Summary of Contents for Underhaug GLOBUS GSF 245-18
- Page 1 GSF 245-18 User manual and spare parts...
-
Page 2: Product Information
Cambridge rollers, crosskill rollers, snow blowers, excavator buckets, quick coupler systems, and other construction equipment for excavators. If you would like to learn more about our products, you can visit our website at www.underhaug.no or contact us by phone or email. -
Page 3: Declaration Of Conformity
DECLARATION OF CONFORMITY Producer: Underhaug AS Address: Torlandsveien 3 4365 Nærbø N-NORWAY We hereby declare under our own responsibility that the following product: Type: Globus Snowblower GSF245-18 Serial No.: Year of Manufacture: 2024-> covered by this declaration, complies with the following standards: •... -
Page 4: Table Of Contents
CONTENT Introduction Side Welcome as customer Product information Declaration of conformity Safety Intended use Safety Crushing hazard Safety labeling Product information Intended use Construction and function Technical data Optional equipment Assembly and connection Assembly Adjustment of the PTO-shaft Connection User tips Adjusting of working dept/width User tips Maintenance... -
Page 5: Safety
2 SAFETY 2.1 Instruction manual Anyone using the Globus snow blower GSF 245-18 must familiarize themselves with the contents of the instruction manual before operating the machine. 2.2 Caution Ensure no people are in the snow blower’s discharge area. Snow, ice, stones, and other foreign objects ejected from the blower can cause injury to people, vehicles, buildings, and other objects. -
Page 6: Lifting Points
The machine is designed for 540 RPM. Rotating parts. Read the user manual. Warning. When performing repairs, always remove the key from the ignition. 2.9 Lifting points The snow blower housing is equipped with three lifting points, marked with the symbol illustrated. Please note that a snow blower weighs approximately 820 kg. -
Page 7: Product Information
3 PRODUCT INFORMATION 3.1 Intended Use The Globus GSF 245-18 is a robust and functional V-blower suitable for medium to large tractors from 70 hp to 170 hp. The blower is supplied with a fixed three-point hitch, adapted to current standards. -
Page 8: Optional Equipment
OPTIONAL EQUIPMENT Available optional equipment for the Globus GSF 245-18 is listed below. Art. no. Description Add. Info. Double-acting hydraulic deflector For hydraulic control of the deflector 127320 Marker lights and strobe (LED) 127971 Light set 128079 Edge cutter cpl L... -
Page 9: Assembly And Connection
ASSEMBLY AND CONNECTION Assembly The blower is delivered fully ready for use unless otherwise agreed. (Note: The PTO shaft is adapted to the tractor.) The GSF 245-18 comes standard with mounting holes that provide multiple options for adjusting the desired position of the deflector. If the blower has been ordered with hydraulic control (127320), it will be delivered with this installed. -
Page 10: User Tips
USER TIPS Power Take-Off (P.T.O.) The snow blower is designed for a PTO that provides 540 RPM. The forward speed and gear selection depend entirely on snow conditions and tractor type. The PTO should only be engaged at low engine speed. -
Page 11: Maintenance
MAINTENANCE Retightening After 5 hours of operation with a new blower, all bolt connections should be checked and tightened where necessary. This should then be checked regularly. Lubrication points • The snow blower is equipped with two ball bearings for the support of the fan shaft. The bearings are filled with grease and have built-in seals. -
Page 12: Replacing Wear Parts
September 15th. 4. The delivery form must be sent to Underhaug no later than 1 month after the delivery of the new product to the customer for the extended warranty to be valid. -
Page 13: Spare Parts
SPARE PARTS Content Side 13... - Page 14 POS: Description: Chapter: Page: Chassis Wear plate 16-17 Fan cpl 18-19 Chute cpl 20-21 Swivel ring cpl 22-23 Engine bracket cpl 22-23 Wear shoes Wheel Edge cutter R Edge cutter L Lubrication schedule/annual inspection Side 14...
-
Page 15: Chassis
Chassis Name, type Qty. Serial no. Note 245-18 127600 Chassis welded 930468 Cleaning rod Side 15... -
Page 16: Wear Steel
Wearing steel Side 16... - Page 17 Name, type Qty. Serial no. Note 245-18 034841 Locking screw M16x50 127642 Waring blade edge cutter L 127642 Wearing blade edge cutter R 127623 Wearing blade R 127623 Wearing blade L 127622 Wearing blade auger blade 034840 Locking screw M16x40 012927 Washer Ø17 016010...
-
Page 18: Fan And Bearings
Fan and bearing Side 18... - Page 19 Name, type Qty. Serial no. Note 245-18 011226 Foot bearing Ø60 011227 Flange bearing Ø60 016010 M16 nut DIN 985 032770 Screw M16x70 012927 Washer Ø17 127553 Fan cpl w/auger 127625 Auger blade 032713 Screw M16x180 029918 Grease nipple M6 rett 033745 Screw M16x45 127555...
-
Page 20: Chute
Chute Side 20... - Page 21 Serial no. 8.6 Chute POS: Art. no: Description: From Add. info: Lower part of the chute against the 124171 swivel ring 2011. 124176 Chute lower part 2011 124181 Flap 1 chute 2011 124184 Flap 2 chute 2011 124187 Linkager od for gearing 124954 Moubting bolt chute cpl 033420...
-
Page 22: Slewing Ring / Engine
Swivel ring / engine Side 22... - Page 23 Name, type Qty. Serial no. Note 245-18 124804 Swivel w/teeth cpl w/brake 033630 Screw M12x30 012919 Washer Ø13 016008 M12 nut DIN 985 033640 Screw M12x40 802040 Screw M12x35 DIN 912 127284 Upper brake 127285 Lower brake 124875 Engine bracket cpl cpl w/engine 124874 Engine mount...
-
Page 24: Wear Skids
Wear skids Name, type Qty. Serial no. Note 245-2 970049 Bolt Ø16 029712 Cotter pin Ø4 126510 Front wear skids cpl 126509 Rear skid plate Deviates from pic. 130114 Rear wearskid cpl Side 24... -
Page 25: Wheel
Wheel Name, type Qty. Serial no. Note 245-18 124949 Wheel set cpl Set w/2 wheels 129945 Wheel frame 125377 Wheel cpl w/bolt 124871 Adjusting pin 010278 Bolt 010704 Ring splint Side 25... -
Page 26: Edge Cutter
Edge cutter Name, type Qty. Serial no. Note 230-2 245-2 128078 Edge cutter R. cpl 128079 Edge cutter L.. cpl 034841 Locking screw M16x50 034840 Locking screw M16x40 012928 Washer Ø17 016010 M16 nut DIN 985 016008 M12 nut DIN 985 033635 Screw M12x35 033640... -
Page 27: Maintenance Schedule
Maintenance schedule: Date Bearing Axle Swivel Auger Chute Sign. Annual mandatory inspection of the machine (according to the user directive). Date: Controller (approved) Stamp/Signature Side 27... - Page 28 WWW.UNDERHAUG.NO PRODUCER: Underhaug AS 4365 Nærbø N-NORWAY Side 28...
