PT419W-PTZ
Professional 19" High-Bright PTZ Teleprompter w/ Widescreen SDI Tally Monitor
OVERVIEW
Ikan's professional teleprompter series is designed for a quick and easy setup to work efficiently in studio or broadcast
applications. The included teleprompter hood fully encloses the PTZ camera allowing it to move freely inside the hood. The
teleprompter features a 65/35 reflective glass that makes the reflection easier to see for the presenter. The lightweight
aluminum teleprompter has multiple 1/4-20" and 3/8-16" threads for mounting to a tripod or pedestal. The widescreen
monitor includes SDI, HDMI, and VGA video inputs. Its high bright screen ensures clear visibility in any lighting condition. An
intuitive image flip button allows for easy adjustment of the display orientation. The widescreen monitor also features a wide
viewing angle.
www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com
Quick Start Guide
Advertisement
Table of Contents
Related Manuals for Ikan PT419W-PTZ
Summary of Contents for Ikan PT419W-PTZ
- Page 1 Professional 19" High-Bright PTZ Teleprompter w/ Widescreen SDI Tally Monitor OVERVIEW Ikan’s professional teleprompter series is designed for a quick and easy setup to work efficiently in studio or broadcast applications. The included teleprompter hood fully encloses the PTZ camera allowing it to move freely inside the hood. The teleprompter features a 65/35 reflective glass that makes the reflection easier to see for the presenter.
-
Page 2: Widescreen Monitor
What’s Included Tall Riser DSLR/Mirrorless Riser Short Riser Widescreen Monitor Sled Base Glass Frame Holder Bracket Glass w/ Rod Clamps Hood Attachment Frame Glass Holder Hood Glass Frame Screws 15mm Rod Clamps 15mm Rods Large Riser Bracket www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com... - Page 3 What’s Included PTZ Camera Riser PTZ Hood www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com...
- Page 4 Teleprompter Assembly Setup Step 1 Step 2 Place the Hood Attachment Frame over the Glass Holder. Then place the Secure the Glass Holder by fastening the knurled nuts to the screws as glass against the Glass Holder. Make sure the screws pass through the pictured below.
- Page 5 Step 5 After the monitor mounts are attached, adjust the 15mm rods to accommodate the monitor. Leave about 1 inch of room for the teleprompter bracket. Make sure the 15mm rods go through both set of monitor mounts. Please ensure that all screws are properly tightened after inserting the monitor. *SAFETY NOTE* Make sure to leave at least 2 inches of the rods inside the teleprompter base.
- Page 6 Step 8 Fold the flaps of the Hood alongside the edges of the Hood Attachment Frame. The flaps of the Hood are magnetic so they will automatically attach. Connect the bottom part of the hood by attaching the magnetic flap to glass frame holder. Connect the Velcro straps to the sides of the hood. Step 9: Connecting the PTZ Riser to PTZ Cameras Connect the PTZ Camera Riser to the PTZ camera plate first, by aligning the screw...
- Page 7 Step 10 Set the PTZ camera inside the hood by aligning the screws on the riser plate to the slot on the Base. Once the screws are aligned, Slide the riser plate into the Base. Step 11 To prevent light from leaking through the hood, seal both zippers down, attach the Velcro straps along the back and sides of the hood. Connect the cables to the back of your PTZ camera by putting them through the slot on the back of the PTZ Hood.
- Page 8 Step 12 Fold the flaps of the Hood alongside the edges of the Hood Attachment Frame. The flaps of the Hood are magnetic so they will automatically attach. Step 13 To prevent light from leaking through the hood, seal both zippers down. www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com...
- Page 9 Step 14 Mount your own tripod plate to the bottom plate by aligning the 1/4-20 and/or 3/8-16 screws and fastening them to the Bottom Plate. It is recommended that you connect your tripod plate to front of the Bottom Plate so that you can balance your teleprompter easier. Once your tripod plate is connected to the Bottom Plate, mount the tripod plate to your tripod head.
- Page 10 Step 16 To secure your teleprompter system, insert the included headless screws into the threads behind and in front of the Base. Step 17 The headless screws should be inserted to the threads as pictured below. www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com...
-
Page 11: Monitor Ports
Monitor Ports Monitor Menu Settings Video Config Contrast (White Level) Brightness (Black Level) Tint (Chroma Hue) Chroma (Chroma Saturation) Sharpness (Detail) RGB Setup – Manually configure RGB Return System Config Menu Duration – Set duration of how long menu stays on screen Video Ratio –... -
Page 12: Learn More
Pinout Diagram for Tally Light Red Light Green Light Contact Common Learn More More dynamic information at official website :www.ikancorp.com Support Contact email: support@ikancorp.com www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com... -
Page 13: Optional Accessories
Watch our VIDEO TUTORIAL on how to assemble PT419W Teleprompters https://ikancorp.com/pt419-tutorial-videos/ Optional Accessories PT4U-G Replacement Glass for PT419 M19W-V2 19” Talent Monitor Add On Kit for PT419W PT-PEDAL Teleprompter Foot Control Pedal PT-CONTROLLER Teleprompter Rotary Controller PT-CASE-4U Rolling Hard Case for PT419 Teleprompter www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com... - Page 14 Foam Case To make your teleprompter more portable, we packed it in a reusable, high-quality foam. The shape and size of the foam was designed to fit into Ikan’s PT-CASE-4U **DO NOT THROW AWAY FOAM CASE** Learn More More dynamic information at official website: www.ikancorp.com Support Contact email: support@ikancorp.com...
