Quoizel Dale DLE8406MBK Installation Manual

Download this manual

SAFETY INFORMATION

Please read and understand this entire manual before attempting to assemble, install or operate the product.

WARNING

• RISK OF ELECTRIC SHOCK - Before beginning installation, turn oﬀ electricity at the circuit breaker box or the main fuse box.

• RISK OF FIRE - Use bulbs speciﬁed by the markings and/or labels on the ﬁxture.

CAUTION

• For your safety, read instructions completely before beginning installation.

• If in doubt about electrical installation, consult a licensed electrician.

• Turn oﬀ electricity to ﬁxture and allow the bulbs to cool before replacing the bulb(s).

• TOOLS REQUIRED

CARE AND MAINTENANCE

• Wipe clean using soft, dry cloth or static duster. Always avoid using harsh chemicals and abrasives to clean ﬁxture as they may damage

the ﬁnish.

If you need further assistance call Quoizel Customer Care at 1-800-645-3184 (9:00am - 5:00pm EST), or visit us on-line at

www.quoizel.com.

PACKAGE CONTENTS

Fixture Body

x 1

MOUNTING HARDWARE

Inner Backplate

x 1

INSTALLATION GUIDE FOR DLE8405MBK

Glass Panel

x 3

Mounting Screw

x 4

Wire Connector

Outlet Box Screw

x 3

x 2

Released Date: 2024-09-05

Need help?

Do you have a question about the Dale DLE8406MBK and is the answer not in the manual?

Page 1 • Wipe clean using soft, dry cloth or static duster. Always avoid using harsh chemicals and abrasives to clean ﬁxture as they may damage the ﬁnish. If you need further assistance call Quoizel Customer Care at 1-800-645-3184 (9:00am - 5:00pm EST), or visit us on-line at www.quoizel.com.
Page 2 INSTALLATION Install Glass Panels Remove Cage from Fixture Body Beveled Surface is outside. Install Bulb Install Cage Back to Fixture Body Install correct bulb referring to ﬁxture markings and/or labels for maximum wattage. Recommended Bulb Type (not included): 100W BULB BASE TYPE BULB TYPE Medium (E26) TYPE A...
Page 3 INSTALLATION Wiring Install Fixture Body White wire from supply White from ﬁxture Black (or red) wire from supply Black from ﬁxture Ground wire from ﬁxture Ground wire from supply Green ground screw Apply Caulking * Note: Do NOT caulk the bottom of the backplate to allow moisture to escape. Your installation is now complete! Restore electricity and save this sheet for future reference.
