  • Page 1 NI-9436 Getting Started 2024-11-01...

  • Page 2: Table Of Contents

    NI 9436 Connection Guidelines ........

  • Page 3: Before You Begin

    Read the NI 9436 Safety, Environmental, and Regulatory Information and complete the software and hardware installation procedures in your chassis documentation. © 2016 National Instruments Corporation. All rights reserved. Refer to the <National Instruments>\_Legal Information directory for information about NI copyright, patents, trademarks, warranties, product warnings, and export compliance.

  • Page 4: Safety Guidelines For Hazardous Voltages

    NI-9436 Getting Started Continuous 250 Vrms, Measurement Category II Withstand 1,500 Vrms, verified by a 5 s dielectric withstand test Channel-to-earth ground Continuous 250 Vrms, Measurement Category II Withstand 3,000 Vrms, verified by a 5 s dielectric withstand test Safety Guidelines for Hazardous Voltages Caution Ensure that hazardous voltage wiring is performed only by qualified personnel adhering to local electrical standards.

  • Page 5: Special Conditions For Marine Applications

    EMC performance is attained. Preparing the Environment Ensure that the environment in which you are using the NI 9436 meets the following specifications. Operating temperature (IEC 60068-2-1, IEC 60068-2-2) -40 °C to 70 °C...

  • Page 6: Ni 9436 Pinout

    NI-9436 Getting Started Pollution Degree Maximum altitude 5,000 m Indoor use only. Note Refer to the NI 9436 Specifications on ni.com/manuals complete specifications. NI 9436 Pinout DI0a DI0b DI1a DI1b DI2a DI2b DI3a DI3b DI4a DI4b DI5a DI5b DI6a DI6b...

  • Page 7: Sourcing-Output Connections

    Sinking-Output NI 9436 Device The NI 9436 channel registers as ON when the sinking-output device drives the input within the input ON range. If no device is connected to DI, the channel registers as OFF. Sourcing-Output Connections You can connect 2- and 3-wire sourcing-output devices to the NI 9436.

  • Page 8: Ni 9436 Connection Guidelines

    Load NI-9265 NI 9436 Connection Guidelines Make sure that devices you connect to the NI 9436 are compatible with the module specifications. You must use 2-wire ferrules to create a secure connection when connecting more than one wire to a single terminal on the NI 9436.

  • Page 9: Installing The Ni-9939

    2. Route the wire through the NI-9939 opening and remove slack from the wiring. 3. Install the Backshell Top Enclosure (1) to the Backshell Bottom Enclosure (3). 4. Place the Label (5) in the Label Carrier (4) and attach onto the backshell. Installing the NI-9939 Using the Cable Retainer © National Instruments...

  • Page 10: High-Vibration Application Connections

    High-Vibration Application Connections If your application is subject to high vibration, NI recommends that you follow these guidelines to protect connections to the NI 9436: • Use ferrules to terminate wires to the detachable connector. • Use the NI 9939 connector backshell kit.

  • Page 11: Ni Services

    NI product. Product registration facilitates technical support and ensures that you receive important information updates from NI corporate headquarters is located at 11500 N Mopac Expwy, Austin, TX, 78759-3504, USA. © National Instruments © 2024 National Instruments Corporation.
