U-Line H-5439 Manual

H-5439, H-5440
STRADDLE STACKER
DESCRIPTION
Mast Height (Lowered)
Mast Height (Raised)
Lifting Height, Max.
Lifting Height, Min.
Weight Capacity, Max.
Overall Length
Overall Width
Fork Size – Length
Fork Size – Width
Forks Adjustable Width (Inside Dim.)
Forks Adjustable Width (Outside Dim.)
Straddle Legs (Inside Dim.)
Straddle Legs (Outside Dim.)
Straddle Leg Height
1. Operator should read all warning signs and
instructions here and on the stacker before use.
2. Do not operate stacker unless you are familiar with it
and have been trained or authorized to do so.
3. This is a manual push truck. Operator must be able
to safely move, control and stop a fully-loaded unit
by themselves.
4. Do not use on uneven ground or in a dangerous
environment.
5. Do not operate unit on inclines.
6. Do not lift people with the stacker.
7. When forks are in motion, no one should stand
PAGE 1 OF 12
1-800-295-5510
uline.com
TECHNICAL DATA
H-5439
77¾"
80"
63"
SAFETY
under the forks or pass below the forks.
8. Do not move the stacker unless the forks are 12 inches
or less off the ground.
9. Keep a two-foot distance between the stacker and
any person not operating the stacker.
10. The weight of goods should be evenly distributed
between the two forks.
11. Do not load over the maximum capacity.
12. Keep the forks in the lowest position when not in use.
13. Locking caster is designed to help prevent rolling
when unit is not in use. It is not designed to slow
down or stop the unit.
Para en Español, vea páginas 5-8.
Pour le français, consulter les pages 9-12.
H-5440
91½"
160"
137"
2 ⁄ "
1
8
2,200 LBS.
70"
43¾ - 54¾"
42"
4"
1/2 - 20"
8½ - 28"
36½ - 48½"
43¾ - 54¾"
5⁄"
0225 IH-5439
