AVYCON AIVO-70A8KM User Manual

Ip network tester
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AIVO-70A8KM
USER MANUAL
IP NETWORK TESTER
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AIVO-70A8KM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AVYCON AIVO-70A8KM

Summary of Contents for AVYCON AIVO-70A8KM

  • Page 1 AIVO-70A8KM USER MANUAL IP NETWORK TESTER...
  • Page 2 • Thank you for purchasing the IP camera tester. Please read the manual before using the IP camera tester and use properly. • For using the IP camera tester safely, please first read the [Safety Information] carefully in the manual. •...

  • Page 3: Table Of Contents

    Table of Contents 1 .Safety information ..................4 2. IP Camera Tester Introduction ..............5 2.1 General ............................5 2.2 Packing list ............................ 5 2.3 Function interface .......................... 5 3. Operation ....................9 3.1 Installing the Battery ........................9 3.2 Instrument Connection ........................9 3.2.1 IP Camera Connection .....................
  • Page 4 Table of Contents 3.3.22 Cable Test ......................61 3.3.23 RJ45 Cable TDR Test ..................62 3.3.24 Cable Tracer ......................64 3.3.25 Digital Multi-Meter ....................68 3.3.26 Audio Record ....................... 74 3.3.27 Data Monitor ......................74 3.3.28 Audio Player ......................75 3.3.29 Media Player ......................

  • Page 5: Safety Information

    1. Safety Information • The tester is intended to use in compliance with the local rules of the electrical usage and avoid to apply at the places which are inapplicable for the use of electrics such as hospital, gas station etc. •...

  • Page 6: Ip Camera Tester Introduction

    2. IP Camera tester Introduction 2.1 General The 7 inch touch screen IP camera monitor is designed for maintenance and installation of IP cameras, analog cameras, 8MP TVI, 8MP CVI, 8MP AHD, 8MP EX-SDI cameras, as well as testing 4K H.264 /8K H.265 camera via mainstream, The 1920x1200 resolution enables it to display network HD cameras and analog cameras in high resolution.
  • Page 7 2. IP Camera tester Introduction...
  • Page 8 2. IP Camera tester Introduction...
  • Page 9 2. IP Camera tester Introduction...

  • Page 10: Operation

    3. Operation 3.1 Installing the Battery The tester has built-in lithium ion polymer rechargeable battery. The battery cable inside battery cabin should be disconnected for safety during transportation! Prior to the use of the instrument, the battery cables inside the battery cabin should be well connected. Usually it doesn’t need to disconnect the cable at the normal use.

  • Page 11: Analog Camera Connection

    3. Operation Note: 1) If the IP camera requires PoE power, then connect the IP camera to the IP tester’s LAN port. The tester will supply PoE Power for the IP camera. Click the icon POE to turn the PoE Power off or on. 2) If use the tester’s menu to turn off the tester’s PoE power supply, the PoE switch and the power sourcing equipment are allowed to connect to the tester’s PSE port, and the PoE power will be supplied to the IP camera by the tester’s LAN port.

  • Page 12: Hd Coaxial Camera Connection

    3. Operation 3.2.3 HD Coaxial Camera Connection * SDI, CVI, TVI, AHD camera are classified as HD coaxial cameras. Hereby the following instruction of how to connect SDI camera to the tester is also applied to CVI, TVI, and AHD camera. 1) Connect the SDI camera’s video output to the IP tester’s “SDI IN”...

  • Page 13: Osd Menu

    3. Operation 3.3 OSD Menu Press the key 2 seconds to turn on Press the key again to turn off short press the key to enter sleep mode, press it again to test. If tester works abnormally and cannot be turned off, Press the key several seconds to turn off, the tester reset.

  • Page 14: Short Cut-Menu

    3. Operation 3.3.2 Short Cut-Menu You can call shortcut –menu by press tester’s “menu” key, you can self- define shortcut -menu. Press the key , you can turn on it, and switch functions, then press to enter app, tap other area on the screen, to exit the menu.

  • Page 15: Screen Capture

    3. Operation 3.3.3 Screen Capture Long press the key “enter”, can capture screen interface and save it in any time. You can go file management to view “file Explorer –sdcard- Pictures—Screenshots”. 3.3.4 Link Monitor Tap icon “Link Monitoring” at left corner on the screen, to enter. It can detect instrument port rate 10/100/1000M, signal quality detection, upload and download speed, etc.

  • Page 16: Testerplay

    3. Operation Advanced Link Monitor It is for monitoring CVBS loop, Ethernet statistics, error frame statistics, frame length etc 3.3.5 TesterPlay Mobile screen projection (Only for android version) The meter creates WIFI hotspot, connect mobile phone to the tester’s WIFI hotspot, or the tester and mobile phone connect the same Wi-fi network.
  • Page 17 3. Operation Mobile phone enter “Remote control” app, please click “Auto search IP” to search remote host IP, then click “Play” to display the real-time image and control IPC Tester. If can’t find the IP address, can click “Manually search IP”, and input tester’s rtsp url to remote host IP, such as 192.168.0.186, then click “Play”.

  • Page 18: Ip Discovery

    3. Operation PC screen projection: Install VLC player in the PC, turn on the VLC player “Media - Open Network Streaming”, and input the RTSP address of on the top instrument two-dimensional code, click “play” to view the screen real-time projection. 3.3.6 IP Discovery Press IP discovery , tester auto-scan the whole network segment IP, as well as auto-modify the tester’s IP to...

  • Page 19: Ipc Test Pro

    3. Operation 3.3.7 IPC Test Pro Camera test often need to open multiple apps, “IPC TEST PRO” app, using new technology and combine multiple functions to one APP, it can increase efficiency. Application: Support multi-segment IP address scan, can visual display camera manufacturer, click IP address to play the image.
  • Page 20 3. Operation It lists cameras name and IP address on the Left of screen. Tester can auto login camera and display camera image. Factory default use admin password to auto login, if you modified the password, then default use the modified password to log in.
  • Page 21 3. Operation Cross network scan: After open this function, enter “Setting - IP Settings - Advanced” to add other network segments IP, Rapid ONVIF function can across network segments to scan camera’s IP. Auto Login: After open this function, tester can auto login camera and display camera image. (The login pass- word is the same with last time, the first time using password is the default password “admin”) Video transmission protocol: UTP and TCP protocol.
  • Page 22 3. Operation ONVIF PTZ control: Tap the image in the direction you want the PTZ camera to move. Tap the left side of the image to move left, right to go right, up to go up and down to go down. Compatible IP PTZ cameras will rotate accordingly.
  • Page 23 3. Operation Profiles: Click “profiles”, can view video streaming current configuration files, as well as switch between Major stream and minor stream. Preview pictures: Quickly preview and zoom in or out pictures, automatically and manual refresh. Identification: Click “Identification” to view information of the camera.
  • Page 24 3. Operation Time set: Click “Time set”, Select “Manual set” to set up the time of camera. Maintenance: For camera software reset or restore to factory settings. User Set: Modify camera user name, password etc parameters. Network setting: Click “Network Set” to change the IP address. Some cameras cannot support change IP address, so there is no change after saving.
  • Page 25 3. Operation When the image is enlarged, if not operate on touch screen, it can operate by the keyboard, press the key to zoon in, press the key to zoom out, press upward and downward key to move image. If it is network video input to the tester, as the tester supports resolution up to 1080p, the input image will be very clear after it is enlarged.
  • Page 26 3. Operation Playback: Click the “Playback” icon to view saved videos. Double click the video you want to play. Click to return to the last menu. To rename or delete a photo, click and hold on the file until this screen appears: OSD Menu: Select OSD and popup the OSD menu.
  • Page 27 3. Operation Video files can play in the Video player on the main menu. Set preset position: Move the camera to preset position, enter the preset number on the Bottom right corner to complete position preset. Call the preset position: Select the preset number on the left, click “Call” to call preset.
  • Page 28 3. Operation PTZ Speed set: Horizontal and Vertical Speed set. RTSP: Get RTSP address of the current camera Doc: Auto generate test reports document of camera, click “generate document”. Click Preview to view the report document.
  • Page 29 3. Operation Enter the camera test information, click “Generate Document” to complete the report. Click “Doc” menu again, you can preview the report document. Icons Description: The description of function icons on the bottom toolbar.

  • Page 30: Non Onvif

    3. Operation 3.3.9 NON ONVIF Display image from the 4K H.265 camera by mainstream Click icon to enter IP camera test Note: Currently, the IPC Test App only supports some brands’ specific IP cameras, these include specific models made by ACTI, AXIS, Dahua, Hikvision, Samsung, and many more. If the camera is not fully integrated, please use the ONVIF or RTSP apps.
  • Page 31 3. Operation Stream code: When test camera via RTSP, you can select mainstream or sub stream to test (if camera’s RTSP have not been start or without, it will tip “auto match fail, please switch to manually selecting”. IP Camera’s IP: Enter the IP camera’s IP address manually or click “Search” to auto-scan for the IP camera’s IP address.

  • Page 32: Hdmi In

    3. Operation After all settings are completed, click “Enter” to view the live video. If IP address setting has error or IP camera is not connected.. The tester prompts “Network Error” Click to quit from image display and return to IP camera test interface. Once you are viewing video on the IPC Test app, you will see the “Video Menu”...
  • Page 33 3. Operation (1) Snapshot Click the icon “Snapshot”, when the video in, to take a picture and save the current video frame in the SD card as JPEG file. If the unit is set to the manual mode an “Input Name” pop up box will appear and you can enter a title for the snapshot.

  • Page 34: Vga

    3. Operation (3) Photo Click the icon “photo” to enter, click the selected thumbnail photo to display it on the screen. Double-tap the image you want to view to make it full screen. Double-click again the photo to return. To rename or delete an image, click and hold on the file until this screen below appears. Click to close and return to PTZ controller.

  • Page 35: Analog Camera Test

    3. Operation 3.3.12 Analog Camera Test Analog camera test and PTZ control, click icon to enter. Display the input video image, click the top menu bar icon to enter video level meter, (PEAK level, SYNC level, COLOR BURST measurement) Select relative function on the right side Toolbar to operate, functions including “Photos”, “Snapshot” , “Record”, “Playback”, “PTZ”, “Set”.
  • Page 36 3. Operation 1) PTZ Controller Parameter Setting Select and click icon “PTZ”, to enter PTZ setting: A. Protocol Use the up and down arrow keys to move the yellow cursor to the “protocol”, set corresponding Protocol and support more than thirty PTZ protocols. Such as Pelco-D, Samsung, Yaan, LiLin, CSR600, Panasonic, Sony-EVI etc.
  • Page 37 3. Operation Check and set the protocols, address, interface and baud, all must be consistent with the dome camera, then the IPC tester can test. After setting the parameter, the tester can control the PTZ and lens To control PTZ by screen touch: Tap left, right, upward and downward on the touch screen to control the PTZ rotation direction.
  • Page 38 3. Operation 3) 4 x Zoom Image Display and Video Out When image input, press to enter “zoom”, press it again to quit. Using the touch screen to control PTZ camera movement: Tap left, right, upward or downward on the video image to move the PTZ camera in a desired direction. Stretch two fingers outward or inward on the touch screen to zoom the image in or out.
  • Page 39 3. Operation 5) Video Record When you click the “Record” icon, video starts recording. A red recording icon appears on the screen and begins to flash and a timer appears indicating the time elapsed for the video. Click on the “Record” icon again to stop recording and save the video file to the SD card.

  • Page 40: Color-Bar Generator (Tv Out)

    3. Operation (7) Recorded Video Playback Click the “Playback” icon to view your recorded videos. Tap on the video file image you want to watch. To rename or delete a video, click and hold on the file until this screen appears: Video files also can play in the main menu “Video Player”.

  • Page 41: Autohd

    3. Operation Click the selected color-bars, testing image or single bar ( red, green, blue, white or black). Double click to full display on the screen and output, click to return main menu. Application BNC loop test: Tester can send and receive color bar generator through the tester’s “video out and video in” port, it is for testing transmission channels, such as video Optical, video cables etc.
  • Page 42 3. Operation Image display: Select the camera type, no need to select the resolution, click the camera icon, can browse the camera image directly. Level Meter Test: Need to select the camera type and resolution, click “test” to test the level Color bar genera- tion: Click”CVBS”, quickly enter color bar generation app Test Result:The percentage and signal grid of the level value.

  • Page 43: Cvi Camera Test

    3. Operation 3.3.16 CVI Camera Test HD CVI camera, CVI dome camera test and PTZ control, click icon to enter When HD CVI signal input, the tester will display the image resolution on the top bar. Double-taps on the screen to make the image displayed full screen.
  • Page 44 3. Operation (1) PTZ Control 1.1 Coaxial PTZ control Click the icon”PTZ”on the right toolbar to do the corresponding setting. “Port”: select coaxial control Enter PTZ address to perform parameters setting Operation instructions, please refer to “3.3.1 PTZ (1) Video monitor test” The PTZ address in the tester must be consistent with the dome camera or decoder, then the IPC tester can test.
  • Page 45 3. Operation To control PTZ by screen touch: Tap left, right, upward and downward on the touch screen to control the PTZ rotation direction, PTZ cameras will rotate accordingly. By two fingers move outward and inward on the touch screen to zoom in and out the PTZ. To control PTZ by key buttons to control the PTZ direction of rotation Press the key...
  • Page 46 3. Operation 1.2 RS485 Control Operation instructions, please refer to “3.3.1 PTZ (1) PTZ control parameters setting”. (2) Coaxial Camera Menu Setting Tap icon “UTC”, select “menu setting” to enter the dome camera menu.
  • Page 47 3. Operation Input calling dome camera menu address code, after finishing the parameter settings, you can press the key or click the icon to call the dome camera menu. Press arrow keys to set...
  • Page 48 3. Operation (3) Snapshot, record, photo viewer and video play back, please refer to “3.3.1 PTZ (1) Video monitor test”. Tap “close menu” or press the key “ “ to close camera menu. (4) Save Setting Click icon “Set” on the right toolbar to enter storage setting. Support auto-storage and manual storage. When select manual storage, user can name and store the files.

  • Page 49: Tvi Camera Test

    3. Operation 3.3.17 TVI Camera Test HD TVI camera, TVI dome camera test and PTZ control, Click icon to enter The tester supports resolution as follows: 1280x720P 25FPS / 1280x720P30FPS / 1280x720P 50FPS / 1280x720P 60FPS 1920x1080P 25FPS / 1920x1080P 30FPS / 1920x1080P 50FPS / 1920x1080P 60FPS //2048x1536P 18FPS/2048x1536P 25FPS/2048x1536P 30FPS /2560x1440P 15FPS/2560x1440P 25 FPS/2560x1440P 30FPS/2688x1520P 15FPS/2592x1944P 12.5FPS/2592x1944P 20FPS/3840 x 2160P 12.5/15 FPS Coaxial camera menu settings...

  • Page 50: Ahd Camera Test

    3. Operation Input calling dome camera menu address code, after finishing the parameter settings, you can press the key or click the icon to call the dome camera menu. More operation instructions (such as PTZ control, coaxial camera menu setting, snapshot, recording and play- back etc), please refer to “3.3.6 CVI camera test”.

  • Page 51: Net Tool Pro

    3. Operation (1) Coaxial PTZ control UTC control: select “PTZ control or PTZ control-2”(AHD camera has two different order, if select “PTZ” cannot control, please go “PTZ-2” ) If to coaxial PTZ control the AHD camera, no parameters setting is needed. More operation instructions please refer to “3.3.6 CVI camera test”...

  • Page 52: Ip Address Scan

    3. Operation (1) IP Address Scan Connect the cable to the LAN port. Set your IP address search range by changing the Start and End IP addresses. Click the “Start” button to scan the IP address range. You can also input an IP address in the Port Number Scan to scan for open ports.

  • Page 53: Network Test (Ethernet Bandwidth Test)

    3. Operation Application: PING testing is the most conventional network debugging tools. It is used for testing if the connect- ed IP camera or other network equipment’s Ethernet port is working normally and the IP address is correct. It’s normal that the first data packet will be lost when test start. (3) Network Test (Ethernet Bandwidth Test) To use the Network tester, you will need two IP testers.
  • Page 54 3. Operation b). Start send packet test: Using the other IP tester, type in the Server’s IP address at the top right corner of the screen. This app is used to send packets for network speed testing. Click the “Start” button to send the packets and start testing.

  • Page 55: Port Flashing

    3. Operation Tester as Client, tester’s IP address is:192.168.0.238. The Server and the Client are at the same network segment, but with different IP address. Input Server’s IP address 192.168.0.39 in the tester and click “Start” to test network bandwidth. Or use tester as a Server, computer as test Client(select Client, input tester’s IP address to test) When use tester as Server, shows results: (4) Port Flashing...

  • Page 56: Dhcp Server

    3. Operation Application: The tester will send special signals to make the connected LAN port flicker at special frequency, which will enable the installers to easily and quickly find the connected Ethernet cable. This function can prevent mistakenly insertion or disconnection non-corresponding cable to artificially interrupt network connection. (5) DHCP Server Click on the DHCP icon to open the DHCP server app.

  • Page 57: Link Monitor

    3. Operation (7) Link monitor Click the icon to open the Link Monitor app. This app is used to see if an IP address is occupied by other network devices. This will avoid new address conflicts Click “Add “ and enter the desired IP address. To test different network segments, click the “Settings” icon on the main menu and go to IP Settings and make the desired changes.

  • Page 58: Power Management V2.0

    3. Operation 3.3.20 Power management V2.0 PoE 48V OUT PoE power output, to use the PoE Power Output function, click the screen and change the switch “ON” or “OFF”. You can also use the drop-down menu in the upper right corner of the screen to enable PoE power output app.
  • Page 59 3. Operation Click “On”, the 24V power output voltage and power are displayed in real time After exiting the “DC 24V” screen, the 24V power supply is still on, and the “24V is on” is displayed in the instrument suspension window until the instrument sleeps or enters the “DC 24V” screen and clicks to turn off the power output.
  • Page 60 3. Operation DC12V/3A/OUT When the tester is turned on, the DC 12V 3A power output functions are automatically turned on PSE IN Connect a network cable from a PoE switch to the IP tester’s PSE IN port. Connect an IP camera or other PoE using node to IP tester’s LAN port, the PoE voltage and Power supply protocol Standard 802.3af/at or non-standard and the cable’s pin connection status show on the screen.

  • Page 61: Poe Power / Dc12V 3A And Dc 5V 2A Usb Power Output

    3. Operation Note: Do not connect PoE power supply equipment (such as a PoE switch) to the tester’s UTP/SCAN port, otherwise it will damage the tester r other PoE node must be connected to the LAN port PSE Transmission When PoE / PSE voltage testing, PoE/PSE conntect to the tester’s PSE “IN” port, the camera connect to tester’s LAN port, tester not only can transmit voltage to supply power for camera, but also transmit data at the same time.

  • Page 62: Cable Test

    3. Operation Note: 1. Don’t input power into the “DC12/3A OUTPUT” port. 2. Don’t output this DC12V/3A power to the DC12V/IN port of the IP camera tester to avoid destroy 3. The IPC tester power output is close to 3A, if the IP camera’s power is over 3A, the tester will auto enter protection mode.

  • Page 63: Rj45 Cable Tdr Test

    3. Operation Visual judgment of network cable availability: All sequence of cable is correct, generally corresponds to Gigabit straight/cross network cables. Cable sequence is wrong, but the cable is still available, generally corresponds to 100M straight- through/cross network cable. All sequence of cable is wrong, not available. Meter-end/cable tester-end fault location: Tester-end/cable tester-end display“x”, it means theRJ45 cable connector or within 1 meter from the RJ45 cable connector is faulty.
  • Page 64 3. Operation Single test: Test cable status, length and attenuation. Repeat test: Continue to test cable status, length and attenuation. Status: After link up, screen display “online”, if not link up or open circuit, screen display “open circuit”, if cable pair is short circuit, screen display “short circuit”.

  • Page 65: Cable Tracer

    3. Operation Click “Help” to check the instruction of all parameters. 3.3.24 Cable Tracer Connect tested cable or BNC cable to the UTP port or the CABLE SCAN (VIDEO OUT) port on the bottom. Click icon to enter, click the Number on the screen to adjust audio type. UTP mode is used for searching the normal network cable or other cables.
  • Page 66 3. Operation tracer, the cable sequence, continuity, test box number and network cable type will be displayed on the right side of the meter interface. The “G” indicates the continuity of the shielded network cable. The 1-8 indicators of cable tracer will flash according to the cable sequence. The DIRECT / CROSS / OTHER three indicator lights display the type of network cable directly.
  • Page 67 3. Operation (1) Curved Trajectory 1) Curve Result Analysis Inflection point: The position of break point or short-circuit of the cable, is where curve suddenly rises or falls after the smooth curve. Short circuit: The curve shows an upward trend after the inflection point Open (break point): The curve shows a downward trend after the inflection point 2) Curve Operation Zoom: Zoom the curve.
  • Page 68 3. Operation User-defined calibration: Choose the cable 100 meters to 200 meters (more than 50 meters), click “Cable”, “Type” to select user-defined 1 for calibration, 11 groups user-defined can be set. 1. Select user-defined and click “Calibration” to enter test, click “user-defined 1” can define cable name, such as: AiPu BNC-5 2.

  • Page 69: Digital Multi-Meter

    3. Operation 3.3.25 Digital Multi-meter Click icon to enter. 1) SYMBOLS: : DC Voltage Measuring : Resistance Measuring : AC Voltage Measuring : Continuity Testing : DC Current Measuring : Diode Testing : AC Current Measuring : Capacitance Measuring AC/DC Voltage and current measurement state display Auto- range The Multimeter auto adjust the range by input signal or tested components...
  • Page 70 3. Operation 2) OPERATING INSTRUCTION A. DC Voltage Measuring WARNING! You can't input the voltage which more than 660V DC, it's possible to show higher voltage, but it's may destroy the inner circuit. Pay attention not to get an electric shock when measuring high voltage a.
  • Page 71 3. Operation WARNING! Shut down the power of the tested circuit, and then connect the meter with the circuit for measurement. a. Connect the black test lead to the “COM “ jack and the red test lead to the “mA” jack for a maximum of 660mA current.
  • Page 72 3. Operation NOTE: • When only the figure “OL” is displayed, it indicates over range situation and the higher range has to be selected. • When the value scale to be measured is unknown beforehand, set the range selector at the highest position. •...
  • Page 73 3. Operation WARNING! The capacitance of a capacitor should be tested separately, should not test in the installation of circuit a. Connect the black test lead to the “COM” jack and the red test lead to the “V/Ω” jack. (the red lead anode “+” ) b.
  • Page 74 3. Operation NOTE: a. The capacitance of a capacitor should be tested separately, should not test in the installation of circuit. b. To avoid electric shock, be sure the capacitors have been discharged fully before measuring the ca pacitance of a capacitor. c.

  • Page 75: Audio Record

    3. Operation • Resistance, Continuity, Diode, PTC component Protection Wrong input voltage, will Auto enter protection state , It only suitable for short and limit time work. If input voltage over 600V, will damage the meter. • mA current fuse range: 250V 1A if the current over the rated range ,fuse will melt to protect the meter .Pls use the same model when change the fuse, Pls opens the battery cover to change.

  • Page 76: Audio Player

    3. Operation Click “Setting” to choose the baud rate of RS485, it must be the same as the DVR or the Control keyboard. The DVR or Control keyboard send the code to the tester, if it can be read, the protocol will shown on the upper right, like Pelco D, if not, like P:--- While the tester receives the code, press the key to empty.

  • Page 77: Rtsp Player

    3. Operation To rename or delete an existing file, press the file name for a few seconds until the screen below appears. You can then rename or delete the file by pressing the desired option. 3.3.30 RTSP Player The RTSP Player app will allow you to view the RTSP video stream from an IP camera. If you were unable to view your camera via the ONVIF or IPC Test apps, it is possible your camera will have an RTSP stream and you can view live video.

  • Page 78: Hik Test Tool

    3. Operation Once you have entered all the necessary information, select Enter at the bottom left to view the RTSP stream. Note: In the event the IPC tester does not auto detect the RTSP stream, refer to the specific camera manufacturer for the specific RTSP stream URL.
  • Page 79 3. Operation ”Activation” and “Batch activation” are optional. Auto open ONVIF protocol: After activation, the new HIK cameras click “play, modify the channel name, modi- fy network information, modify user information” any one of to auto open the selected camera ONVIF protocol. Play: Security status shows the “activated”...
  • Page 80 3. Operation Modify channel name: Clicking “Modify the channel name” will pop up OSD settings, including time, channel name and other optional items. After channel selecting, you can edit the channel name, modify the display position, and switch the font size. Select “default location”...
  • Page 81 3. Operation Modify user information: Modify the camera’s user name and password. Factory Reset: Camera factory reset.

  • Page 82: Dahua Test Tool

    3. Operation 3.3.32 Dahua Test Tool Dahua test tool is developed for installation and debugging of the Dahua IP camera, it can display image, and modify IP, user name and password etc. Making Dahua camera test more convenient and quickly. Activation: select left [online detection] to display the “inactivated”...
  • Page 83 3. Operation Play: When mode display “activated” camera, input correct password, click “Play” poping up “private protocol” and “ONVIF”, Select correspond protocol to view the camera image. Modify Channel: Click “Modify Channel”, will pop up OSD setting, includes time, channel name,etc After selected Channel name, can edit channel name, modify the display position and font size.
  • Page 84 3. Operation Modify Network: Support Modify and batch modify two way, can modify camera IP address, Subnet mask and gateway. Input new IP address, need to input password, click “OK” to save the modification...
  • Page 85 3. Operation Modify user information: Modify camera user name and password, which is onvif, Dahua test tool, IPC TESTE user name and password, not web user name and password. Factory reset setting: Camera will be soft reset, and the device’s user name, password and network set be saved.

  • Page 86: Update

    3. Operation 3.3.33 Update Copy the downloaded update file to SD card “update” directory, if no directory, please create one. Click the icon to open the Update menu. Select “Local Update” to update via the SD card or select “Online Update”...

  • Page 87: Led Flashlight

    3. Operation 3.3.35 LED Flashlight It is convenient for the installation or maintenance in the evening or in the dark. Click icon to enter. While in the flashlight app, click the red button to turn on the LED lamp. Press it again to turn it off. If you don’t press the red button to shut off the lamp and press the button to exit the app, the lamp will stay on.

  • Page 88: Professional Wifi Analyzer

    3. Operation Please click to view the notepad, all saving contents display. Click each record bar to show the details. Press the record bar for several seconds, prompt whether delete it. 3.3.38 Professional Wifi Analyzer Detect the surrounding wifi signal and signal strength, support 2.4G and 5G frequency band.

  • Page 89: System Setting

    3. Operation Access point list and List format, display WIFI’s channel, frequency, signal strength, device information and distance, etc. 3.3.39 System Setting Click icon to enter Language: Select your desired language: English, Chinese, Korean, Russian, Italian, Polish, Spanish, French or Japanese, German,Turkish,etc. Typewriting: You can select typewriting or install other typewriting:...
  • Page 90 3. Operation Date/Time: Set the Date/time of the IP tester IP setting: Manually set the IP address, Subnet Mask, Default Gateway and DNS address or select “Dynamic allocation” to use DHCP. To test multiple network segments, click “Advanced “ and then click “Add “ to enter another IP address for the IP tester.
  • Page 91 3. Operation Select and press “WIFI” several seconds, to set static IP address. Wi-Fi hotspot: Input “SSID” name and “password”, and then click “ok” to create Wi-Fi hotspot. Brightness: Set the desired brightness of the IP tester and adjust the sleep time settings. Volume: Set volume level SD Card: Displays SD Card Capacity.

  • Page 92: File Explorer

    3. Operation Start the FTP server and then input the tester’s FTP address in the PC’s address bar. This will enable the PC to read, copy and edit the files from the SD card without the use of SD card reader. Version Information: Shows applications version information, if press any apps icon several seconds to unin- stall.

  • Page 93: Audio Test

    3. Operation FTP server You can choose internal or external SD card. Other operation details, Please refer to FTP settings. 3.3.41 Audio Test You can test the audio input from audio pickup devices by connecting the audio pickup device to the IP tester with the supplied audio cable.

  • Page 94: Specifications

    4. Specifications 4.1 General Specifications Model IP Camera Tester * models Optional Display New 7 inch retina touch screen, 1920*1200 resolution Network port 10/100/1000M auto adjust, RJ45, Dual LAN port Built in WIFI, speeds 433M(5G), 150M(2.4G)allows you to connect to a WIFI wireless network and view IP cameras, Operating Frequencies: 2.4G and 5.8G...
  • Page 95 4. Specifications 2160P 25/30 fps, UTC control and call OSD menu 1 channel CVI input BNC interface, resolution support 720P CVI video signal test * 25/30/50/60fps,1080P 25/30fps, 2560x1440P 25/30fps, 2592x1944 20fps, 2960x1920 20fps, 3840 x 2160 12.5/15 fps. UTC control and call OSD menu 1 channel TVI input BNC interfce ,resolution support 720P TVI video signal test*...
  • Page 96 4. Specifications USB 5V power output 5V 2A power output PoE power output 48V PoE power output, Max power 25.5W Under normal mode, you can change icons sequence and self-define the Screen management number of icons in each page Self-define icons, desktop and application interface background, modify Theme interface sliding effect.

  • Page 97: Multi-Meter Specifications

    4. Specifications POWER External power DC 12V 2A supply Battery Built-in 7.6V Lithium polymer battery, 7800 mAh Rechargeable Fasting charge, after charging 3.5 hours, normal working time 16 hours Parameter Capacitive touch screen, OSD menu, select your desired language: English, Operation setting Chinese, Korean, Russian, Italian or Polish, etc Auto off...
  • Page 98 4. Specifications DC Voltage Range Accuracy R esolution 660mV (Manual range) 0.1mV 6.600V 1m ± 0.3%+4 66.00V 1 660.0V 1 00mV AC Voltage Range Accuracy R esolution 660.0mV (Manual range) 0.1mV ± 1.5%+6 6.600V 66.00V 1 ± 0.8%+6 660.0V 1 00mV DC Current Range...
  • Page 99 4. Specifications Resistance Range Accuracy Resolution ±（0.8%+5） ±（0.8%+2） ±（1.2%+5） Continuity Range Resolution Function ,the tester will sound Diode Range Resolution F unction Schottky diode:0.15~0.25V 2.0V 1 rectifier diode:0.6~1.0V triode PN junction:0.5~0.8V Capacitance Range Accuracy Resolution 6.600nF ±（0.5%+20） 66.00nF 10pF 660.0nF 100pF ±（3.5%+8）...

  • Page 100: Optical Power Meter Specifications

    4. Specifications 4.3 Optical Power Meter Specifications -70 +10dBm Measure Range(dBm) Wavelength(nm) 850nm,1300nm,1310nm,1490nm,1550nm,1625nm Detector InGaAs ±3%dB(-10dBm,22) ±5%dB(full range,22 ) Uncertainly Display Resolution Linear:0.1% ; Nonlinear:0.01dBm -10 +50 Operating Temperature( ) Storage Temperature ( ) -20 +70 Connector type FC/PC 4.4 Visual Fault Locator Specifications Laser type Wavelength Calibration 650nm...
  • Page 101 Copyright @ AVYCON. All rights reserved. Specifications and pricing are subject to change without notice. phone: 949-752-7606 email: info@avycon.com social: @avycon_aivo website: avycon.com...
