P-1620 Check Valve Replacement
Instructions - CX
Warning
This replacement kit shall be installed by a qualified service agent in accordance with these
instructions and all applicable codes and requirements of the authority having jurisdiction. If the
information in these instructions is not followed exactly a fire, an explosion or production of
carbon monoxide may result causing property damage, personal injury or loss of life.
The qualified service agency is responsible for the proper installation of this kit. The installation
is not proper and complete until the operation is checked as specified in these instructions.
Part #
180-326
When to Install the P-1620 Check Valve Replacement Kit
Install the P-1620 kit if you need to replace a damaged bypass check valve.
Item Number
Description
A
Bypass Check Valve
Note
A ladder or step may be required to have a clear vertical view of the work area.
Do not attempt to remove the assemblies without a clear view, as damage to the connectors,
screws or refractory may occur.
IBC Technologies Inc.
-
120-533E0
September 12, 2023
Check Valve - CX
Description
Check Valve, Combi
CX Combi with Check Valve
- Released Document
Quantity
1
|
1-844-432-8422
www.ibcboiler.com
1 of 2
Advertisement
Related Manuals for IBC P-1620
Summary of Contents for IBC P-1620
- Page 1 Description Quantity 180-326 Check Valve, Combi When to Install the P-1620 Check Valve Replacement Kit Install the P-1620 kit if you need to replace a damaged bypass check valve. CX Combi with Check Valve Item Number Description Bypass Check Valve Note A ladder or step may be required to have a clear vertical view of the work area.
- Page 2 4. Turn on power to the boiler. 5. Turn on call(s) for heat. 6. Check connections for leaks during operation. 7. Perform a combustion analysis, and test for proper operation. 8. Reinstall the front cover. IBC Technologies Inc. 1-844-432-8422 www.ibcboiler.com - Released Document 120-533E0...
