  • Page 1 NEWALL MEASUREMENT SYSTEMS LTD HEAD OFFICE Newall Measurement Systems Ltd. Technology Gateway, Cornwall Road South Wigston Leicester LE18 4XH United Kingdom Telephone: +44 (0)116 264 2730 Facsimile: +44 (0)116 264 2731 Email: sales@newall.co.uk Web: www.newall.co.uk Newall Electronics, Inc. 1778 Dividend Drive...

  • Page 2: Table Of Contents

    NEWALL MEASUREMENT SYSTEMS LTD Digital Readout CONTENTS 1.0 INTRODUCTION EMC and Low Voltage Compliance Technical Specifications 2.0 INSTALLATION Mounting Power Supply Connections Switching On 3.0 SET-UP Machine Type Sleep/Datahold Encoder Type Resolution Direction Radius/Diameter Linear Error Compensation Calculating Linear Error Compensation 4.0 USER INSTRUCTIONS...
  • Page 3 Notes Newall Measurement Systems...

  • Page 4: Introduction

    Introduction 1.0 Introduction 1.1 EMC AND LOW VOLTAGE COMPLIANCE The B60 Readout conforms to the relevant European standards for electromagnetic compatibility and low voltage directive as detailed below. BS EN 61000-6-4: Electromagnetic compatibility. Generic Emission Standard - Industrial Environment BS EN 61000-6-2: Electromagnetic compatibility.

  • Page 5: Installation

    This symbol appears on the equipment and refers to the safety aspects detailed below. 2.1 MOUNTING B60 is supplied with a fixing kit consisting of a M10 stud, nut and washers. Figure 1.2b shows use of this in conjunction with a mounting arm.

  • Page 6: Connections

    ] key. The B60 is configured as a generic Digital Readout in either a 2 or 3 axes version. As such it must be con- figured for the machine type to which it is to be operated on if the benefits of the machine specific functions are to be had.

  • Page 7: Encoder Type

    SLEEP ENCODER TYPE SPHEROSYN MICROSYN RESOLUTION (SPHEROSYN) - 5µm / 10µm / 20µm / 50µm (MICROSYN) - 1µm / 2µm / 5µm / 10µm READINGS RADIUS DIAMETER LINEAR ERROR COMPENSATION USER DEFINABLE Table 2 - Menu Options Newall Measurement Systems...

  • Page 8: Machine Type

    Set-Up 3.1 MACHINE TYPE The B60 can be configured to act in Lathe, Mill or Basic mode. See Section 6.0 for details on machine specific functions. In Set-Up press the [ abs/inc ] key until the [ A ] axis shows the legend “TYPE”. The [ A ] axis will show the current setting.
  • Page 9 M M o o u u n n t t i i n n g g A A r r r r a a n n g g e e m m e e n n t t s s Newall Measurement Systems...
  • Page 10 F F i i g g u u r r e e 1 1 . . 3 3 C C o o n n n n e e c c t t i i o o n n D D i i a a g g r r a a m m Newall Measurement Systems...

  • Page 11: Radius/Diameter

    ] or [ A ], switches between radius and diameter readings for that axis. When the B60 is displaying the choices you wish to use, press [ abs/inc ] to continue to the next option. 3.7 LINEAR ERROR COMPENSATION This option allows you to apply a constant correction factor to all measurements displayed. This factor is expressed in parts per million (PPM).

  • Page 12: User Instructions

    User Instructions 4.0 User Instructions 4.1 OPTIONS B60 is available in two either 2 or 3 axes display options Figure 1.4 shows the layout of the various keypad configurations. 4.2 USING THE KEYPAD Figure 1.4 shows the layout of the keypad. The keys are used as follows:...
  • Page 13 User Instructions B60 2 Axis B60 3 Axis F F i i g g u u r r e e 1 1 . . 4 4 K K e e y y p p a a d d L L a a y y o o u u t t...

  • Page 14: Standard Functions

    As an alternative to resetting the axes, you can enter the coordinates relative to the current incremental position. Each time you switch to incremental mode, the B60 display will show the position relative to the last reset position while in the incremental mode.

  • Page 15: Digifind

    Each time the B60 is powered up the cabinet will automatically use Digifind to compensate for any axis movement of up to ±6mm (±0.25”) for Spherosyn and ±2.5mm(±0.098”) for Microsyn.

  • Page 16: Inch/Millimetre

    While the B60 has been set to datahold, the keypad will not function and the displays will be blank. If the machine axis is moved, "D D I I S S P P L L A A C C D D " (displaced) will appear in the display window. The B60 will continue to record all encoder movement and will update the display once datahold is cancelled.

  • Page 17: Functions

    6.1 B60 MILL FUNCTION The B60 offers Pitch Circle Diameter (PCD) in addition to the Standard functions. PCD is also known as “Bolt Hole Circle”. The convention for angular position is that the 0 degree position is at 3 o’clock and positive angles are measured anti-clockwise.

  • Page 18: B60 Lathe Function

    [ > ] to move to the next input “C C ” for centre position. All subsequent inputs are as the two axis version. 6.2 B60 LATHE FUNCTION N N o o t t e e : : The conventional method of setting a lathe is to set the A...
  • Page 19 A axis display. e.g. [ 0 ][ ent ]. The A and A keys are inactive in the tool set mode. Press to exit tool set mode. Newall Measurement Systems...

  • Page 20: Troubleshooting

    〈 Check the power lead is not damaged. unit is switched on. 〈 Check the selector switch on the B60 is set to accept the correct power supply voltage. 〈 Check the fuse. Note that if the fuse has blown, this suggests a fault with the power source which must be corrected before the fuse is replaced.
