- Page 1 STONE RAKE GSR 32300 /GSR44400 / GSR63300 /GSR 87400 User manual and spare parts...
-
Page 2: Product Information
If you would like to learn more about our products, you can visit our website at www.underhaug.no or contact us by phone or email. Our goal is for you to be a satisfied Globus customer. To achieve this, we focus on quality and user- friendly products. -
Page 3: Declaration Of Conformity
DECLARATION OF CONFORMITY Producer: Underhaug AS Address: Torlandsveien 3 4365 Nærbø N-NORWAY We hereby declare under our own responsibility that the following product: Type: Globus Stone rake GSR 32300 /GSR44400 / GSR63300 /GSR 87400 Serial No.: Year of Manufacture: 2024->... -
Page 4: Table Of Contents
CONTENT Introduction Side Welcome as customer Product information Declaration of conformity Safety User Manual Caution Crushing hazard Safety labeling Product Information Intended use Technical data Additional equipment Assembly and Connection Assembly Adjustment of the PTO-shaft Connection User tips User tips Maintenance Retightening Gearbox... -
Page 5: Safety
2. SAFETY 2.1 Operating Manual Anyone who operates the Globus stone rake must familiarize themselves with the contents of the operating manual before using the machine. 2.2 Caution Ensure that no persons are in the machine's working area. Stones, soil, and other foreign objects affected by the machine can cause damage to people, vehicles, buildings, and other objects. -
Page 6: Lifting Points
2.7 Safety Labels The Globus Stone Rake is equipped with various warning labels that indicate actions that must be taken to avoid injuries and accidents. The symbol appears on warning labels placed at different locations on the machine. These are shown in the images below. If the labels are lost from the machine, new ones can be provided by the manufacturer or dealer. -
Page 7: Product Information
3. PRODUCT INFORMATION 3.1 Application The Globus stone rake is a soil cultivation tool used to gather stones in rows before stone sorting. The stone rake provides the best results on fields that have been plowed and harrowed first. Larger stones with a diameter of 30-40 cm should be removed before using the stone rake to avoid overloading the machine. -
Page 8: Assembly And Connection Assembly
4. ASSEMBLY AND CONNECTION 4.1 Assembly Instructions The stone rake is always supplied with a transport bracket, and the associated mounting device is disassembled. Otherwise, the machine is delivered complete and ready to use, unless otherwise agreed. 4.2 Adjusting the PTO Shaft Always use the power take-off shaft supplied with the machine. -
Page 9: User Tips
5. USER TIPS 5.1 Power Take-Off (PTO) The stone rake is designed for 540 RPM. The forward speed and gear selection depend entirely on the conditions and the type of tractor. The PTO should only be engaged at low speed. 5.2 User Tips •... -
Page 10: Warranty
7. WARRANTY TERMS 7.1 Warranty Underhaug AS guarantees that the product, including all parts, is manufactured in accordance with applicable specifications and is free from material or manufacturing defects for a period of 12 months from the date of sale. The date of sale is the invoice date. A receipt for a paid invoice serves as the warranty certificate. -
Page 11: Spare Parts
8. SPARE PARTS 8.1 Main frame and stone rake Side 11... - Page 12 8.1 Main frame and stone rake Qty. Description: POS: Art. no.: 940001 Main frame 4 m 940147 Main frame 3 m 940085 Mounting bracket 4 m 940154 Mounting bracket 3 m 940084 Lid 4 m 940156 Lid 3 m 940086 List for lid 4 m 940156 List for lid 3 m...
- Page 13 Tine set 64 tines 3 m double 140480 Tine set 44 tines 4 m 140481 Tine set 87 tinder 4 m double 140482 Tine bracket 940127 Side 13...
-
Page 14: Belt And Chain
8.2 Belt and chain Side 14... - Page 15 8.2 Belt and chain Qty. Description POS: Art. no. 033720 Bolt M16 x 20 033630 Bolt M12 x 30 016008 Locking nut M12 940353 Gearbox kpl. 940076 Belt cover mount. 033680 Bolt M12 x 80 016008 Locking nut M12 033630 Bolt M12 x 30 016008 Locking nut M12...
- Page 16 940098 940090 940099 022126 033520 016006 940190 940097 940089 940100 012916 012920 012927 940317 032755 NOT ILL. 940096 940319 940320 Side 16...
-
Page 17: Maintenance Overview
MAINTENANCE Maintenance Overview Date Bearing Shaft Slewing ring Auger Chute Sign. Annual MANDATORY inspection of the machine (cf. User Directive) Date: Controller (aproved) Signatur Side 17... - Page 18 NOTES Side 18...
- Page 19 WWW.UNDERHAUG.NO PRODUCER: Underhaug AS 4365 Nærbø N-NORWAY Side 19...
