  • Page 1 GTF 235 User manual and spare parts...
  • Page 2 If you would like to learn more about our products, you can visit our website at www.underhaug.no or contact us by phone or email. Our goal is for you to be a satisfied Globus customer. To achieve this, we focus on quality and user- friendly products.

  • Page 3: Declaration Of Conformity

    DECLARATION OF CONFORMITY Producer: Underhaug AS Address: Torlandsveien 3 4365 Nærbø N-NORWAY We hereby declare under our own responsibility that the following product: Type: Globus Snowblower GTF 235 Serial No.: Year of Manufacture: 2024-> covered by this declaration, complies with the following standards: •...

  • Page 4: Table Of Contents

    CONTENT Introduction Side Welcome as customer Product information Declaration of conformity Safety User Manual Caution Crushing hazard Safety labeling Lifting points Product Information Intended use Power requirements Construction and functions Technical data Additional equipment Assembly and Connection Assembly Adjustment of the PTO-shaft Connection User tips Adjustment of working depth/width...

  • Page 5: Safety

    2. SAFETY 2.1 User Manual All users of the Globus Snowblower GTF 2550 and GTF 2750 must familiarize themselves with the content of the user manual before using the machine. 2.2 Caution Ensure that no one is in the snowblower's throwing area. Snow, ice, stones, and other foreign objects thrown from the blower can cause damage to people, vehicles, buildings, and other objects.

  • Page 6: Lifting Points

    The machine is designed for 540 RPM. Rotating parts. Read the user manual. Warning. Always remove the key from the ignition during repairs. 22.9 Lifting Points The snow blower body is equipped with lifting eyes marked with the symbol as illustrated. Please note that the GTF 2550 and GTF 2750 weigh approximately 1650 kg and 1750 kg, respectively.

  • Page 7: Product Information

    3 PRODUCT INFORMATION 3.1 Application The Globus GTF 235-18 is a two-stage snow blower suitable for tractors from 70 hp. The snow blower is supplied with a fixed 3-point hitch designed to meet applicable standards. The machine requires skilled operation, and the user manual should be read before connection and operation, even if you have experience with similar machines.

  • Page 8: Technical Data

    Technical data Model GTF 235 Working width 235cm Working width w/ cutting edge R 255cm Power requirement 70hp Fan diameter 70cm Weight PTO axle 30kg Weight, approx. 820kg Additional Equipment Available additional equipment for the Globus GTF 2550 and GTF 2750 is listed below. Drawings and parts lists for each item can be found later in the manual.

  • Page 9: Assembly And Connection

    4 ASSEMBLY AND CONNECTION 4.1 Assembly The snow blower is delivered fully assembled and ready for use, unless otherwise agreed. For practical reasons during transport, the chute may be delivered disassembled or laid down. The edge blades are delivered unassembled for self-assembly unless otherwise agreed. If the edge blades need to be installed, refer to the parts list for detailed drawings.

  • Page 10: User Tips

    5 USER TIPS 5.1 Power Take-Off (P.T.O.) The snow blower is designed for a power take-off that provides 540 rpm. Forward speed and gear selection depend entirely on snow conditions and tractor type. The P.T.O. should only be engaged at low engine speed. 5.2 Adjustment of Working Width/Depth The working width of 235 cm can be adjusted by installing edge blades (see technical data 3.3).

  • Page 11: Maintenance Retightening

    • Place the snow blower on a flat surface. Adjust the skid shoes so they are level with the ground. Then extend the hydraulic top link to apply pressure on the skid shoes. Note! The blower should scrape the rear blade, not the front side blades. 6.
  • Page 12 2. Chute The chute has 8 grease nipples and should be lubricated every 8 operating hours. Use universal grease, such as Statoil Uniway Li 62. 3. Drive System Use gear oil Statoil GearWay 80W-90 (Change after 50 hours of operation, then every 200 hours or annually).

  • Page 13: Warranty Terms

    1. As long as the conditions mentioned in the points below are met, the product is covered by Underhaug's extended warranty for 3 years – 36 months from the sale date. The invoice date from the dealer to the customer serves as documentation for the sale date.

  • Page 14: Spare Parts

    4. The handover form must be sent to Underhaug no later than one month after the new product is delivered to the customer for the extended warranty to apply. SPARE PARTS Contents POS: Description: Chapter: Page: Screw, operation and fan...
  • Page 15 Screw, operation and fan Page 15...
  • Page 16 Chapter 8.2 Screw, operation and fan Serial no. POS: Art. no: Deskription: From Add.info: 1 124782 Gearbox S2100 GTF 235 100 - 2 130113 Rear cover 100 - 3 032321 Screw M6x12 100 - 4 012911 Washer Ø7 100 - 5 125959 Cpl.

  • Page 17: Chassis

    Chassis Chapter 8.3 Chassis Serial no. POS: Art. no: Description: From Add.info: 33 125860 Chassis welded and painted GTF 235 100 - 34 930468 Stake pin 100 - Page 17...
  • Page 18 Chute Page 18...
  • Page 19 Chapter 8.4 Chute complete Serial no. POS: Art. no: Description: From Add.info: Chute, lower part towards the swivel 124171 ring 2011 100 - 124176 Chute, lower part 2011 100 - 124181 Flap 1 chute 2011 100 - 124184 Flap 2 chute 2011 100 - 124187 Linkage Ratio...
  • Page 20 Slitesko og slitestål Page 20...
  • Page 21 Chapter 8.5 Wear steel/skid shoes Serial no. POS: Art. no: Description: From Add.info: 34 125908 Wear parts Main 100 - 35 034840 Locking screw L-40 100 - 36 012927 Washer Ø17 100 - 37 016010 M16 Locking nut 100 - 38 125909 Wearing steel R+L STD.
  • Page 22 Ekstrautstyr Page 22...
  • Page 23 Page 23...
  • Page 24 Page 24...

  • Page 25: Chapter 8.6 Additional Equipment

    Chapter 8.6 Additional equipment Serial no. POS: Art. no: Descripton: From Add.info: 80 125988 Edge cutter L. cpl. 100 - 81 125964 Edge cutter R cpl. 100 - 82 125963 Wheel set cpl. 100 - (2 psc.) 83 125834 Hydr.edge cutter R cpl. 100 - 84 125778 Cylinder Ø50730x200...
  • Page 26 Svingkrans med drift Page 26...
  • Page 27 GTF 235 Discription Qty. Serial no. Mark 124804 Swivel ring w/teeth 100-> cpl. w/brake 033630 Screw M12x30 100-> 012919 Wssher Ø13 100-> 016008 M12 nut DIN 985 100-> 033640 Screw M12x40 100-> 802040 Screw M12x35 DIN 912 100-> 123955 Brake Top 100->...
  • Page 28 Maintenance Overview: Date Bearing Axle Swivel ring Auger Chute Sign. Annual mandatory inspection of the machine (according to the user manual) Date: Controller (apporoved) Stamp/Signature Page 28...
  • Page 29 Notes Page 29...
  • Page 30 Notes Page 30...
  • Page 31 Notes Page 31...
  • Page 32 WWW.UNDERHAUG.NO PRODUCER: UNDERHAUG AS 4365 Nærbø N-NORWAY Page 32...
