SUPPORT PORTAL - Portman® Lights
User Manual [P3 EVO]
WELCOME
Dear User,
Thank you for choosing Portman P3 EVO™ – the original product with a registered design.
We are proud to deliver you the highest quality, greatest design and real passion with our product.
Each fixture in the Portman portfolio is different, yet all of them ensure you the best performance to support your creativity.
FOR YOUR SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY BEFORE YOUR INITIAL START-UP!
Please remember:
any updates on this document,
current products' libraries,
current products' firmware,
RMA procedure
can be found on our webpage in the support area:
www.support.portmanlights.com
SAFETY INFORMATION
WARNING! This product is for professional use only! It is not for household use.
This product presents a risk of lethal or severe injury due to heat, electric shock, fire or falls.
Intense and flashing light could trigger epileptic seizures. Read this manual before your
initial start-up and follow the safety information in this manual and engraved on the fixture.
Every person involved in the installation, service and maintenance of this device must be
qualified and have experience in working with stage lighting fixtures.
Before your initial start-up, please make sure that there is no damage caused by transportation.
Should there be any, consult your dealer and do not use the device.
Please consider that damages caused by manual modifications to the device are not subject to warranty.
CAUTION! Keep this device away from rain and moisture!
CAUTION! Be careful with your operations! With a dangerous voltage you can
suffer an electrical shock when touching the fixture and wires!
CAUTION! When in operation the fixture's surface becomes hot. Allow the device
to cool down for approximately 30 minutes before any maintenance or service.
Keep a minimum 0,2-meter distance from flammable materials to the fixture.
CAUTION! Avoid looking directly into the light source (meant especially for epileptics)!
CAUTION! Unplug the mains lead before opening the housing.
Protection against electrical shock
• Disconnect the fixture from AC power when not in use.
• Disconnect the fixture from AC power before any maintenance or service.
• Do not remove the rear cover. There are no user-serviceable parts inside.
• Always ground the fixture electrically.
• Use only the wires attached to the kit. If the power cable shows any sign of damage do not use it!
• Use only a source of AC power that complies with local building and electrical codes and has both overload and ground-fault protection.
• Do not expose the fixture to rain or moisture.
Protection against burns and fire
• Never operate when the fixture is damaged or some part is missing.
https://support.portmanlights.com/portal/en/kb/articles/user-manual-p3-evo
Advertisement
Related Manuals for PORTMAN P3 EVO
Summary of Contents for PORTMAN P3 EVO
- Page 1 We are proud to deliver you the highest quality, greatest design and real passion with our product. Each fixture in the Portman portfolio is different, yet all of them ensure you the best performance to support your creativity. FOR YOUR SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY BEFORE YOUR INITIAL START-UP!
-
Page 2: Technical Specification
2 x 5-PIN DMX (inlet and outlet) 1 x EtherCON connectors 1 x AC powerCON TRUE1 (inlet and outlet) 1 x SMA (WDMX antenna) *optional built-in drivers Portman Colour Feedback System™ other features built-in macros WDMX module optional Appliance class Class I ... -
Page 3: Product Overview
PRODUCT OVERVIEW Dimension Pixel order Back view https://support.portmanlights.com/portal/en/kb/articles/user-manual-p3-evo... -
Page 4: Preparation For Use
Kit content (what’s in the box) • 1x P3 EVO™ • 1x AC power wire 2m • 1x User Manual Optional accessories (not included) • W-DMX module • flight case PREPARATION FOR USE AC power connection Luminaire must be powered with 100-240V and 50/60Hz. This fixture will automatically detect the alternating current frequency. To turn on the fixture, simply plug in the powerCON TRUE1 and set the power switch to “ON”. - Page 5 You can aim the fixture to any position that you want except towards the rigging structure. The main part can spin 3600 in the yoke. Remember not to let power and DMX wires touch the surface of the fixture. Always keep safe distance from the closest object. REMEMBER! Always secure the hung fixture with safety wire! CAUTION! Incorrect installation may result in the device falling and may damage it or cause damage to other objects! REMEMBER! Always secure hanged fixture with safety wire!
- Page 6 Receives control signal from Master WDMX connected Reacts to WDMX Stays in Master Mode unit Gets back to the last Macro or Manual Receives control signal from Master DMX disconnected Keeps last DMX frame setting unit Gets back to the last Macro or Manual Receives control signal from Master After power reset All values default...
- Page 7 The fixture is in SLAVE mode and there is MASTER signal detected. There is no DMX signal. Portman Colour Feedback System™ works also when you operate the menu. When you navigate through the menu the buttons change their colours. In the first level of the menu, the buttons are blue, the second level of the menu is cyan.
- Page 8 LOGARITHMIC FLICKER MODE MODE 1 (2.8kHz) Changes the frequency of the LED driving signals. MODE 2 (5.4kHz) MODE 3 (10kHz) DISPLAY AND DP BRIGHTNESS Changes the parameters of display and buttons highlight. ...
- Page 9 MACRO SPEED MACRO SPEED Sets the macro speed MACRO 0 – 100% BRIGHTNESS Sets macro intensity value INTENSITY PHOTOMETRICS Thank you for buying original products! By buying original products you buy the real quality but also support creativity and progress in the industry.
- Page 10 © 2016-2024 Portman Lights Sp. z o. o. All rights reserved. The information and specifications are subject to change without notice. Portman Lights Sp. z o. o. disclaims liability for any injury, damage, direct or indirect loss, consequential or economic loss or any other loss occasioned by the use of, inability to use or reliance on the information contained in this user manual.
