- Page 1 Wavecom Wavecom Direct Thermal Printer User Manual...
-
Page 2: Operating The Printer
TT040-50BB Printer User Manual Wavecom Wavecom Direct Thermal Printer The Wavecom Direct Thermal printer is powered by a Lithium Ion Battery and features Bluetooth connectivity. Operating the Printer Printer Diagrams Charging the Printer Loading Print Ribbon Loading Tags Printer Functions... - Page 3 TT040-50BB Printer User Manual Wavecom Printer Diagrams Media Cover LCD Screen Media Cover Peeler Module Release Button Interface Buttons & LED Indicators NFC touch point MicroSD card socket Charging Port & USB-C Port Battery Opening Clasp Lithium Ion Battery Belt Clip Loops Status Icons Date &...
-
Page 4: Charging The Printer
TT040-50BB Printer User Manual Wavecom Charging the Printer The printer battery will take approximately four to five hours to fully charge. Do not leave the printer unattended while charging. Open the interface cover on the Plug the power cable into the power... - Page 5 TT040-50BB Printer User Manual Wavecom Loading Tags Open the printer top cover by Separate the Label Holders by gently pressing the green release button, pulling them in opposite directions and lifting open the cover. Insert the media between the Pull the tags through so that it they label holders as shown.
-
Page 6: Button Functions
TT040-50BB Printer User Manual Wavecom Printer Functions Button Functions Button Description Enter the Menu screen List-ul Menu Button Variable function (see bottom left of LCD screen) Feed a single tag & align your tag roll Feed Button Pause the current print job... -
Page 7: Status Led
TT040-50BB Printer User Manual Wavecom Status LED Status LED Description Flashing Green Printer is paused, or is receiving data from another device Solid Amber Printer is clearing data Solid Red Printer head is open; Cutter Error Flashing Red Printer Error... -
Page 8: Settings Menu
TT040-50BB Printer User Manual Wavecom Settings Menu Menu Option Second Level Description Default Value Menu Option Changing these settings will be overwritten when printing via WinPATS. Setting We recommend leaving these settings at their default values. Set the media sensor type and calibrate the selected sensor... - Page 9 Check print head status and to set the Disabled Maintenance settings for print head care. Key Sounds Toggle Printer key sounds Access TSC contact information for technical support. We Contact Us recommend contacting Wavecom first as we can help diagnose issues involving both WinPATS and the printer.
-
Page 10: Troubleshooting Procedures
TT040-50BB Printer User Manual Wavecom Troubleshooting Issue Possible Causes Troubleshooting Procedures Remove and reinstall the battery. The battery is not properly installed. Switch the printer on. No power The battery out of power. Charge the battery. The battery is damaged. -
Page 11: Specifications
Dimensions 117mm (W) x 173mm (H) x 79mm (D); 745g Wavecom Direct Thermal Tags The Wavecom Direct Thermal Printer must be used with direct thermal tags. These are available in rolls of 150 tags. Order Information: Direct Thermal Tags (White) -
Page 12: Maintenance
TT040-50BB Printer User Manual Wavecom Maintenance This section explains the methods to clean and maintain your printer. Your printer may accumulate residues (media dust, adhesives, etc.) as a by-product of normal printing. To maintain the best printing quality, you should remove these residues by cleaning the printer periodically. -
Page 13: Platen Roller
TT040-50BB Printer User Manual Wavecom Cleaning Processes Printer Method Cleaning Interval Component Print Head 1. Always turn off the printer before cleaning the The Print Head should print head be cleaned each time a roll of tags is replaced. 2. Allow the print head to cool for at least one minute before beginning cleaning 3. -
Page 14: Safety Information
TT040-50BB Printer User Manual Wavecom Safety Information Important safety instructions: Read all of these instructions and keep them for later use. Follow all warnings and instructions on the product. Disconnect the power plug from the AC outlet before cleaning or if a fault occurs. - Page 15 TT040-50BB Printer User Manual Wavecom Disclaimer – E&OE All specifications may be subject to be change by Wavecom Pty. Ltd. without prior notice. Updated Specifications & Model changes may be found on the Wavecom website: - www.wavecom.com.au At the time of developing this manual, all care and consideration for accuracy has been implemented.
-
Page 16: Purchase Information
TT040-50BB Printer User Manual Wavecom Purchase Information Date of Purchase Sold By Wavecom Instruments Pty. Ltd. www.wavecom.com.au 257 Grange Road, Findon, South Australia, Australia 5023 service@wavecom.com.au (+61) 08 8243 3500 www.winpats.app (+64) 0800 164 888...
