  • Page 1 SER MANUAL CEANUS 2618011182000 ERSION 16, 2025 ANUARY...
  • Page 2 *************** MUST READ Check for firmware updates Before using the product, make sure you use the most recent firmware version, data sheet, and user manual. This is especially important for Wireless Connectivity products that were not purchased directly from Würth Elektronik eiSos. A firmware update on these respective products may be required.
  • Page 3: Revision History

    WIRELESS CONNECTIVITY & SENSORS User manual Oceanus-I Revision history Manual Hardware Notes Date version version December Initial release of the 2024 manual Correct RX/TX radio January switch table in chapter RF 2025 switch Order code 2618011182000 Version 1.1, January 2025...
  • Page 4 WIRELESS CONNECTIVITY & SENSORS User manual Oceanus-I Abbreviations Abbreviation Name Analog to Digital Converter Board Support Package BYOF Build Your Own Firmware CMOS Complementary Metal Oxide Semiconductor Digital to Analog Converter Electrostatic Discharge Evaluation Firmware Ground GPIO General Purpose Input Output...
  • Page 5: Table Of Contents

    Enabling radio and generating example application ... . . 17 BSP Boardfiles for Oceanus-I ......18 Migrating a STM32WL example to WLE .
  • Page 6 WIRELESS CONNECTIVITY & SENSORS User manual Oceanus-I ESD handling ........34 Safety recommendations .
  • Page 7: Introduction

    The user has the opportunity to develop his own application, using LoRaWAN® or P2P for radio communication. Within a LoRaWAN® network, Oceanus-I takes the role of an end node. Combining RF with further requirements or devices, like sensors, directly on the Oceanus-I, eliminates the need for an additional host.
  • Page 8: Block Diagram

    50 Ω port to antenna UMRF Figure 2: Block diagram 1.2 Ordering information WE order code Description 2618011182000 Oceanus-I BYOF module in T&R packaging 2618019382001 EV-Kit with Oceanus-I Table 1: Ordering information Order code 2618011182000 Version 1.1, January 2025 www.we-online.com/wcs...
  • Page 9: Electrical And Radio Specifications

    WIRELESS CONNECTIVITY & SENSORS User manual Oceanus-I 2 Electrical and radio specifications Unless stated otherwise, all the values given in the manual were measured on the Daphnis-I EV-Board (same HW platform with Daphnis-I standard firmware) with the following conditions: T = 25 °C, VDD= 3.3 V, PER 1%, 868.3 MHz and internal DCDC in use.
  • Page 10: Power Consumption

    WIRELESS CONNECTIVITY & SENSORS User manual Oceanus-I 2.3 Power consumption Description Test conditions Typ. Unit load, +14 dBm output power TX current configuration, 868.3 MHz, LoRa® 26.5 consumption (SF12, BW 125 kHz) RX current load, LNA on, LoRa® (SF12, consumption...
  • Page 11: Current Consumption During Stop 2 Mode

    WIRELESS CONNECTIVITY & SENSORS User manual Oceanus-I 10.00 8.00 6.00 4.00 2.00 0.00 -40 -35 -30 -25 -20 -15 -10 -5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 Temperature range [°C] 2.0 V...
  • Page 12: Radio Characteristics

    The following factors and tasks are critical for the performance of the Oceanus-I module: External antenna for signal reception and transmission, RF trace delivering the signal from the external antenna to the RF pad of the Oceanus-I module, Minimization of external and environmental effects.
  • Page 13: Pin Characteristics

    WIRELESS CONNECTIVITY & SENSORS User manual Oceanus-I 2.5 Pin characteristics Pin specifications listed in the table below. For more details, refer to the datasheet of the MCU [1]. Min. Typ. Max. Unit Parameter 0.7 ×VDD Input high-level voltage 0.3 ×VDD...
  • Page 14: Pinout

    WIRELESS CONNECTIVITY & SENSORS User manual Oceanus-I 3 Pinout VBAT PA15 PH3-BOOT0 PA13 PA14 VDDA Figure 5: Pinout (top view) Order code 2618011182000 Version 1.1, January 2025 www.we-online.com/wcs...
  • Page 15 WIRELESS CONNECTIVITY & SENSORS User manual Oceanus-I Module Pin Designation Type Description Number General purpose I/O General purpose I/O Supply Supply voltage NRST Input Reset General purpose I/O General purpose I/O General purpose I/O Supply Ground Supply Ground RF connection through...
  • Page 16: Rf Pin

    WIRELESS CONNECTIVITY & SENSORS User manual Oceanus-I General purpose I/O Supply Ground Supply Ground PA13 SWDIO Supply Ground Table 7: Pinout For alternative and additional functions of GPIO pins, check the STM32WLE5CCU6 manual [1]. 3.1 RF pin The RF pin provides a 50 RF signal.
  • Page 17: Rx/Tx Radio Switch

    WIRELESS CONNECTIVITY & SENSORS User manual Oceanus-I RF_SW_VCC RF_SW_CTRL1 Description (PB12) (PC13) Shall be used only if radio is off Radio reception Radio transmission Table 9: RX/TX radio switch Order code 2618011182000 Version 1.1, January 2025 www.we-online.com/wcs...
  • Page 18: Build Your Own Firmware

    The BYOF approach is not suited for novice and non-advanced firmware developers. In such a case, consider using a standard module Daphnis-I from our product portfolio. To start with your own firmware development for Oceanus-I, you need a set of information and fulfilled requirements. 4.1 Prerequisites: An active account at st.com to access, downloads, middleware and updates...
  • Page 19: Enabling Radio And Generating Example Application

    WIRELESS CONNECTIVITY & SENSORS User manual Oceanus-I Required software packets will be downloaded to be used for later code creation. This might take a while. Once finished, the project is created and will contain basic drivers for the hard- ware and a minimal software example. Make sure the IDEs workspace does not contain other active projects.
  • Page 20: Bsp Boardfiles For Oceanus-I

    With respect to the subcomponent radio module it is important to note: The Oceanus-I implements a HSE of type TCXO 32 MHz, on pin OSC_IN and TCXO VCC is provided by pin PB0. It has DCDC support and embeds an LSE of type Resonator/Oscillator (32 kHz) on pins PC14 and PC15.
  • Page 21: Migrating A Stm32Wl Example To Wle

    WIRELESS CONNECTIVITY & SENSORS User manual Oceanus-I implement to handle error states. Potential buttons, GPIOs, UART, SPI, I C and LEDs of the end application can be implemented as part of the BSP files. 4.5 Migrating a STM32WL example to WLE While it is recommended to start new projects as described in the previous chapter, some ex- amples provided by ST cannot be generated using the Device Configuration Tool and are only...
  • Page 22: Design In Guide

    WIRELESS CONNECTIVITY & SENSORS User manual Oceanus-I 5 Design in guide 5.1 Advice for schematic and layout For users with less RF experience it is advisable to closely copy the relating EV-Board with respect to schematic and layout, as it is a proven design. The layout should be conducted with particular care, because even small deficiencies could affect the radio performance and...
  • Page 23 WIRELESS CONNECTIVITY & SENSORS User manual Oceanus-I Elements for ESD protection should be placed on all pins that are accessible from the outside and should be placed close to the accessible area. For example, the RF-pin is accessible when using an external antenna and should be protected.
  • Page 24: Designing The Antenna Connection

    WIRELESS CONNECTIVITY & SENSORS User manual Oceanus-I Filter and blocking capacitors should be placed directly in the tracks without stubs, to achieve the best effect. Antenna matching elements should be placed close to the antenna / connector, blocking capacitors close to the module.
  • Page 25: Antenna Solutions

    WIRELESS CONNECTIVITY & SENSORS User manual Oceanus-I Figure 8: Dimensioning the antenna connection as micro strip The width W for a micro strip can be calculated using the following equation: 5 98 = 1 25 +1 41 Example: A FR4 material with = 4.3, a height H = 1000 µm and a copper thickness of T...
  • Page 26: Wire Antenna

    WIRELESS CONNECTIVITY & SENSORS User manual Oceanus-I 5.3.1 Wire antenna An effective antenna is a /4 radiator with a suiting ground plane. The simplest realization is a piece of wire. It’s length is depending on the used radio frequency, so for example 8.6 cm 868.0 MHz and 3.1 cm for 2.440 GHz as frequency.
  • Page 27: 2600130086 - Hermippe-Iii Dipole Antenna

    WIRELESS CONNECTIVITY & SENSORS User manual Oceanus-I 5.3.4.1 2600130086 - Hermippe-III dipole antenna Well suited for applications where the RF is lead through a metal wall that could serve as ground plane to the antenna. Figure 9: Hermippe-III dipole antenna Specification...
  • Page 28: 2600130081 - Hyperion-I Dipole Antenna

    WIRELESS CONNECTIVITY & SENSORS User manual Oceanus-I 5.3.4.2 2600130081 - Hyperion-I dipole antenna Figure 10: Hyperion-I dipole antenna Ideally suited for applications where no ground plane is available. Specification Value Center frequency [MHz] Frequency range [MHz] 853 – 883 Wavelength...
  • Page 29: 2600130082 - Hyperion-Ii Magnetic Base Antenna

    WIRELESS CONNECTIVITY & SENSORS User manual Oceanus-I 5.3.4.3 2600130082 - Hyperion-II magnetic base antenna Well suited for applications where the RF is lead through a metal wall that could serve as ground plane to the antenna. Figure 11: Hyperion-II magnetic base antenna with 1.5 m antenna cable The 2600130082 is an antenna in form of /4 and therefore needs a ground plane at the feeding point.
  • Page 30: Reference Design

    User manual Oceanus-I 6 Reference design Oceanus-I was tested and certified on the corresponding Oceanus-I EV-Board. For the com- pliance with the EU directive 2014/53/EU Annex I, the EV-Board serves as reference design. This is no discrepancy due to the fact that the EV-Board itself does not fall within the scope of the EU directive 2014/53/EU Annex I as the module is tested on the EV-Board, which is also the recommended use.
  • Page 31: Ev-Board

    WIRELESS CONNECTIVITY & SENSORS User manual Oceanus-I 6.1 EV-Board 6.1.1 Schematic Figure 12: Reference design: Schematic diagram Order code 2618011182000 Version 1.1, January 2025 www.we-online.com/wcs...
  • Page 32: Layout

    WIRELESS CONNECTIVITY & SENSORS User manual Oceanus-I 6.1.2 Layout Figure 13: Reference design: Assembly diagram Order code 2618011182000 Version 1.1, January 2025 www.we-online.com/wcs...
  • Page 33: Top Layer (Upper Left), Second Layer (Upper Right), Third Layer (Bottom Left), Fourth Layer (Bottom Right)

    WIRELESS CONNECTIVITY & SENSORS User manual Oceanus-I Figure 14: Top layer (upper left), second layer (upper right), third layer (bottom left), fourth layer (bottom right) Order code 2618011182000 Version 1.1, January 2025 www.we-online.com/wcs...
  • Page 34: Manufacturing Information

    WIRELESS CONNECTIVITY & SENSORS User manual Oceanus-I 7 Manufacturing information 7.1 Moisture sensitivity level This wireless connectivity product is categorized as JEDEC Moisture Sensitivity Level 3 (MSL3), which requires special handling. More information regarding the MSL requirements can be found in the IPC/JEDEC J-STD-020 standard on www.jedec.org.
  • Page 35: Cleaning

    WIRELESS CONNECTIVITY & SENSORS User manual Oceanus-I by the customer at their own risk. Rework is not recommended. –5°C Max. Ramp Up Rate Max. Ramp Down Rate Preheat Area s max s min Time 25°C to Peak Time Figure 15: Reflow soldering profile After reflow soldering, visually inspect the board to confirm proper alignment...
  • Page 36: Potting And Coating

    WIRELESS CONNECTIVITY & SENSORS User manual Oceanus-I 7.2.3 Potting and coating If the product is potted in the customer application, the potting material might shrink or expand during and after hardening. Shrinking could lead to an incomplete seal, allowing contaminants into the component. Expansion could damage components. We recom- mend a manual inspection after potting to avoid these effects.
  • Page 37: Safety Recommendations

    WIRELESS CONNECTIVITY & SENSORS User manual Oceanus-I 7.4 Safety recommendations It is your duty to ensure that the product is allowed to be used in the destination country and within the required environment. Usage of the product can be dangerous and must be tested and verified by the end user.
  • Page 38: Product Testing

    WIRELESS CONNECTIVITY & SENSORS User manual Oceanus-I 8 Product testing 8.1 Würth Elektronik eiSos in-house production tests To achieve a high quality standard, Würth Elektronik eiSos follows a philosophy of supplying fully tested radio modules. At the end of the production process, every unit undergoes an opti- cal inspection.
  • Page 39 WIRELESS CONNECTIVITY & SENSORS User manual Oceanus-I Perform functional tests, including communication checks with the host controller and verification of interfaces. Assess fundamental RF characteristics (modulation accuracy, power levels, spectrum). Verify that the device meets expected performance standards. Order code 2618011182000 Version 1.1, January 2025...
  • Page 40: Physical Specifications

    WIRELESS CONNECTIVITY & SENSORS User manual Oceanus-I 9 Physical specifications 9.1 Dimensions Dimensions 15.0 * 16.0 * 3.00 mm Table 11: Dimensions Tolerances: see chapter 9.3 9.2 Weight Weight 1.21 g Table 12: Weight Tolerance: 0.15 g Order code 2618011182000 Version 1.1, January 2025...
  • Page 41: Module Drawing

    WIRELESS CONNECTIVITY & SENSORS User manual Oceanus-I 9.3 Module drawing 12.8 16.0 ±0.3 2.74 Figure 16: Module dimensions [mm] Order code 2618011182000 Version 1.1, January 2025 www.we-online.com/wcs...
  • Page 42: Footprint

    WIRELESS CONNECTIVITY & SENSORS User manual Oceanus-I 9.4 Footprint 14.2 12.8 Figure 17: Footprint and dimensions [mm] Order code 2618011182000 Version 1.1, January 2025 www.we-online.com/wcs...
  • Page 43: Marking

    WIRELESS CONNECTIVITY & SENSORS User manual Oceanus-I 10 Marking 10.1 Lot number The 15 digit lot number is printed in numerical digits as well as in form of a machine readable bar code. It is divided into 5 blocks as shown in the following picture and can be translated according to the following table.
  • Page 44: General Labeling Information

    In case of small labels, additional certification marks are placed on the label of the reel. The information on the label are fixed. Only the serial number changes with each entity of the radio module. For Oceanus-I the label is as follows: 1801118200 Shortened WE order...
  • Page 45: Information For Explosion Protection

    WIRELESS CONNECTIVITY & SENSORS User manual Oceanus-I 11 Information for explosion protection In case the end product should be used in explosion protection areas, the following information can be used: The module itself is unfused. The maximum power of the module is 14 dBm for external antenna.
  • Page 46: References

    WIRELESS CONNECTIVITY & SENSORS User manual Oceanus-I 12 References https://www.st.com/en/ [1] STMicroelectronics. Web page: STM32WLE5CC. microcontrollers-microprocessors/stm32wle5cc.html . Order code 2618011182000 Version 1.1, January 2025 www.we-online.com/wcs...
  • Page 47: Important Notes

    WIRELESS CONNECTIVITY & SENSORS User manual Oceanus-I 13 Important notes The following conditions apply to all goods within the wireless connectivity and sensors product range of Würth Elektronik eiSos GmbH & Co. KG: General customer responsibility Some goods within the product range of Würth Elektronik eiSos GmbH & Co. KG contain statements regarding general suitability for certain application areas.
  • Page 48: License Terms

    WIRELESS CONNECTIVITY & SENSORS User manual Oceanus-I provided information related to their accuracy, correctness, completeness, usage of the products and/or usability for customer applications. Information published by Würth Elektronik eiSos GmbH & Co. KG regarding third-party products or services does not constitute a license to use such products or services or a warranty or endorsement thereof.
  • Page 49 WIRELESS CONNECTIVITY & SENSORS User manual Oceanus-I The incorporated firmware created by Würth Elektronik eiSos is and will remain the exclusive property of Würth Elektronik eiSos. Firmware update(s) You have the opportunity to request the current and actual firmware for a bought wireless connectivity product within the time of warranty.
  • Page 50 Oceanus-I ........
