PROCET PT-PSE118GR-OT 30W User Manual

Overview
* The product supports direct AC power supply.
* With a wide temperature design, it can operate in environments ranging from -40°C to 65°C, making it suitable for
outdoor use. It can achieve full-load startup at -40°C.
* The AC port provides surge protection of up to 6KV (common mode) and 4KV (differential mode), ensuring safe and
stable power delivery.
* It complies with the EN55032 3m EMC test standard, offering high electromagnetic interference resistance.
* The product supports full gigabit ports and is compatible with 10/100/1000Mbps network speeds.
* The PT-PSE118GR-OT-10 and PT-PSE118GRN-OT-10 models support transmission speeds of up to 10Gbps.
* Aluminum Alloy shell, IP67 waterproof protect rated, Waterproof metal cable glands, Excellent corrosion resistance.
Appearance
Side View
22±1mm 45±1mm
211±1mm
Metal Glands Component
Specification
AC Input
Power Pins
Output
Data Speed
Operating Humidity
Operating Temp.
IP Rating
Operating Altitude
Network Protocols
Dimensions/Weight
User Manual for PT-PSE118GR-OT_30W
42
±1mm
PT-PSE118GR-OT_30W
100-240Vac 1.5A(Max)
4,5(+)/7,8(-) or 3,6(+)/1,2(-)
55Vdc 0.55A(Max) 30W
10/100/1000Mbps/2.5/5/10Gbps
20%-80%,non-condensation
-40℃ to 65℃
IP67
Up to 2000m
IEEE802.3i/IEEE802.3u/IEEE802.3ab/IEEE802.3z
211mm X 101mm X 42mm/625g
Front View
101±1mm
AC Power Input Port
Embedded in the body
LAN Input Port
Embedded in the body
PoE Output Port
Embedded in the body
