diagram Of Icemaker Waterway

    SERVICE MANUAL Issue 201106 Rev. Model: AFD630IX Ref1106S013V0 6-4 Diagram of icemaker waterway Tap water w a t e r Automatic Water pipe icemaker Water flow Water valve Specification for waterway parameters Description Spe. Supplier From water source to water valve ￠5mm PP...

  • Page 26: Chapter 7 Circuit Diagram

    SERVICE MANUAL Issue 201106 Rev. Model: AFD630IX Ref1106S013V0 Chapter 7 Circuit diagram 7-1. Main control PCB diagram C ontrol cable for door P ow er board LE D Lam p C O N 2 D isplay panel C O N 3...

  • Page 27: Main Control Pcb Diagram

    SERVICE MANUAL Issue 201106 Rev. Model: AFD630IX Ref1106S013V0 7-2. Main control PCB diagram Main control board of AFD refrigerator has 4 connectors in total. CN1 connector is used to connect the sensor and door switch, which is listed as below from left to right：...

  • Page 28: Instruction Of Internal Pcb

    SERVICE MANUAL Issue 201106 Rev. Model: AFD630IX Ref1106S013V0 7-3 Instruction of Internal PCB 7-3-1 View of Power Supplier PCB CON3 CON2 Port Definitions: CON2 +12V +12V EMPTY LAMP+ LAMP- CON3 COMP W-HTR ICE VALVE...

  • Page 29: Master View Of Display Pcb

    SERVICE MANUAL Issue 201106 Rev. Model: AFD630IX Ref1106S013V0 7-3-2 Master View of Display PCB Flash SD card holder LED1 USB port CN10 Port Definitions: CN5-1 CN5-2 CN5-3 CN5-4 CN5-5 CN5-6 CN5-7 CN5-8 CN5-9 CN5-10 +12V +12V Communic Fridge Ice Making...

  • Page 30: Chapter 8 Trouble Shooting

    SERVICE MANUAL Issue 201106 Rev. Model: AFD630IX Ref1106S013V0 Chapter 8 Trouble shooting 8-1. Common problems and solutions 8-1-1 Symptom: food in the fridge storage compartment is frozen Check: 1) Verify that the temperature in the fridge storage compartment is too low and the food is frozen there;...

  • Page 31: Symptom: Neither Displaying Nor Starting When Powering On

    SERVICE MANUAL Issue 201106 Rev. Model: AFD630IX Ref1106S013V0 2) Measure the resistance of the heating wire with a multimeter. It should be around 345Ω. 3) Measure the resistance of the defrosting fuse. If it is zero, the fuse is OK. If it is infinite, the fuse is malfunctioning.

  • Page 32: Common Problems With Icemaker System

    SERVICE MANUAL Issue 201106 Rev. Model: AFD630IX Ref1106S013V0 8-1-6 Common problems with icemaker system 1. Water inflow adjustment Adjust set button. When inputting water time is flashing (input water time is only available when icemaker is open), press OK button for time adjustment. Just press up and down button to adjust the time.

  • Page 33: Examination And Solutions For Other Problems

    SERVICE MANUAL Issue 201106 Rev. Model: AFD630IX Ref1106S013V0 8-2 Examination and Solutions for Other Problems Problems Causes Solutions Water/moisture/frost in the refrigerator  Hot and moist climate.  Accumulation frost moisture Moisture accumulates  The door is not closed accelerate in such climate.
  • Page 34 SERVICE MANUAL Issue 201106 Rev. Model: AFD630IX Ref1106S013V0 fridge/freezer storage running time of the refrigerator in order to compartment is dirty, maintain desired temperature. worn, cracked or mismatched.  Clean the condenser.  The condenser is dirty. Too high temperature ...

  • Page 35: Checking Flow Chart

    SERVICE MANUAL Issue 201106 Rev. Model: AFD630IX Ref1106S013V0 8-3. Checking flow chart Com pressor doesn’ t start W hether lighting and display system is Trouble of lighting and display system normal W hether the grade of therm ostat is Adjust the grade according to fact...
  • Page 36 SERVICE MANUAL Issue 201106 Rev. Model: AFD630IX Ref1106S013V0 Sincere forever Haier Group Haier Industrial Park, No.1, Haier Road 266101, Qingdao, China http://www.haier.com...
