Table of Contents

Advertisement

Quick Links

Download this manual
Symbol Omnidirectional Scanner
Advanced Programmer's Guide
Click on
red text
at any location in the manual to
jump to the specified chapter, topic, or reference.
Table of Contents
Chapter 1: Advanced Data Formatting
Chapter 2: ADF Bar Codes
Copyright
70-15600-01
Revision C
June 1997

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LS 5000 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Symbol LS 5000 Series

Summary of Contents for Symbol LS 5000 Series

  • Page 1 Symbol Omnidirectional Scanner Advanced Programmer’s Guide Click on red text at any location in the manual to jump to the specified chapter, topic, or reference. Table of Contents Chapter 1: Advanced Data Formatting Chapter 2: ADF Bar Codes Copyright 70-15600-01...
  • Page 2 The material in this manual is subject to change without notice. Symbol reserves the right to make changes to any product to improve reliability, function, or design. Symbol does not assume any product liability arising out of, or in connection with, the application or use of any product, circuit, or application described herein.

  • Page 3: Table Of Contents

    Contents Chapter 1. Advanced Data Formatting Rules ..........1-2 Criteria .
  • Page 4 Character ........2-85 Send Pause ....... . . 2-88 Send Value .

  • Page 5: Chapter 1. Advanced Data Formatting

    PROGRAMMING bar code on page 2-3. When you have finished, you must then scan the DISABLE PROGRAM- MING bar code on page 2-604. All other Symbol omnidirectional scanners can be programmed at any time and do not require these symbols. For these scanners, simply scan the bar codes for the parameters you wish to set.

  • Page 6: Rules

    Symbol Omnidirectional Scanners: Advanced Data Formatting Rules To build a rule, you must select Criteria and Actions. The rules you enter must be logically correct. Criteria include Input Source, Code Type, Code Length, and Message Containing a Specific Data String. Actions are any alterations related to, or affecting these Criteria.

  • Page 7: Message Containing A Specific Data String

    Symbol Omnidirectional Scanners: Advanced Data Formatting Message Containing A Specific Data String Select whether the formatting will affect data that begins with a specific character or data string, or contains a specific character or data string. Specific String at Start - Scan this bar code, then scan the desired character or characters (up to a total of 8) in the alphanumeric keyboard bar codes.

  • Page 8: Actions

    Symbol Omnidirectional Scanners: Advanced Data Formatting Actions Select how to format the data for transmission. Send Data - Send all data that follows, send all data up to a specific character selected from the alphanumeric keyboard bar code, or send the next N characters.
  • Page 9 Symbol Omnidirectional Scanners: Advanced Data Formatting Move Cursor Past a Character - This parameter will move the cursor past all occurrences of a selected character. Scan this bar code, then select a character from the alphanumeric keyboard. Send Keystroke - Scan the “Send __” bar code for the keystroke you wish to send.
  • Page 10 Symbol Omnidirectional Scanners: Advanced Data Formatting Pad Data on Left With Zeros - To pad data to the left, scan the bar code containing the desired number of zeros. This parameter is activated by Send commands. Send Preset Value - Send Values 1 through 6 by scanning the appropriate bar code.

  • Page 11: Alternate Rule Sets

    Symbol Omnidirectional Scanners: Advanced Data Formatting Alternate Rule Sets ADF rules may be grouped into one of four alternate sets which can be turned on and off when needed. This is useful when you want to format the same message in different ways.
  • Page 12 Symbol Omnidirectional Scanners: Advanced Data Formatting To implement this, you would first enter an ADF rule that applies to the normal situation. This rule may look like this: When scanning a bar code of length 15, send the next 2 characters, send the class key, send the next 8 characters, send the stock key, send the data that remains, send the enter key.
  • Page 13 Symbol Omnidirectional Scanners: Advanced Data Formatting The switching back to normal rules can also be done in the “sale” rule. For example, the rule may look like this: When scanning a bar code of length 15, send the next 2 characters, send the class key, send the next 8 characters, send the stock key, turn off rule set 1.

  • Page 14: Rules Hierarchy (In Bar Codes)

    Symbol Omnidirectional Scanners: Advanced Data Formatting Rules Hierarchy (in Bar Codes) When rules are created, they are stored at the “top” of a rules list. If three rules have been created, the list would be configured as follows: Third Rule...

  • Page 15: Default Rules

    Symbol Omnidirectional Scanners: Advanced Data Formatting Note also that ADF Rules are actually created when you use the standard data editing functions. Scan serial, and magstripe options are entered as ADF rules, and the hierarchy mentioned above also applies to them. These rules reside in the same “rule list”...

  • Page 16: Beeper Definitions

    Symbol Omnidirectional Scanners: Advanced Data Formatting Beeper Definitions Beeper Sequence Indication Short High-Low Entry of a number is expected. Enter another digit. Add leading zeros to the front if necessary. Short Low-Low Entry of an alphabetic character is expected. Enter another character or scan the End of Message bar code.
  • Page 17 Symbol Omnidirectional Scanners: Advanced Data Formatting Beeper Sequence Indication Long Low-High-Low- Out of rule memory. Erase some High existing rules, then try to save rule again. (The current rule need not be re-entered.) Long Low-High-Low Cancel rule entry. Rule entry mode exited because of an error or the user asked to exit rule entry.

  • Page 18: Adf Bar Code Menu Example

    Symbol Omnidirectional Scanners: Advanced Data Formatting ADF Bar Code Menu Example This section will show you specifically how ADF rules are entered and used. Examples are given for each of the three data sources. Formatting Scan Data A local men's clothing store wants to encode a vendor number, size, and color code into their own Code 128 bar codes.

  • Page 19: Rule 1: The Code 128 Scanning Rule

    Symbol Omnidirectional Scanners: Advanced Data Formatting To enter these rules, follow the steps below and on the next page: Rule 1: The Code 128 Scanning Rule Step Bar Code Beep Indication Page Either Scanner Port 2-22 High High Code 128...

  • Page 20: Rule 2: The Upc Scanning Rule

    Symbol Omnidirectional Scanners: Advanced Data Formatting Rule 2: The UPC Scanning Rule Step Bar Code Beep Indication Page Either Scanner Port 2-22 High High UPC/EAN 2-51 High High Send All Data That 2-106 High High Remains Send F1 2-437 High High...

  • Page 21: Formatting Magstripe Data (Ls 5000/5100/5200)

    A small department store chain called “the STORE” accepts all major credit cards, and their own credit card. They use a dual track magstripe reader with their Symbol product. The major credit cards follow the standard encoding methods, but the store card is different. The word “STORE”...
  • Page 22 Symbol Omnidirectional Scanners: Advanced Data Formatting The following rules need to be entered: When dual magstripe data is read, and the data contains “STORE” starting at position 2, send the [F5] key, select track 2, skip ahead 1 character, send all data up to “-”, send the [ENTER] key, Select track 1, skip all data up to “-”, send all data...

  • Page 23: Rule 3: The Bank Credit Card Rule

    Symbol Omnidirectional Scanners: Advanced Data Formatting Rule 3: The Bank Credit Card Rule Step Bar Code Beep Indication Page Dual Magstripe Reader 2-27 High High Send F6 2-442 High High Send account number 2-127 High High Send Enter Key 2-430...

  • Page 24: High High

    Symbol Omnidirectional Scanners: Advanced Data Formatting 2-564 Low Low 2-565 Low Low 2-560 Low Low 2-563 Low Low 2-550 Low Low End of Message 2-573 High High Send F5 2-441 High High Skip ahead 1 character 2-133 High High Send up to character...

  • Page 25: High Low High

    Symbol Omnidirectional Scanners: Advanced Data Formatting Save Rule High Low High This very long rule illustrates the ability of ADF to handle non-standard credit card formats. Most ADF users will be writing rules for standard credit cards, as illustrated in Rule...

  • Page 26: Formatting Serial Data

    Symbol Omnidirectional Scanners: Advanced Data Formatting Formatting Serial Data A convenience store has a smart weight scale that transmits the price of an item, followed by the weight and description. The weight is a 6 digit number from 0 to 999.999.

  • Page 42: Special Commands

    Symbol Omnidirectional Scanners: ADF Bar Codes Special Commands Rule Sets DISABLE RULE SET 1 2-14...
  • Page 43 Symbol Omnidirectional Scanners: ADF Bar Codes Special Commands Rule Sets DISABLE RULE SET 2 2-15...
  • Page 44 Symbol Omnidirectional Scanners: ADF Bar Codes Special Commands Rule Sets DISABLE RULE SET 3 2-16...
  • Page 45 Symbol Omnidirectional Scanners: ADF Bar Codes Special Commands Rule Sets DISABLE RULE SET 4 2-17...
  • Page 46 Symbol Omnidirectional Scanners: ADF Bar Codes Special Commands Rule Sets DISABLE ALL RULE SETS 2-18...

  • Page 96: Code Lengths

    Symbol Omnidirectional Scanners: ADF Bar Codes Criteria Code Lengths This is not a keypad. Select one length per rule only. 2-68...
  • Page 97 Symbol Omnidirectional Scanners: ADF Bar Codes Criteria Code Lengths This is not a keypad. Select one length per rule only. 2-69...
  • Page 98 Symbol Omnidirectional Scanners: ADF Bar Codes Criteria Code Lengths This is not a keypad. Select one length per rule only. 2-70...
  • Page 99 Symbol Omnidirectional Scanners: ADF Bar Codes Criteria Code Lengths This is not a keypad. Select one length per rule only. 2-71...
  • Page 100 Symbol Omnidirectional Scanners: ADF Bar Codes Criteria Code Lengths This is not a keypad. Select one length per rule only. 2-72...
  • Page 101 Symbol Omnidirectional Scanners: ADF Bar Codes Criteria Code Lengths This is not a keypad. Select one length per rule only. 2-73...
  • Page 102 Symbol Omnidirectional Scanners: ADF Bar Codes Criteria Code Lengths This is not a keypad. Select one length per rule only. 2-74...
  • Page 103 Symbol Omnidirectional Scanners: ADF Bar Codes Criteria Code Lengths This is not a keypad. Select one length per rule only. 2-75...
  • Page 104 Symbol Omnidirectional Scanners: ADF Bar Codes Criteria Code Lengths This is not a keypad. Select one length per rule only. 2-76...
  • Page 105 Symbol Omnidirectional Scanners: ADF Bar Codes Criteria Code Lengths This is not a keypad. Select one length per rule only. 2-77...
  • Page 106 Symbol Omnidirectional Scanners: ADF Bar Codes Criteria Code Lengths This is not a keypad. Select one length per rule only. 2-78...
  • Page 107 Symbol Omnidirectional Scanners: ADF Bar Codes Criteria Code Lengths This is not a keypad. Select one length per rule only. 2-79...
  • Page 108 Symbol Omnidirectional Scanners: ADF Bar Codes Criteria Code Lengths This is not a keypad. Select one length per rule only. 2-80...
  • Page 109 Symbol Omnidirectional Scanners: ADF Bar Codes Criteria Code Lengths This is not a keypad. Select one length per rule only. 2-81...
  • Page 110 Symbol Omnidirectional Scanners: ADF Bar Codes Criteria Code Lengths This is not a keypad. Select one length per rule only. 2-82...

  • Page 111: Specific Data String

    Symbol Omnidirectional Scanners: ADF Bar Codes Criteria Specific Data String SPECIFIC STRING AT START • Go to Alphanumeric Keyboard to enter string (Followed by END OF MESSAGE on 2-573) 2-83...
  • Page 112 Symbol Omnidirectional Scanners: ADF Bar Codes Criteria Specific Data String SPECIFIC STRING ANY LOCATION • Go to Numeric Keypad to enter location (2 digits), then • Go to Alphanumeric Keyboard to enter string (Followed by END OF MESSAGE on 2-573)

  • Page 113: Actions

    Symbol Omnidirectional Scanners: ADF Bar Codes Actions Character SEND UP TO CHARACTER* *Enter character from alphanumeric keyboard. 2-85...
  • Page 114 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Character MOVE TO CHARACTER* *Enter character from alphanumeric keyboard. 2-86...
  • Page 115 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Character MOVE PAST CHARACTER* *Enter character from alphanumeric keyboard. 2-87...

  • Page 116: Send Pause

    Symbol Omnidirectional Scanners: ADF Bar Codes Actions Send Pause SEND PAUSE 2-88...

  • Page 117: Send Value

    Symbol Omnidirectional Scanners: ADF Bar Codes Actions Send Value SEND VALUE 1 2-89...
  • Page 118 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Send Value SEND VALUE 2 2-90...
  • Page 119 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Send Value SEND VALUE 3 2-91...
  • Page 120 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Send Value SEND VALUE 4 2-92...
  • Page 121 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Send Value SEND VALUE 5 2-93...
  • Page 122 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Send Value SEND VALUE 6 2-94...

  • Page 123: Beeps

    Symbol Omnidirectional Scanners: ADF Bar Codes Actions Beeps Choose only one beep sequence per ADF rule BEEP ONCE 2-95...
  • Page 124 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Beeps Choose only one beep sequence per ADF rule. BEEP TWICE 2-96...
  • Page 125 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Beeps Choose only one beep sequence per ADF rule BEEP THREE TIMES 2-97...

  • Page 126: Turn On/Off Rule Sets

    Symbol Omnidirectional Scanners: ADF Bar Codes Actions Turn On/Off Rule Sets TURN ON RULE SET 1 2-98...
  • Page 127 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Turn On/Off Rule Sets TURN ON RULE SET 2 2-99...
  • Page 128 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Turn On/Off Rule Sets TURN ON RULE SET 3 2-100...
  • Page 129 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Turn On/Off Rule Sets TURN ON RULE SET 4 2-101...
  • Page 130 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Turn On/Off Rule Sets TURN OFF RULE SET 1 2-102...

  • Page 141: Send Characters/ Data

    Symbol Omnidirectional Scanners: ADF Bar Codes Actions Send Characters/ Data SEND NEXT 7 CHARACTERS 2-113...
  • Page 142 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Send Characters/ Data SEND NEXT 8 CHARACTERS 2-114...
  • Page 143 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Send Characters/ Data SEND NEXT 9 CHARACTERS 2-115...
  • Page 146 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Send Characters/ Data SEND NEXT 12 CHARACTERS 2-118...
  • Page 147 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Send Characters/ Data SEND NEXT 13 CHARACTERS 2-119...
  • Page 148 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Send Characters/ Data SEND NEXT 14 CHARACTERS 2-120...
  • Page 149 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Send Characters/ Data SEND NEXT 15 CHARACTERS 2-121...
  • Page 150 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Send Characters/ Data SEND NEXT 16 CHARACTERS 2-122...
  • Page 151 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Send Characters/ Data SEND NEXT 17 CHARACTERS 2-123...
  • Page 152 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Send Characters/ Data SEND NEXT 18 CHARACTERS 2-124...
  • Page 153 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Send Characters/ Data SEND NEXT 19 CHARACTERS 2-125...
  • Page 154 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Send Characters/ Data SEND NEXT 20 CHARACTERS 2-126...
  • Page 155 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Send Characters/ Data SEND ACCOUNT NUMBER* This option applies only to those scanners that support a mag- stripe reader. 2-127...
  • Page 156 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Send Characters/ Data SEND EXP DATE (MMYY)* This option applies only to those scanners that support a mag- stripe reader. 2-128...
  • Page 157 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Send Characters/ Data SEND EXP DATE (YYMM)* This option applies only to those scanners that support a mag- stripe reader. 2-129...
  • Page 158 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Send Characters/ Data SEND CUSTOMER’S NAME* This option applies only to those scanners that support a mag- stripe reader. 2-130...
  • Page 159 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Send Characters/ Data SELECT TRACK 1 DATA* This option applies only to those scanners that support a mag- stripe reader. 2-131...
  • Page 160 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Send Characters/ Data SELECT TRACK 2 DATA* This option applies only to those scanners that support a mag- stripe reader. 2-132...
  • Page 161 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Skip Ahead/Back SKIP AHEAD 1 CHARACTER 2-133...
  • Page 162 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Skip Ahead/Back SKIP AHEAD 2 CHARACTERS 2-134...
  • Page 163 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Skip Ahead/Back SKIP AHEAD 3 CHARACTERS 2-135...
  • Page 164 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Skip Ahead/Back SKIP AHEAD 4 CHARACTERS 2-136...
  • Page 165 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Skip Ahead/Back SKIP AHEAD 5 CHARACTERS 2-137...
  • Page 166 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Skip Ahead/Back SKIP AHEAD 6 CHARACTERS 2-138...
  • Page 167 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Skip Ahead/Back SKIP AHEAD 7 CHARACTERS 2-139...
  • Page 168 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Skip Ahead/Back SKIP AHEAD 8 CHARACTERS 2-140...
  • Page 169 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Skip Ahead/Back SKIP AHEAD 9 CHARACTERS 2-141...
  • Page 170 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Skip Ahead/Back SKIP AHEAD 10 CHARACTERS 2-142...
  • Page 171 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Skip Ahead/Back SKIP BACK 1 CHARACTER 2-143...
  • Page 172 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Skip Ahead/Back SKIP BACK 2 CHARACTERS 2-144...
  • Page 173 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Skip Ahead/Back SKIP BACK 3 CHARACTERS 2-145...
  • Page 174 Symbol Omnidirectional Scanners: ADF Bar Codes Actions Skip Ahead/Back SKIP BACK 4 CHARACTERS 2-146...
  • Page 580 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-552...
  • Page 581 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-553...
  • Page 582 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-554...
  • Page 583 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-555...
  • Page 584 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-556...
  • Page 585 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-557...
  • Page 586 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-558...
  • Page 587 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-559...
  • Page 588 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-560...
  • Page 589 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-561...
  • Page 590 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-562...
  • Page 591 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-563...
  • Page 592 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-564...
  • Page 593 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-565...
  • Page 594 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-566...
  • Page 595 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-567...
  • Page 596 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-568...
  • Page 597 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-569...
  • Page 598 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-570...
  • Page 599 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-571...
  • Page 600 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard CANCEL 2-572...
  • Page 601 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard END OF MESSAGE 2-573...
  • Page 602 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-574...
  • Page 603 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-575...
  • Page 604 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-576...
  • Page 605 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-577...
  • Page 606 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-578...
  • Page 607 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-579...
  • Page 608 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-580...
  • Page 609 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-581...
  • Page 610 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-582...
  • Page 611 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-583...
  • Page 612 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-584...
  • Page 613 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-585...
  • Page 614 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-586...
  • Page 615 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-587...
  • Page 616 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-588...
  • Page 617 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-589...
  • Page 618 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-590...
  • Page 619 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-591...
  • Page 620 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-592...
  • Page 621 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-593...
  • Page 622 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-594...
  • Page 623 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-595...
  • Page 624 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-596...
  • Page 625 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-597...
  • Page 626 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-598...
  • Page 627 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-599...
  • Page 628 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-600...
  • Page 629 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-601...
  • Page 630 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-602...
  • Page 631 Symbol Omnidirectional Scanners: ADF Bar Codes Alphanumeric Keyboard 2-603...
  • Page 632 Symbol Omnidirectional Scanners: ADF Bar Codes Disable Programming This bar code is needed for LS 5000, LS 5100 and LS 5200 series scanners only. All other Symbol omnidirectional scanners are programmed without using this bar code. DISABLE PROGRAMMING (LS 5000/5100/5200)

This manual is also suitable for:

Ls 5100 seriesLs 5200 series

Table of Contents
