Abode Xcite AW3119 Quick Start Manual

Fitting type:
Inset
Min. base unit (bowl, tap & overflow only):
•
Packaged size L x W x D: 1030 x 610 x 285mm
•
Supplied boxed or sleeved: Boxed
•
Boxed weight: 22.26 kg
•
Sink only weight: 17.18 kg
•
Included parts:
1 AX1052 (m)
X
2 x 90mm std bsw, std o/flow &
pipework
Recommended accessories:
1 AX2502 or AX2510
X
High & Dry drainer rack - Lime green
and grey
Materials and workmanship warranty summary:
Sink materials & workmanship 10 years.
•
Waste kits 1 year.
•
Connecting pipework 1 year.
•
14/02/2014 -
This sheet is a summary of the product information
full details are available on request, errors & omissions excepted, details
are subject to change without prior notification.
1.5 Bowl & drainer
Sink handing:
600 mm
1 AX1033 (m)
X
Composite inset fixing clips x 8
1 AX2500
X
Silicone drainer mat 320 x 320mm
Care instructions:
Clean the products regularly using soapy water and a non
•
abrasive cloth, regular cleaning will prevent the build up
of lime scale and dirt.
Avoid contact with corrosive or abrasive substances.
•
After cleaning rinse thoroughly with clean water then dry.
•
For more detail see supplied booklet or www.abode.eu
•
Xcite
Reversible
Durable matt finish granite composite construction throughout
•
One a half bowl design for maximum practicality
•
Softened square edges for a sharp but easy clean look
•
Reversible drainer position for maximum flexibility
•
Stainless steel wastes and pipework included
•
Taphole provision to accept Swich filter diverter? Yes, on sink deck
•
1 AX4025 (m)
X
fitting instructions for AX1052 Fitting & care instructions & data sheet
plumbing kit
1 AX3011
X
Bowl mat 274 x 334 R5 Glass Chopping Board 500x280mm
www.abode.eu
Finish style:
Black Granite
1 AX4004 (m)
X
- coloured inset
1 AX2017
X
Glass Chopping Board 500x280mm
(475) - Black Gloss
All accessories can be
purchased directly from
www.abode-shop.co.uk
or phone 01226 283434
EN13310:2003
Domestic kitchen sink made of Granite & Acrylic composite
Cleanability: Pass
Load resistance: NPD / NA
(applies to wall hung sinks only)
Durability: Pass
For more information see www.abode.eu/ce.html
Product order code: (AW3119)
1 AX2023
X
(475) - White Gloss
