User Manual [P2 hexaline]
WELCOME
Dear User,
Thank you for choosing Portman P2 hexaline™ – the original product with a registered design.
We are proud to deliver you the highest quality, greatest design and real passion with our product.
Each fixture in the Portman portfolio is different, yet all of them ensure you the best performance to support your
creativity.
FOR YOUR SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY BEFORE YOUR INITIAL
START-UP!
Please remember:
any updates on this document,
current products' libraries,
current products' firmware,
RMA procedure
can be found on our webpage in the support area:
www.support.portmanlights.com
SAFETY INFORMATION
WARNING! This product is for professional use only! It is not for household use.
This product presents a risk of lethal or severe injury due to heat, electric shock, fire or falls.
Intense and flashing light could trigger epileptic seizures. Read this manual before your
initial start-up and follow the safety information in this manual and engraved on the fixture.
Every person involved in the installation, service and maintenance of this device must be
qualified and have experience in working with stage lighting fixtures.
Before your initial start-up, please make sure that there is no damage caused by transportation.
https://support.portmanlights.com/portal/en/kb/articles/user-manual-p2-hexaline-10-5-2024

Advertisement

loading
Need help?

Need help?

Do you have a question about the P2 hexaline and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PORTMAN P2 hexaline

Summary of Contents for PORTMAN P2 hexaline

  • Page 1 Thank you for choosing Portman P2 hexaline™ – the original product with a registered design. We are proud to deliver you the highest quality, greatest design and real passion with our product. Each fixture in the Portman portfolio is different, yet all of them ensure you the best performance to support your creativity.
  • Page 2 Should there be any, consult your dealer and do not use the device. Please consider that damages caused by manual modifications to the device are not subject to warranty. CAUTION! Keep this device away from rain and moisture! CAUTION! Be careful with your operations! With a dangerous voltage you can suffer an electrical shock when touching the fixture and wires! CAUTION! When in operation the fixture’s surface becomes hot.

  • Page 3: Technical Specification

    • Provide advance notice that a flashlight is in use. • Avoid long cycles of rapid flashing light. • Always use safety glasses to protect your eyes when opening the front cover. TECHNICAL SPECIFICATION 1910 x 205 x 170mm   dimensions (75.2 x 8.07 x 6.70 in)  ...

  • Page 4: Product Overview

    WDMX module optional Appliance class Class I IP rating IP20 declarations of UKCA conformity PRODUCT OVERVIEW Dimension Pixel order Back view https://support.portmanlights.com/portal/en/kb/articles/user-manual-p2-hexaline-10-5-2024...

  • Page 5: Optional Accessories (Not Included)

    Kit content (what’s in the box) 1 x Portman P2 hexaline 1 x base 1 x height adaptor 1 x hanging adaptor 3 x spigot with cotters 1 x spare bulb 1 x AC power wire (powerCON TRUE1) 1 x USER MANUAL...

  • Page 6: Installation

    Luminaire must be powered with 200- 240V and 50/60Hz. This fixture will automatically detect the alternating current frequency. To turn on the fixture, simply plug in the powerCON TRUE1 and set the power switch to “ON”. Use only high quality 3 x 2.5 mm2 or larger mains power cords. Inspect all the power feed cables for damages before use.

  • Page 7: Lamp And Fuse Replacement

    REMEMBER! Always use attached spigots and cotters to install or hang the fixture using base, height adaptor or hanging adaptor. REMEMBER! Never use more than one unit on base or on hanging clamp without additional safety support. To change the angle of the fixture’s hinge, use the rounded spigot. Always hold both parts of the fixture! pull the rounded spigot, change the position, lock the spigot in the right hole,...

  • Page 8: Operation Modes

    The Portman P2 hexaline can work in three operation modes: Wired DMX mode, Wireless DMX mode (if the WDMX card is installed) and standalone mode. You can link The P2 hexaline to a DMX controller using a 5 or 3 pin DMX wire, or Wireless Solution Sweden hardware (if WDMX card is installed).
  • Page 9 RDM (Remote Device Management) is an enhancement of the DMX 512 protocol and allows bi-directional communication between DMX consoles and fixtures. It works simultaneously with DMX 512 and on the same lines and wires. RDM is not affecting non-RDM devices in a line however, non-RDM devices can disrupt communication with the console.
  • Page 10 Menu map Main section Level Desdcription ADDRESS 1-505 Sets up the DMX start address Changes the DMX input to wired (default). In this mode WIRED fixture is receiving DMX signal from the DMX IN 5 pin XLR socket. DMX INPUT Changes the DMX input to wireless.
  • Page 11 Shows the fixture’s actual FIRMARE VERSION firmware version Unlinks all linked Wireless UNPAIR WDMX Solution Sweden WDMX transmitters. Controls the intensity of all MANUAL CONTROL ALL CHAN: channels at once. CHAN. 1 0-100% CHAN. 2 0-100% CHAN. 3 0-100% Individually controls the intensity of selected channel CHAN.
  • Page 12 © 2016-2024 Portman Lights Sp. z o. o. All rights reserved. The information and specifications are subject to change without notice. Portman Lights Sp. z o. o. disclaims liability for any injury, damage, direct or indirect loss, consequential or economic loss or any other loss occasioned by the use of, inability to use or reliance on the information contained in this user manual.
