SMART TOILET
OWNER'S MANUAL &
INSTALLATION GUIDE
The images are for illustrative purposes only;
please refer to the actual product for accuracy.
READ ENTIRE INSTALLATION GUIDE PRIOR TO INSTALLING THE TOILET
For installation and assembly videos, please visit our website
www.streamlinebath.com
OR
our YouTube page by searching for
"Streamline Bath"
OR
following the below link to our channel:
https://www.youtube.com/channel/UCII7TGMbkwoGSqzo-pGfaJw
CAUTION!
TWO PERSON
LIFT REQUIRED
support@streamlinebath.com
(310) 935-0028
streamlinebath.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LT-658 and is the answer not in the manual?

Questions and answers

Related Manuals for Streamline LT-658

Summary of Contents for Streamline LT-658

  • Page 1 READ ENTIRE INSTALLATION GUIDE PRIOR TO INSTALLING THE TOILET For installation and assembly videos, please visit our website www.streamlinebath.com our YouTube page by searching for "Streamline Bath" following the below link to our channel: https://www.youtube.com/channel/UCII7TGMbkwoGSqzo-pGfaJw CAUTION! TWO PERSON LIFT REQUIRED support@streamlinebath.com...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Safety Information Prior To Installation Grounding Instructions Technical Specifications Tools Required Parts Supplied Parts Diagram Installation Instructions Guidelines for First Use Remote Control Pairing Remote Control Operation Control Panel Side Knob Control Indicator Light Troubleshooting Replacing The Remote-Control Battery Replacing The Backup Battery Foot Sensor Automatic Lid Operation...

  • Page 3: Safety Information

    Safety Information READ ALL INSTRUCTIONS BEFORE USING Streamline shall NOT be held liable for To ensure your safety, it is crucial to any and all incidental damages or follow the safety warnings and floods caused due to the use of this guidelines outlined in this manual.
  • Page 4 Streamline will not be held responsible for defects or issues that DO NOT insert fingers or objects into the arise from neglecting this crucial step.
  • Page 5 Use this product only as described in or modify the product yourself. This can the manual. Avoid using attachments cause fire, electric shock, overheating, not recommended by Streamline. or short circuits. Do not operate the product if the If the toilet malfunctions, stop using it cord or plug is damaged, if it immediately.
  • Page 6 Streamline for assistance. When replacing the filter, close the Failure to do so could result in a risk of water supply angle valve and ensure the fire or electric shock.
  • Page 7 If the product malfunctions, stop use instructions may result in injury or immediately, turn off the power, and property damage: contact Streamline customer service. Do not install or use the product in wet Avoid prolonged use of the heated seat areas, such as steam rooms.
  • Page 8 Emission of smoke. Avoid putting heavy objects on the seat or cover, and do not stand on the toilet. Overheating. Doing so could damage the product The toilet seat cushion being out of and cause injury. place. Do not open the seat or cover if there Continued use after a malfunction can are objects resting on the toilet.
  • Page 9 - Do not disassemble the battery or dispose of it in water or fire, as this could cause the battery to leak fluids and start a fire. Unique Identifier Product Description Smart Toilet LT-658; LT-135; LT-139; LT-571; LT-175; LT-462; LT-187; LT-191; LT-389; Model Number(s) LT-794; LT-199; LT-223; LT-227; LT-239; LT-243; LT-247; LT-251 Trade Name Streamline FCC Compliance Statement This device complies with Part 15 of the FCC Rules.
  • Page 10 NOTE This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 11: Prior To Installation

    Your recent purchase is greatly appreciated, and we are delighted to have you as our valued customer. At Streamline, we strive to provide the highest quality products, and we are confident that our smart toilet will exceed your expectations in terms of both functionality and style.

  • Page 12: Grounding Instructions

    Grounding Instructions DANGER – Improper use of the grounding plug can result in a risk of electric shock. WARNING: Risk of electric shock. Connect only to a dedicated circuit protected by a Ground-Fault Circuit-Interrupter (GFCI), which protects against line-to-ground shock hazard. Use a 120 V, 10A, 60 Hz service. Do not remove the grounding pin or use a grounding adapter.
  • Page 13 If you are unsure about the grounding instructions or whether the product is properly grounded, consult a qualified electrician or sales and service personnel for verification. Additionally, have a qualified electrician confirm that the power supply meets the product's required voltage and power specifications This product must be grounded to reduce the risk of electric shock in case of a short circuit.

  • Page 14: Technical Specifications

    Technical Specifications Ambient Temperature Range 41°F-104°F ; 5°C-40°C Main Unit Inlet Water Temperature Range 41°F-95°F ; 5°C -35°C Voltage Rating 110V-120V Rated Power Input 1200W Frequency 60 HZ Power Cord Length 33.9'' (85CM) Water Tank Capacity Tankless Water Proof Rating IPX4 Minimum Water Pressure(Dynamic) 21.8 PSI (0.15 Mpa)
  • Page 15 General Lighting LED Light Automatic Flushing The toilet will automatically flush as the user walks away Control Panel LT-389; LT-571 Side Knob LT-462; LT-658; LT-794 Foot Sensor Reduced Flush Foot Sensor Open Only on models: LT-794 support@streamlinebath.com (310) 935-0028 streamlinebath.com...

  • Page 16: Tools Required

    Tools Required The following tools are required for installation. Ensure all tools are prepared before beginning the installation process. Caulk Gun Sealant Tape Utility Knife Marker Wrench Screwdriver Tape Measure Measuring Cup Channel Lock Hand Wrench Safety Glasses Pencil Pliers Level Bar Putty Knife support@streamlinebath.com...

  • Page 17: Parts Supplied

    Parts Supplied Wax Ring Toilet Toilet Flange Floor Bolts Deodorizer Rear Wash Dryer Strong/Feminine Wash Front/Strong Wash Water Temp Deodorizer Night Light Power Save Auto Flush Shut-Off Valve Nozzle clean Front Wash Stop Weak/Child Wash Back/One Solution Seat Temp (1/2’’G Male NPT to ¾’’G Male) Remote Control Shut-Off Valve Panel Water...

  • Page 18: Parts Diagram

    Parts Diagram Deodorizer Rear Wash Dryer Strong/Feminine Wash Front/Strong Wash Water Temp Deodorizer Night Light Power Save Auto Flush Nozzle clean Seat Temp Front Wash Stop Weak/Child Wash Back/One Solution Remote Control Strong Nozzle Wash Shield Rear Wash Front Warning Label Wash Power Cord with GFCI...

  • Page 19: Installation Instructions

    Installation Instructions 1. Turn off the shutoff valve. Flush the toilet to fully empty the tank. Afterward, disconnect the water hose and remove the previously installed toilet and old water shutoff valve. 2. Flush the toilet to empty the tank 3.
  • Page 20 3. Measure the appropriate rough-in distance for the installation. Using the provided template, mark the location of the drainage hole so that it is parallel to the shutoff valve. Next, align the flange with the marked drain hole and mark the positions of the four mounting holes on the floor for accurate placement.
  • Page 21 5. Secure the flange to the floor by fastening it with the four provided screws, each accompanied by a flat washer. If additional stability is required, use the provided anchors to ensure a secure and stable installation. Plastic washers 6. Insert the two brass floor bolts into the designated slots in the toilet flange. Once positioned, secure each bolt with the provided plastic washer.
  • Page 22 7. Securely affix the wax ring to the outlet underneath the toilet, ensuring it creates a tight seal. For additional security, if necessary, apply a layer of 100% waterproof silicone sealant around the wax ring to reinforce the seal and prevent any potential leaks.
  • Page 23 9. Carefully lift the toilet seat lid assembly from the toilet by gently lifting from the interior back right corner. Be cautious not to apply excessive force or pull the cover too far while lifting to avoid damage. 10. Remove the cover of the battery case, which is located on the back of the toilet seat underneath it.
  • Page 24 11. Insert the washers and nuts onto the floor bolts, and then use a wrench or appropriate tool to securely tighten the nuts onto the fixing bolts. Ensure the toilet is firmly secured to the floor, avoiding overtightening, which could damage the toilet base or flange.
  • Page 25 12. Reinstall the toilet seat-lid assembly to complete the installation. Take care not to apply excessive pressure while reattaching the assembly to avoid damaging any components. 13. Press the knob on the side of the toilet to confirm that the flushing mechanism is functioning correctly.
  • Page 26 14. When assembling fittings, it is essential to ensure that all connections are well- sealed to prevent leaks. If using Teflon tape, wrap it around the 1/2'' NPT Male thread of the water supply line three to four times to achieve a secure and reliable seal.
  • Page 27 16. Attach a separate hose into a bucket to test the shutoff valve, ensuring the water flow reaches at least 1.2 gallons every 15 seconds. Flush the water supply line to remove any debris and confirm sufficient water pressure. After verifying, turn off the shutoff valve and disconnect the hose.
  • Page 28 18. It's essential to test for leaks by thoroughly inspecting all joints to ensure they are tight and secure. Make any necessary adjustments to eliminate any potential leaks before completing the installation. 19. After turning on the shut-off valve, carefully inspect the entire installation for any leaks.
  • Page 29 20. Lastly, apply a bead of silicone sealant around the base of the toilet to create a watertight seal. Allow the silicone to dry completely for 24 hours before using the toilet to ensure a secure and lasting bond. support@streamlinebath.com support@streamlinebath.com (310) 935-0028 (310) 935-0028...
  • Page 30 21. Remove the backing from the double-sided tape on the bracket, and firmly press the bracket onto the wall next to the toilet. Ensure the surface is clean before installation. Apply even, strong pressure to secure the tape in place. Please note that batteries for the remote are NOT included.

  • Page 31: Guidelines For First Use

    Guidelines for First Use 1. Check for Leaks: Open the water shutoff valve and carefully inspect all connections for any leaks. 2. Power Connection: Ensure the plug is securely inserted into the socket and verify that the power indicator light is illuminated. 3.

  • Page 32: Remote Control Pairing

    Remote Control Pairing Note: If you have more than two of the same smart toilets, there may be interference when using the remote control. To prevent this, use the remote control code matching function to ensure each remote control operates only its designated toilet.

  • Page 33: Remote Control Operation

    Remote Control Operation Water Temperature Rear Wash: Press the Rear Adjustment: Press the Water Wash button to extend Temperature button to the nozzle from the toilet. adjust the temperature of Press the button again to the water. There are four activate oscillating available settings: cleaning mode, where the...
  • Page 34 Deodorizer: Press the Deodorizer button to activate the deodorizing function; the Dryer: Press the Dryer indicator light will illuminate button to begin warm air to show it’s in use. Press the drying. Press it again to button again to deactivate it. switch to movable air To enable auto-deodorization, drying, where the airflow...
  • Page 35 Feminine Care: Press this button to Strong Wash: Press this button to activate feminine care wash in idle activate the powerful washing mode mode. The nozzle will extend, the water in idle mode. The nozzle will extend, temperature will be set to the highest water pressure will be set to the level (102.2°F/39°C), water pressure to highest level, and the wash will...
  • Page 36 Remote Control Version 1 Nightlight Flush/Auto Flush Power Save/Off Nightlight: Press the Flush/Auto Flush: Press Power Save/Off: Press the Nightlight button to toggle the Flush/Auto Flush Power Save/Off button to the nightlight on or off. The button to flush the toilet enter standby mode, corresponding indicator light once, indicated by a...
  • Page 37 Remote Control Version 2 Open/Set Close/Power Save Flush/Auto Flush Close/Power Save: When the Flush/Auto Flush: Press Open/Set: When both the seat is open, press this button the Flush/Auto Flush toilet lid and seat are to activate the soft-close button to flush the toilet closed, pressing this feature.

  • Page 38: Control Panel

    Control Panel Please note that not all models are equipped with a control panel. Our toilet models feature either a control panel or a side knob. The instructions provided here are general and may not apply to your specific model. Be sure to check the product listing details to confirm which features are included with your model.

  • Page 39: Side Knob Control

    Side Knob Control Please note that not all models are equipped with a side knob. Our toilet models feature either a control panel or a side knob. The instructions provided here are general and may not apply to your specific model. Be sure to check the product listing details to confirm which features are included with your model.
  • Page 40 8. Rotating the knob backward turns on the automatic rear wash. This function will wash for 1 minute, followed by 2 minutes of warm air drying. Rotating the knob forward again during the rear wash will stop the rear wash and move to warm air drying.

  • Page 41: Indicator Light

    Indicator Light Please note that only models with a control panel include an indicator light panel. For models with a side knob, the indicator light is integrated directly into the knob itself. The instructions provided here are general and may not apply to your specific model.

  • Page 42: Troubleshooting

    Troubleshooting Situation Reason Process No power. Ensure that the electrical Confirm that the electrical power is connected outlet is receiving power properly and verify that and press the reset button the plug is securely on the plug until you hear inserted into the base.
  • Page 43 Process No response when a Button malfunction. If the issue persists, restart button is pressed. the device, or contact Streamline customer service for further assistance. Water is leaking. Check that the shutoff Reconnect the shutoff valve & water supply hose valve &...
  • Page 44 The soft-close function is The auto-damping Unplug and recharge the not working properly. mechanism may be unit. Contact Streamline damaged. customer service for further assistance if the issue persists. The water pressure is Check the water pressure Adjust the water pressure insufficient.
  • Page 45 Contact a malfunction. Streamline customer service for further assistance if the issue persists. The bowl does not fill with The product is not flushing...

  • Page 46: Replacing The Remote-Control Battery

    Situation Reason Process The dryer function stops Power may be off, or user Check the power mid-operation. might have moved out of connection and adjust the seat sensor area. user seating position to ensure the sensor is activated. The auto-flushing feature Check if the auto-flushing To activate the is not functioning.

  • Page 47: Replacing The Backup Battery

    Replacing The Backup Battery Battery Cover Battery Box Battery Box Underneath the toilet seat 1. Unplug the power cord from the electrical outlet. 2. Lift the toilet seat lid to access the battery box. 3. Remove the battery cover from the battery box. 4.

  • Page 48: Foot Sensor

    Foot Sensor Please note that the functionality of the foot sensor varies with each model. Not all models have the same functions. The instructions provided here are general and may not apply to your specific model. Be sure to check the product listing details to confirm which features are included with your model.
  • Page 49 Toilet Lid and Seat Both Closed: With the lid and seat closed, wave your foot near the sensing area to open the lid. Wave again to raise the seat. A third wave will close both the lid and seat, activating reduced flush mode. Toilet Lid Open, Seat Down: If the lid is open and the seat is down, wave your foot near the sensing area to raise the seat.

  • Page 50: Automatic Lid Operation

    Automatic Lid Operation Please note that not all models are equipped with the automatic lid operation feature. The instructions provided here are general and may not apply to your specific model. Be sure to check the product listing details to confirm which features are included with your model.

  • Page 51: Buzzer Function

    Buzzer Function A single buzz indicates that the seat is in use with all functions available. A second buzz signifies that the seat is in use but with limited functions available. Three or more buzzes indicate a product failure. The buzzer will sound only during remote control use, side control dial operation, or initialization.

  • Page 52: Emergency Troubleshooting

    Emergency Troubleshooting Power Failure: Use the full or half flush buttons to manually flush the toilet. For models with a knob: A full flush can be activated by pressing the side knob once, using the flush button on the remote control, or via autoflush when the user leaves the seat.
  • Page 53 Long-Term Storage: If the toilet will not be used for an extended period, especially during winter, follow these steps to prevent freezing: 1. Turn off the water supply angle valve. 2. Disconnect the power. 3. Discharge any remaining water from the system. Press 4.

  • Page 54: Cleaning & Maintenance

    Cleaning & Maintenance Always disconnect the toilet from the power source before cleaning. Proper care and maintenance are essential to keeping your smart toilet operating efficiently and prolonging its lifespan. Follow the guidelines below to ensure optimal performance and hygiene. 1.
  • Page 55 3. Cleaning The Filter: Regularly check the condition of the filter. Over time, debris and minerals can accumulate, impacting water flow and nozzle function. A clean filter ensures smooth operation and helps prevent clogs If you experience low water pressure, it may be due to a clogged valve filter. Follow these steps to clean the filter: 1.
  • Page 56 5. Soft-Close Seat and Lid Care Proper Use: The soft-closing mechanism on the lid and seat is designed to prevent slamming and prolong the product’s life. Avoid forcing the lid or seat closed manually, as this can damage the hydraulic system. If you notice that the soft-close feature is becoming sluggish or unresponsive, check for dirt or debris around the hinges, and clean them gently with a soft cloth.
  • Page 57 By adhering to this product care guide, you’ll maintain the functionality, appearance, and comfort of your smart toilet for years to come. For any significant issues or repairs, always consult Streamline customer service to avoid damaging sensitive components. support@streamlinebath.com support@streamlinebath.com...

  • Page 58: Warranty

    USE THE PRODUCT, OR ANY OTHER ASSOCIATED EQUIPMENT, THE COST OF SUBSTITUTE EQUIPMENT, AND ANY CLAIMS BY THIRD PARTIES RESULTING FROM THE USE OF THIS PRODUCT. UNDER NO CIRCUMSTANCES SHALL STREAMLINE'S LIABILITY EXCEED THE PURCHASE PRICE OF THE UNIT . STREAMLINE® PRODUCTS MUST BE INSTALLED BY A FULLY INSURED, LICENSED, PROFESSIONAL WHO SHALL FOLLOW THE INSTRUCTIONS PROVIDED BY STREAMLINE®.
  • Page 59 • In no event shall Streamline have any liability or the warranty. responsibility whatsoever for damage to surrounding property, including cabinetry, floors, ceilings, and other structures or objects around the product.
  • Page 60 Streamline. All product names, logos, and brands are the property of their respective owners. Streamline retains all rights to its trademarks, trade names, and copyrighted materials associated with this product. Unauthorized use of these materials is strictly prohibited and may result in legal action.
