PROCET PT-PSE118GBR-OT User Manual

Overview
* The product supports direct AC power supply.
* With a wide temperature design, it can operate in environments ranging from -40°C to 65°C, making it suitable for
outdoor use. It can achieve full-load startup at -40°C.
* The PoE and AC ports provide surge protection of up to 6KV (common mode), ensuring safe and stable power delivery.
* It complies with the EN55032 3m EMC test standard, offering high electromagnetic interference resistance.
* The product supports full gigabit ports and is compatible with 10/100/1000Mbps network speeds.
* The PT-PSE118GBR-OT-10 and PT-PSE118GBRN-OT-10 models support transmission speeds of up to 10Gbps.
Appearance
Side View
22±1mm 45±1mm
211±1mm
Metal Glands Component
Specification
AC Input
Power Pins
Output
Data Rates
Operating Humidity
Operating Temp.
IP Rating
Operating Altitude
PoE Surge Protection
AC Surge Protection
Dimensions/Weight
User Manual for PT-PSE118GBR-OT_60W
42
±1mm
100-240Vac 1.5A(Max)
4,5(+)/7,8(-) 3,6(+)/1,2(-)
55Vdc 1.1A(Max) 60W @50℃
55Vdc 0.82A 45W @55℃
55Vdc 0.55A 30W @65℃
10/100/1000Mbps/2.5/5/10Gbps
20%-80%,non-condensation
-40℃ to 65℃
IP67
Up to 2000m
Protected line: 1,2,3,4,5,6,7,8
Common mode surge protection(10/700us): 6KV
Differential mode surge protection (10/700us): 1.5KV
Line-Earth 1.2/50us (8/20us): 6KV
Line-Line 1.2/50us (8/20us): 4KV
211mm X 101mm X 42mm/628g
Front View
101±1mm
AC Power Input Port
Embedded in the body
LAN Input Port
Embedded in the body
PoE Output Port
Embedded in the body
