P-1001 Controller Board Replacement
Kit Instructions - AHU
Warning
This replacement kit shall be installed by a qualified service agency in accordance with the
manufacturer's instructions and all applicable codes and requirements of the authority having
jurisdiction. If the information in these instructions is not followed exactly, a fire, an explosion or
production of carbon monoxide may result causing property damage, personal injury or loss of
life.
The qualified service agency is responsible for the proper installation of this kit. The installation
is not proper and complete until the operation of the converted appliance is checked as specified
in the manufacturer's instructions supplied with the kit.
150-014
152-003
240-168
255-122
500-186
When to Install the P-1001 Control Board Replacement Kit
Install the P-1001 kit if you need to replace a damaged control board in an AHU
Note
A ladder or step may be required to have a clear vertical view of the work area.
Do not attempt to remove the assemblies without a clear view, as damage to the connectors,
screws or refractory may occur.
IBC Technologies Inc.
Released Document
120-456E0
August, 2022
Control Board - AHU
Part #
Screw, 6-32 X 3/8
Cable tile, white 4.0"
Fuse block cover
Humidity sensor gasket
PCB controller
Description
1-844-432-8422
Quantity
4
1
1
1
1
|
www.ibcboiler.com
1 of 4
